Page 2
CONGRATULATIONS ON PURCHASING YOUR TOTALLY WICKED D16 ELECTRONIC CIGARETTE...
Page 3
Mouthpiece Atomizer Power Button D16 Tank Atomizer Base Battery Body...
Page 4
Using your D16 Kit maximum fill level. Filling the D16 Tank with e-liquid: Grip the base of the D16 tank and Note: Be sure to “prime” the remove the tank from the battery by unscrewing. Once removed turn atomizer head before first use by dripping a few drops of e-liquid the tank so that the base is at the into the centre, then allowing it to...
Page 6
Using your D16 Kit Powering On and Off: Installing/Replacing an Atomizer The D16 kit uses a 5 click on/off Head: function. To switch the D16 on, To install a new atomizer head, press the power button five times remove the tank base as described in quick succession.
Page 8
Using your D16 Kit Charging the Battery: Vaping: The D16 battery is recharged by Press and hold the power button inserting the micro USB cable into as you inhale vapour from the the micro USB port situated to the mouthpiece. Release the power left of the vape button.
Page 9
Using your D16 Kit Battery Life Indication: The remaining battery charge is indicated by the illumination of the LED shortly after the devices power button has been released. The battery’s remaining level of charge and corresponding light conditions are detailed in the table below. Battery Level Light Condition 60%-100%...
Page 10
Using your D16 Kit Short Circuit Protection: Incompatible Resistance Warning: If an atomizer short circuit occurs If the atomizer heads resistance or the atomizer head’s resistance is exceeds 5.0ohms, the vape buttons below 0.2ohms, the LED will flash LED will slowly flash to indicate the 3 times and the D16 kit will not atomizer heads resistance is too produce power or vapour.
Page 11
Using your D16 Kit Atomizer Protection: Low Voltage Protection: To protect the atomizer head, the When the internal battery cell’s D16 has a 10 second cut off safety remaining voltage drops below feature. If the vape button is held 3.3V, the LED will flash 40 times down for longer than ten seconds quickly and the device will power while vaping, the D16 kit will cease...
Additional product information There are no reported medical side effects with this product. If you believe you experience a side effect, please contact the manufacturer. Warranty The D16 kit components have a 28-day parts warranty, with the exception of atomizer heads, which are a consumable item and covered by ‘dead on arrival’...
Page 15
Product Storage and Battery Precautions • Store the D16 kit and its accessories away from children when not in use. • Ensure the D16 kit is powered off when not in use. • Avoid accidentally pressing the D16 power button when not in use. •...
Page 16
GLÜCKWUNSCH ZUM KAUF IHRES TOTALLY WICKED D16 E-ZIGARETTEN KITS.
Page 17
Mundstück Verdampferkopf Powertaster D16 Tank Verdampferbasis Akku...
Page 18
Bedienung Ihres D16 Kits überfüllen. Setzen Sie anschließend D16 Tank befüllen: alle Komponenten in umgekehrter Schrauben Sie zunächst die Reihenfolge wieder zusammen. gesamte Tankeinheit vom Akku ab. Drehen Sie den Tank mit Hinweis: Träufeln Sie vor der dem Mundstück nach unten und ersten Benutzung etwas E-Liquid schrauben Sie die Verdampferbasis direkt in den Verdampferkopf...
Page 20
Bedienung Ihres D16 Kits Power Ein/Aus: Verdampferkopf-Installation: Das D16 Kit verfügt über eine 5-Klick Entfernen sind die Verdampferbasis Ein/Aus-Funktion. Drücken Sie zum wie unter “D16 Tank befüllen” Einschalten den Powertaster 5-mal beschrieben. Der Verdampferkopf zügig in Folge. Die Powertaster kann durch einfaches ziehen LED blinkt danach 5-Mal auf von der Basis entfernt werden.
Page 22
Bedienung Ihres D16 Kits Akku aufladen: Dampfen: Der D16 Akku wird mit dem USB- Powertaster drücken und inhalieren. Kabel am Mikro-USB-Port (links Wenn der Taster gedrückt wird, neben dem Powertaster) aufgeladen. leuchtet eine LED auf. Nutzen Sie bitte als Stromquelle einen geeigneten USB-Port oder USB-Netzstecker.
Page 23
Bedienung Ihres D16 Kits Akku-Ladestandanzeige: Der Ladestand des Akkus ist nach jeder Betätigung des Powertasters über unterschiedliches Aufleuchten der LED ersichtlich – siehe nachfolgende Tabelle. Akkuladestand LED Indikatoren 60%-100% Dauerleuchten 30%-59% Pulsierendes Aufleuchten 10%-29% Schnelleres Aufleuchten 0-9% Schnelles Aufleuchten...
Page 24
Bedienung Ihres D16 Kits Kurzschluss-Schutzfunktion: Widerstandsanzeige: Wenn das Gerät einen Wenn das Gerät einen Verdampferkopf-Kurzschluss erkannt Verdampferkopf-Widerstand höher hat oder der Widerstand ist niedriger als 5 Ohm erkannt hat, blinkt die als 0.2 Ohm, blinkt die LED 3-mal LED langsam auf. Vergewissern auf und die Stromzufuhr an den Sie sich, dass der Verdampferkopf Verdampfer wird unterbrochen...
Page 25
Bedienung Ihres D16 Kits 10 Sek. Sicherheitsabschaltung: Niederspannungsschutz: Hält man den Powertaster langer Fällt die Akku-Spannung auf unter als 10 Sek. gedrückt, wird die 3,3 Volt, blinkt die LED 40-mal auf Stromzufuhr an den Verdampfer und das Gerät schaltet sich ab – automatisch unterbrochen.
Page 26
Kit Inhalt: 1 x D16 Tank 1 x D16 Akku 1 x HC 1.6 Ohm Verdampferkopf (bereits eingesetzt) 1 x HC 1.6 Ohm Verdampferkopf (Ersatz) 1 x USB Kabel 1 x Bedienungsanleitung...
Page 27
Spezifikationen D16 Akku Spezifikationen D16 Tank Abmessungen: 93mm x 16,5mm Abmessungen: 58,6mm x 16,5mm Akkuzellen: Integriert Tankkapazität: 2ml Akzeptierte Verdampferkopf- Verdampferkopf-Typ: HC Widerstände: 0.2 Ohm – 5 Ohm Maximaler Durchmesser für Verdampferanschluss: 510er Einfüllstutzen: 3,7mm Gewinde...
Die D16 Kit Komponenten haben eine 28-tägige Garantie. Verdampferköpfe sind als Verschleißteil von der Garantie ausgeschlossen und durch eine DOA- Regulierung abgedeckt. Das mitgelieferte USB-Kabel hat eine 12-monatige Garantie. Sollte eine Komponente fehlerhaft sein, bitten wir Sie Ihren Händler oder den Totally Wicked Kundenservice zu kontaktieren.
Page 29
Aufbewahrungshinweise und Sicherheitsinformationen • Das D16 Kit und das Zubehör außerhalb der Reichweite von Kindern aufbewahren. • Schalten Sie das D16 Kit aus, wenn nicht in Gebrauch. • Vermeiden Sie versehentliches Drücken des Powertasters, wenn das D16 Kit nicht in Gebrauch ist. •...
Page 30
Tel 01254 692244 Manufactured in China www.totallywicked.co.uk under the authority of Pillbox38 UK Ltd, Tel 1(888) 761-9425 Stancliffe Street, www.totallywicked.com Blackburn, Lancashire, Tel 0941-78447082 BB2 2QR. www.totallywicked.de...
