StarTech.com HB30C1A1CPD Quick Start Manual

Quick-start guide
2-Port USB 3.0 Hub with USB Power Delivery - USB-C to 1x USB-A and 1x USB-C
HB30C1A1CPD
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
Introduction
You can connect the HB30C1A1PD to the USB-C™ port on your
laptop to add a USB-A and USB-C port to your system. The USB-C
port on the hub supports both USB Power Delivery 2.0 and data
transfer. The hub supports data transfer speeds up to 5Gbps.

Product diagram

USB-C plug
About USB 3.0 and USB 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard
offers speeds up to 5Gbps. Any mention of USB 3.0 in this manual or
on the StarTech.com website for HB30C1A1CPD refers to the 5Gbps
USB 3.1 Gen 1 standard.

Package contents

• 1 x USB 3.0 hub
• 1 x quick-start guide
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/HB30C1A1CPD.
USB-C port
USB-A port
*actual product may vary from photos
Requirements
• A laptop with a USB-C port
If your laptop doesn't support USB Power Delivery 2.0, you can't use
the hub to pass power through to your laptop.
USB Power Delivery 2.0 requirements
• A laptop with a USB-C port that supports Power Delivery 2.0
• A USB-C power adapter
• An AC electrical outlet
Not all USB-C ports support the full functionality of the USB Type-C™
standard. To use the hub to power and charge your laptop, make
sure that the USB-C port on your laptop supports USB Power
Delivery 2.0.
Requirements are subject to change. For the latest requirements,
please visit www.StarTech.com/HB30C1A1CPD.
USB Power Delivery 2.0
USB Power Delivery 2.0 is a specification that allows power (up to
100 watts) to be sent over a USB-C or Thunderbolt™ 3 cable that
supports the specification.
The HB30C1A1CPD supports USB Power Delivery 2.0 and will deliver
up to 60 watts of power through the USB-C or Thunderbolt 3 port on
your laptop.
About USB-C
The USB-C port on the hub supports USB Power Delivery 2.0 and can
also be used for data throughput.
Thunderbolt 3 also uses the USB-C connector, so you can connect
the adapter to a Thunderbolt 3 port. When you connect the adapter
to a Thunderbolt 3 port, you can achieve USB speeds of 5Gbps.
Connect the hub
1. Connect the USB-C plug on the hub to a USB-C port on your
laptop.
2. Connect a USB peripheral (for example, a flash drive) to the USB-A
port on the hub.
3. Do one of the following:
• To use power delivery, connect a USB-C power adapter to the
USB-C port on the hub.
• Connect a USB peripheral to the USB-C port on the hub.
The HB30C1A1CPD is natively supported and when you connect it to
your laptop, your laptop automatically detects the hub and installs
the required drivers.
Manual Revision: 06/28/2017
