Abtus AVS-313 User Manual

SPECIFICATIONS
INPUT 3 x PC Input (*D-Sub 15pin)
3 x PC-Audio (*3.5mm)
1 x C-Video (*RCA)
1 x Stereo Audio (*RCA)
1 x Stereo Audio (*2.54mm connector, feedback from projector)
1 x Microphone (*3.5mm)
1 x Microphone (*6.3mm)
OUTPUT 2 x VGA Output (*standard 2.54mm connector for Projector)
1 x VGA output (*D-Sub 15pin for monitor)
2 x C-Video (*standard 2.54mm connector)
1 x Main Stereo Audio (*standard 2.54mm connector)
2 x Tx (*standard 2.54mm connector)
VGA BANDWIDTH 3-in 3-out VGA Matrix Switcher Distribution Amplifier
(900MHz R+G+B)
MAX. RESOLUTION 1280 x 1024
ALL CABLE LENGTH Up to 28 meter
CONFIGURABLE COM PORT 1:2 x RS-232 (8 Data Bit and 1 Stop Bit)
Baud Rate (1200 to 115200)
Parity Bit (Non, Even or Odd)
Programmable projector protocol
DELAY TIME Projector “ON/OFF” delay time (*in sec) 1 to 99
CONTROL BUTTON Number of user defined “Control Button” x 8
Available protocol for each “Control Button” x 2
LED With LED for indication and confirmation
VIDEO SELECTION All Video / VGA Switching
AUDIO SELECTION Audio Switching
VOLUME Main Volume Control
MIC. GAIN Microphone Input Gain Control
POWER ADAPTOR 12V-DC
MECHANICAL
HOUSING ABS enclosure
DIMENSIONS (L x W x H) 149 x 88 x 48 mm (Standard UK two gang casing)
WEIGHT 350g
PACKAGE INCLUDE
1 x Controller unit
1 x 12 V DC Power adaptor
1 x User Manual
** For detail, updated Command Code and Application Software, please visit and download from www.abtussingapore.com
Programmable Integrated Projector Controller Switcher
Digital
Digital
Analog
Analog
ABtUS SINGAPORE PTE LTD
Multimedia
Controller Switcher
Model: AVS-313
www.abtussingapore.com
