- Page 1 User’s Gui d e Shop online at omega.com e-mail: info@omega.com For latest product manuals: www.omegamanual.info ZW-REC zwSERIES WIRELESS RECEIVER...
- Page 2 Fax: (203) 359-7700 e-mail: info@omega.com For Other Locations Visit omega.com/worldwide The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
-
Page 3: Table Of Contents
1.2 E ......................3 NVIRONMENTAL AND PERATING ONDITIONS 1.3 B ..............................4 EFORE EGINING 1.4 I ZW-REC ..........................4 NCLUDED WITH THE 1.5 D ................................. 5 ESCRIPTION 2 HARDWARE ............................... 6 2.1 ZW-REC D ............................... 6 IAGRAM 2.2 DIP S ............................... -
Page 4: List Of Figures And Tables
TATEMENT LIST OF FIGURES AND TABLES Figure 1. Included Items ..........................4 Figure 2. ZW-REC Parts Diagram ....................... 6 Figure 3. DIP Switch Detail ........................7 Table 1. Network ID DIP Switches ......................7 Figure 4. Reset Button ..........................8 Figure 5. -
Page 5: Notes, Cautions & Warnings
Failure to follow all instructions and warnings may result in injury. 1.2 Environmental and Operating Conditions The ZW-REC is designed to be fixed mounted and operated in a clean and dry environment. Care should be taken to prevent the components of the device from being exposed to moisture, toxic chemicals, extreme cold or hot temperature that are outside the specification listed in this manual. -
Page 6: Before Begining
If you need assistance, please contact the Customer Service Department nearest you. Obtaining User Manuals and Software A quick start guide is included with the ZW-REC. The latest user manual, firmware upgrades and free software, such as Omega Dashboard, are available at the website listed on the cover page of this manual. -
Page 7: Description
ZW-REC receiver. Each ZW-REC receiver can support up to 128 End Devices and up to 8 receivers can be setup in one area allowing for networks of up to 1024 total End Devices. The Omega Dashboard web server software can monitor and log data from one or more receivers from a single webpage. -
Page 8: Hardware
HARDWARE 2.1 ZW-REC Diagram Figure 2. ZW-REC Parts Diagram Item Description Item Description Antenna Connector Mounting Bracket Holes Power LED Serial Number USB Connector Network ID DIP Switches Network / Diagnostic LEDs Network ID Label Power Connector MAC Address Label... -
Page 9: Dip Switches
NID. Make sure the same NID is selected on the ZW-REC and the End Devices. Only switches 5 to 8 are used. Do not use switches 1 to 4. zSeries End devices only support NIDs 0 to 7. UW Series End Devices require a 5 digit NID referred to as a PAN ID for configuration. -
Page 10: Reset Button
Switch 2 is used to reset the ZW-REC to factory defaults. This is useful if the IP address or password to the ZW-REC is lost. To set the Receiver to factory default settings perform the following steps: •... -
Page 11: Dimensions And Mounting
2.4 Dimensions and Mounting The ZW-REC includes all required hardware for mounting. To mount the ZW-REC position unit where required. Mark the location of the top center of the unit. Refer to Figure 5 to mark and drill the two screw holes as indicated. Use the included drywall anchors if needed and mount the bracket so that the bracket clips are facing up. -
Page 12: Initial Setup
End Devices ship with a default NID of 0. If this installation requires multiple Receivers, ensure that each Receiver has a unique NID. Record the NID on the Net. Addr. label on the back of the ZW-REC for easy reference in the future. -
Page 13: Default Passwords
3.4 Default Passwords A password is required to view the ZW-REC web page. Enter the Client information in the dialog box when prompted. The default usernames and passwords are shown in Table 2. Table 2. Default Passwords User Account Login Name... -
Page 14: End Device Readings And Configuration
End Devices now. Confirm that all End Devices are set to the same Network ID as the desired ZW-REC. Also ensure each End Device has a different Device ID selected. If an End Device is running, it needs to be reset after changes to the Device ID or Network ID. -
Page 15: Changing End Device Settings
from the End Device. The Sequence Number resets to 0 after it reaches 255. The Last Update field shows the last time a new measurement was updated on the webpage. The webpage update rate is set at the bottom of the page. This changes how often the webpage checks for readings but does not change how often End Devices transmit new readings. -
Page 16: Special Functions
The Reset End Device button resets the End Device if it is currently connected to the network. The End Device will reset itself the next time it sends a reading to the ZW-REC and re-join the network automatically. Identify Mode not available for UW Series End Devices... -
Page 17: End Device Status
4.3 End Device Status The End Device Status page provides a quick overview of all current connected End Devices and their status. The page functions similarly to the End Device Readings page. Use the Previous and Next buttons to navigate between pages of End Devices. End Devices can be selected and filtered in the same way as the reading page. -
Page 18: Chart Page
4.4 Chart Page The Chart page gives a graphical view of the sensor data. Figure 10 shows the chart interface. The Chart is highly customizable based on your needs. Any combination of End Devices can be charted and two measurement types can be displayed at once. Figure 10. -
Page 19: Figure 11. Chart Toolbar
Setting up the Chart The first time the chart is loaded it is blank. To start graphing, first use the toolbar in the upper left of the chart to select which end devices to view. Next select which sensor type to view. -
Page 20: System Page
Omega Dashboard Software. System Page The ZW-REC System page is used to setup the Radio and Network parameters for the device and to upgrade firmware. The administrator login is required for this page. Changes to these settings could cause loss of connectivity to the webpages or the connected End Devices. Care is advised when making any changes. -
Page 21: Network Setup
Host Name, DHPS and DNS Server The default host name for the ZW-REC is zwrec**** where **** are the last 4 digits of the MAC Address. See Figure 2 for the location of the MAC address. The ZW-REC can be accessed using its host name instead of its IP address. To use this feature DHCP must be with a Domain Name Server (DNS). -
Page 22: Client Connection
The Client Connection options configure how TCP connections are handled. Client connections allow external software to read data from the ZW-REC using the ZW-REC Serial Protocol detailed in the ZW- REC Serial Programming Guide. The default options work with the Omega Dashboard. If different software is used these setting may need to be changed. -
Page 23: Radio
5.4 Radio When the ZW-REC starts up it performs an energy scan to find a clear RF channel. This RF channel is displayed in the Radio Section. Due to network planning this channel may need to be changed. Select the desired channel here. If the RF Channel is changed all connected End Devices need to be reset. To prevent the ZW-REC from re-scanning when it is rebooted uncheck the Enable Energy Scan box. -
Page 24: Security Page
Figure 19. Change Password Dialog submit changes. By default, any password up to 16 characters long is allowed by the ZW-REC. If additional security is required check the require Strong Password box to enable the Strong Password Policy. Strong Password Requirements •... -
Page 25: Encryption
ZW-REC using https:// followed by the ZW-REC IP address or hostname. When encryption is enabled the ZW-REC is configured with a default SSL certificate that is not issued by a Certificate Authority (CA). Most web browsers provide a warning page when connecting to the ZW-REC indicating the SSL certificate is not issues by a trusted certificate authority. -
Page 26: Specifications
SPECIFICATIONS Wireless Communications Standard IEEE 802.15.4, DSSS Frequency 2.4GHz Transmit Power 9.5dBm Receiver Sensitivity -96dBm Range Up to 1000m (3280’) Compatible Transmitters zwSeries Up to 128 Devices zSeries Up to 32 Devices UWTC, UWRTD, UWRH, UWIR Up to 48 Devices Operating Conditions Input Voltage to 30V... - Page 27 Approval Information The product herewith complies with the essential requirements and other relevant provisions of the directives listed below and carries the CE-marking accordingly. The following CE Mark is affixed to this equipment. The CE declaration is available at the website listed on the cover page of this manual. EMC Directive 2014/30/EU Low Voltage Directive...
-
Page 28: Appendix A Certificate Configuration
Upload a Certificate Once you have obtained a certificate, you can upload it to ZW-REC. The certificate contains two parts; the Certificate and the Private Key. Click on the Choose File button next to the Certificate and Private Key fields shown in Figure 21. Use the file browser to find the corresponding file. -
Page 29: Appendix B Firmware Updates
It is recommended that any firmware upgrade is initiated on the same local area network as the ZW-REC using a wired Ethernet connection. This will reduce the risk of dropped packets or network traffic interfering with the upgrade. -
Page 30: Upgrading Version 2.0 And Above
Update Success screen in Figure 24 is shown. Step 5: Connect to the ZW-REC again using the IP Address recorded in Step 1. Follow the instruction in Section B.2 Step 3 to upload coordinator.b64. Step 6: Connect to the ZW-REC again using the IP Address recorded in Step 1. -
Page 31: Figure 25. Firmware Upgrade Dialog
Wait for the update success screen shown in Figure 27. Figure 27. Upload Success Page Once the firmware is loaded the ZW-REC restarts and is ready to use. User settings including, IP Address, Encryption, User Name and Password are preserved during the update so no additional setup is required. -
Page 32: Updating Zwseries End Devices
Step 3: The Upload File button will now be usable. Click the button to upload the firmware to the ZW-REC. The ZW-REC will then update each selected End Device the next time it checks in. The update process may take several minutes for each End Device and the ZW-REC will finish updating one End Device before starting on the next. -
Page 33: Appendix C Rf Topics
The ZW-REC transmits at a power of +9.5dBm. Certain End Devices are lower power than the ZW-REC so the received signal strength is higher at the End Device than it is at the ZW-REC. For these End Devices the Signal Strength indicator needs to be higher for reliable communications. -
Page 34: C.3 M Aximizing R Ange
The antenna provided with the ZW-REC is a dipole. Care must be taken in the positioning of the antenna to achieve the best possible range. The gain of the antenna is lower along the axis of the antenna. -
Page 35: Appendix D Wireless Certifications
APPENDIX D Wireless Certifications D.1 Federal Communication Commission Interference Statement Part 15C, Class DTS Intentional radiator Contains TX FCC ID: TYOJN5168M5 Caution: In order to comply with FCC radio frequencies (RF) exposure limits, dipole antennas should be located at a minimum 7.9" (200mm) or more from the body of all persons. -
Page 36: D.1 I Ndustry C Anada S Tatement
D.1 Industry Canada Statement Contains Industry Canada ID IC: 7438A-CYO5168M5 This device complies with Industry Canada Le présent appareil est conforme aux CNR license-exempt RSS standard(s). Operation is d'Industrie Canada applicables aux appareils radio subject to the following two conditions: (1) this exempts de licence. - Page 37 Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification.
-
