Biocare 3060 Owner's Manual

Blood Pressure Monitor
Wrist Strap Blood Pressure Monitor
Owner's Manual
Model : 3060
Dear 3060 System Owner :
Thank you for purchasing the 3060 Blood Pressure Monitoring System. This manual provides
important information to help you operate this system correctly. Before using this product,
please read the following contents thoroughly and carefully.
With the compact size and easy operation of this 3060 Blood Pressure Monitoring System, you
can easily monitor your blood pressure by yourself at any time or place. In addition, this
system can help you and your healthcare professionals to monitor and adjust your treatment
plans, and keep your blood pressure under control.
If you have other questions regarding this product, please contact the place of purchase.

IMPORTANT SAFETY PRECAUTIONS READ THIS BEFORE USE

1. Use this device ONLY for the intended use described in this manual.
2. Do NOT use accessories which are not speci ed by the manufacturer.
3. Do NOT use the device if it is not working properly or damaged.
4. Do NOT use the equipment where aerosol sprays are being used, or where oxygen is being
administered.
5. Do NOTuse under any circumstances on newborns.
6. This device does NOT serve as a cure for any symptoms or diseases. The data measured are
for reference only. Always consult your doctor to have the results interpreted.
7. Keep the equipment and its exible cord away from hot surfaces.
8. Do NOT apply the cu to areas other than the place directed.
9. Do NOT remove plastic wrapping membrane to ensure the waterproof function.
10.proper maintenance and periodically calibration are essential to the longevity of your
device. If you are concerned about your accuracy of measurement, please contact local
customer service for help.
KEEP THESE INSTRUCTIONS
BEFORE YOU BEGIN
☉ Intended Use
The 3060 system is a system designed to measure the systolic and diastolic blood pressure and
pulse rate by using a non-invasive technique in which an in atable cu is wrapped on the
wrist. It is intended for individuals age 18 and above for use at home and in clinical settings.
The device is not to be used for the diagnosis or screening of hypertension or for testing on
newborns.
☉ Test Principle
Blood pressure is measured non-invasively at the wrist based on oscillometric method.
This device is NOT able to take measurements in the presence of common
arrhythmia, such as atrial or ventricular premature beats or atrial brillation. It may
produce reading error.

MONITOR OVERVIEW

➊ AC/DC Adaptor Socket
➋ M/SET Buttton
➌ CAM Button
➍ Wrist Cuff

➎ Display Screen

➏ Power Button
➐ Battery compartment
Do not use the accessory or equipments which are not certified by Manufacture. It
might increased emissions or decreased immunity of this system.
Owner's Manual
DISPLAY SCREEN
1. WHO classification indicator
➑ ➒
2. User Number
3. Night-time Average
➋ ➓
4. Day-time Average
5. Number of memory
6. Memory recall
➊
7. CAM Mode
8. Date
9. Time
10. Daily Alarm
11. Irregular heartbeat indicator
12. Pulse rate
13. Low battery indicator
➌
14. Diastolic pressure reading
➍
➎ 15. Systolic pressure reading
➏ ➐

SETTING THE MONITOR

Before using your monitor for the rst time, check and update these settings. Make sure you
complete the steps below and save the desired settings.
Entering the Setting Mode
Start with the monitor o . Press and rmly hold M/SET for 3 seconds until the "2012" ashes on
the upper right corner.
If the meter is idle for 1.5 minutes, it turns to no time setting: "--/--/--:--".

Setting the Date and the Time

With the year ashing, press M/SET button until the correct year appears.
Press CAM button to set.
With the month ashing, press M/SET button until the correct month appears.
Press CAM button to set.
With the day ashing, press M/SET button until the correct day appears.
Press CAM button to set.
With the hour ashing, press M/SET button to select the desired time system 24hr or 12hr,
AM/PM only displays while the 12hr system is selected. Press CAM button to set.
With the minute ashing, press M/SET button until the correct minute appears.
Press CAM button to set and exit from date/time setting.
NOTE
1. If the meter is idle for 1.5 minutes during the setting mode, it will switch o automatically

Setting the Alarm

With device in standby status, press and rmly hold M/SET
button and CAM button at the same time for 2 seconds until
an alarm icon ashes on the upper right corner.
Release the both buttons and then "1" will ash on the screen,
press M/SET button to switch between alarm "1" and "2".
Press CAM button with the hour ashing, press M/SET button
until the desired hour appears. Press CAM button to set.
With the minute ashing, press M/SET button until the desired
minute appears.
Press CAM button to set. The meter will switch o automatically.
At the time of your alarm, the meter will beep and automatically
turn on. You can press every button to silence the alarm. When
the alarm "1" or "2" ashing, press CAM button to switch o the
alarm, the display "ON" changed to be "OFF"

USER NUMBER SELECTION

This system stores blood pressure measurements for up to two users.
Each user has 60 memories stored separately.
1. With device in standby status, user 1 is the default user. Press START
button and M/SET button for 1 second till User "1" icon hides and User "2" icon shows.
2. When User "2" icon displays, Press START button and M/SET button for 1 second again, User
"1" icon displays and hides User "2" icon.
Owner's Manual

TESTING YOUR BLOOD PRESSURE

BEFORE MEASUREMENT

☉Avoid ca eine, tea, alcohol and tobacco for at least 30 minutes before measurement.
☉Wait 30 minutes after exercising or bathing before measurement.
☉Sit or lie down for at least 10 minutes before measurement.
☉Do not measure when feeling anxious or tense.
☉Take a 5-10 minute break between measurements. This break can be longer if necessary,
depending on your physical condition
☉Keep the records for your doctor as reference.
☉Blood pressure naturally varies between each arm. Always measure your blood pressure on
the same wrist.

CORRECT APPLICATION OF THE PRESSURE CUFF

Slide the cu onto your wrist. Wrap the cu comfortably
around your wrist.
The top margin of the meter should be about 0.6 cm to
1.3 cm (1/4 to 1/2 inch) below the ball of thumb. When the
cu is positioned correctly, fold the loose end back and
secure it in place by pressing the pile material rmly
against the hook material.
Warning!!
Always apply the wrist cu before turning on the device. Failure
to do so will damage the device.
TESTING YOUR BLOOD PRESSURE
Step1 Sit down for at least 10 minutes before measuring
Step2 Apply the wrist cu
Step3 Press the POWER button
and place your arm in front of your chest. Relax and make sure
the device is at the same height as your heart. Holding the
elbow of the arm wearing the wrist cu with your other hand
helps you hold still during measurement. Remain still and do
not talk or move during the measurement.

TAKING MEASUREMENTS

TAKING A SINGLE MEASUREMENT

Always apply the pressure cu before turning on the monitor.
1.Touch the Power button to turn the monitor on, move the device
to be the same height as the heart. When the position is correct, a
red bar and a yellow bar ash on the display and device starts
automatically. Otherwise, two red bars ashing indicate the position
is too high while two green bars ashing to prompt too low.
2. "0" displays on LCD which means device is under auto zero resetting.
3. Pump starts to in ate and pressure in cu increases
to working pressure.
4. The heart symbol " " will show silently when pulse is
detected during the in ation. When signal of pulse becomes
strong, " " icon starts to ash.
Owner's Manual
5. After the measurement, the monitor displays
the systolic pressure, diastolic pressure and pulse
rate with a long beeper sounds. The reading is
classi ed by color bar which divided according
to WHO classi cation of blood pressure.
If IHB is detected, LCD displays the measurement
with" " icon ashing 8 times to remind users of
irregularheartbeat.
Note
☉ If you press Power button during measurement, the monitor will be turned o .
☉ If the pulse rate symbol is shown as " " instead of " ", this indicates that the monitor
has detected an irregular heart beat.
PROSMEASUREMENT MODE
Always apply the pressure cu before turning on the
monitor.
1.Press CAM button to begin. move the deviceto be
same height as the heart, when the position is correct,
a red bar and a yellow bar ash on the display and device
starts automatically. Otherwise, two red bars ashing
indicates the position is too high while two green bars
ashing means too low. "0" displays on LCD which means
device is under auto zero resetting. LCD shows in
Pros mode; "1" means 1st measurement.
2. Pump starts to in ate and pressure in cu increases to
working pressure.
3. The heart symbol " " will show silently when pulse is
detected during the in ation. When signal of pulse
becomes strong, " " icon starts to ash and a beep
is heard for every heartbeat.
4. After the 1st measuring, cu de ates completely and
device comes into 60 seconds count down.
5. Pump starts to in ate and pressure in cu increases to
working pressure.
6. The heart symbol " " will show silently when pulse is
detected during the in ation. When signal of pulse
becomes strong, " " icon starts to ash and a beep is
heard for every heartbeat.
Note
☉ If the reading meet the condition of |SYS BP1-SYS BP 2| <14 mmHg and |Dia BP1 - Dia BP2|
<9 mmHg as well as pulse rate> 60 for 1st and 2nd measurement, the whole Pros measure-
ment nished after the two measurements and the result shows on LCD.
☉ If the reading does not meet the mentioned condition, it will continue to the third turn
measurement.
7 . After the 2nd measuring, cu de ates completely and
device comes into 60 seconds count down.
8. Pump starts to in ate and pressure in cu increases to
working pressure.
