Abtus AVS-1200C/V2 Owner's Manual

SPECIFICATIONS
PROGRAMMABLE 2 x configurable com ports provide control of Projector/Plasma/
MULTI MEDIA CONTROLLER AV Switcher via RS-232 commands
CONFIGURING COM PORT 1 x configuring com port provides programming of controller
and acts as a slave when configured with another Master
controller or PC AP control
IR LEARNING 1 x programmable IR control (IRMCs) enables customized IR
control of projector when RS-232 control is not available
PROGRAMMABLE BUTTONS A total of 11 programmable buttons that can be configured with
RS-232 and/or IR control plus digital Volume control for Volume
Up, Down and Mute control
CUSTOMIZED BUTTON Input selection/control buttons can be customized with clearly
LABEL / TEXT labeled text/icon with cool backlit for visibility control even in
total darkness
LCD DISPLAY Clear indication of status and function of the controller through
a small LCD panel
CLOCK Built-in Clock function
AUTO SHUT-DOWN TIMER A programmable timer that allows automatic shut down of the
system i.e. projector to preserve energy and prolong the
projector lamp life
MACRO CONTROL Allows customized macro control, which makes control easier
for end users with just one touch of a button
VOLUME CONTROL Allows control of volume of media switcher and/or projector
PANEL LOCK Programmable “panel lock” functions that tie in with “Auto
Shut down timer” that prevent any mis-use of the panel after
normal class timing and “reset” based on pre-programmed time
* Specifications are subject to changes without notice.
Multi Media
Controller
Model: AVS-1200C/V2
ABtUS SINGAPORE PTE LTD
www.abtussingapore.com
