Durite VID-509 User Manual

Mini dash mount dvr with gp 12/24volt

Table of Contents

Download this manual

Before using this unit please read these instructions carefully. Take special care to follow the warnings

indicated on the unit itself as well as the safety suggestions listed below. Keep these instructions for

future reference.

* Please ensure you are familiar and comply with local traffic and driving regulations.

* P ower Source - T he Mini DVR should be connected to a 12-24 volt DC power supply only.

* W ater and Moisture - D o n ot u se t he M ini D VR w here i t m ay b e s ubject t o w ater i ngress o r e xcessive

moisture. Do not use outside the vehicle unprotected.

* Heat - Do not install the Mini DVR near a direct heat s ources.

* V entilation - T he Mini DVR should be situated to allow free circulation of air.

* F oreign Material - Care should be taken so that objects do not fall onto or into, and that liquids are

not spilled on the Mini D VR.

* M ounting Surface - T he Mini DVR should be mounted to a strong secure surface.

* Replacement Parts - Use only manufacturers replacement specified parts. Unauthorized substitutions

may result in fire risk, electric shock or other hazards and will void the warranty

* S ervice - The user should not attempt to service this units beyond that described in the operating

instructions. T here are no user-serviceable parts within the unit.

* S creen Protective Film - Remove the LCD screen protective plastic cover before use.

Mini Dash Mount DVR with GPS

12/24 V olt

VID-509 (0-776-60)

WARNINGS

Table of Contents

Do you have a question about the VID-509 and is the answer not in the manual?

Page 1 Mini Dash Mount DVR with GPS 12/24 V olt VID-509 (0-776-60) WARNINGS Before using this unit please read these instructions carefully. Take special care to follow the warnings indicated on the unit itself as well as the safety suggestions listed below. Keep these instructions for ...
Page 2 BUTTON LAYOUT BUTTON FUNCTIONS EXPLAINED 1. <Power> Button Function 1: Power on/off In p ower-off s tate, p ress t he < Power> b utton t o p ower o n t his D VR. T hen, t he D VR b egins t o w ork a uto- matically.
Page 3 3. <OK> Button Function 1: Locking During t he v ideo-recording p rocess, p ress t he < OK> b utton t o s ave t he v ideo-recording d ata i nto a s epa- rate folder in the memory card.
Page 4: Operation Guide
OPERATION GUIDE A. Installing the DVR 1. Power off the automobile e ngine. 2. Insert the T F card (Micro SD) into the T F slot. The 1080P format is adopted for the video-recording function, and a large amount of data is a.
Page 5: Specifications
5. Collision Sensing The DVR is fitted with a built-in collision sensor (G-sensor). In case of severe vehicle collision, the DVR locks the image data generated at the time of the accident, and displays a lock icon in the middle of the screen.
Page 6 GPS SOFTWARE IMAGE The image below is to show an example of the features available in the software provided with this mini dash mount DVR. The software shows the location of the vehicle via GPS. It also shows the speed and the G Force upon the vehicle as it travels.

0-776-60
