VM Audio VMHS511 Quick Installation Manual

5.1 speaker system

Advertisement

Quick Links

Setup
(option 2)
Use the supplied cables to connect to audio source (refer to
Setup Section).
• Turn on the Speaker System.
DVD AUDIO OUTPUT
• Set the Volume for each Speaker to the zero position to start.
FL
FR
SW
SR
SL
CEN
AUX AUDIO INPUT
• Turn on Audio Source and launch media.
L
R
• Select USB / SD / AUX /DVD Iput Source from Remote
FL
FR
DVD / Surround
Control or Subwoofer Front Panel.
CEN
SW
Processor
SL
SR
• Adjust each Speaker Volume as needed.
DVD AUDIO INPUT
POWER SWITCH
CEN
ON
FL
FR
˜
AC IN
EXCLUSIVE FEATURES
SL
SR
USB and SD Card
OFF
AUDIO OUTPUT
The VMHS511 will accept USB or SD data drives that contain
MP3 music files. Music playback order can be adjusted from the
Remote Control.
Pro-Logic Surround
1. Use the Stereo RCA Cables (included) to plug into
The VMHS511 is equipped with a Pro-Logic surround mode that
your DVD or Surround Processor Outputs.
provides 4.1 channels of sound with conventional Left and Right
Stereo Sources.
2. Plug the other end of the cable into the Input Section
of the Subwoofer.
• Select PRO mode for Movie Surround Soundtrack
• Disble PRO mode for Music or Game 2-Channel Sound.
| 7
5. Operation
6. Troubleshooting
System is not powering on?
• Switch Power Button on and verify if the LED Indicator is
Illuminated.
• Confirm that the AC plug is plugged in and that there is power
to that outlet.
Speaker(s) does not produce sound?
• Verify the system is getting power and check above steps.
• Make sure the volume is turned up to an audible listening level
and/or your PC is not in a mute status.
• Verify that all cables are plugged into the correct jacks.
• Try connecting your system to another audio source or device.
If the system works correctly with the other device, then your
first device is most likely the cause of the problem.
Sound is distorted or is not clear?
• Low quality compressed music files will increase the distortion
and noise that are easily noticed with amplified speakers.
Recheck sound quality with a non-compressed music file.
• Check the audio source level and decrease if necessary. You
should never have your source volume above 90% volume level
to minimize distortion.
| 8
Caution & Warning
CAUTION
RISK OF ELECTIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
• Avoid high temperatures. Allow for sufficient heat dispersion
when installed in a rack.
• Keep the bass module free from moisture, water, and dust.
• Do not let foreign objects into the port opening of the subwoofer.
• Handle the power cord carefully. Hold the plug when unplugging
the cord.
• Unplug the power cord when not using the unit for long period
of time.
• Do not let flammable sprays come in contact with the unit.
• Never disassemble or modify the unit in any way.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE
| 9
| 10
5.1 Speaker System
VMHS511
Quick Installation
VM Audio Tech Support
US / Canada
phone: (855) audio-99 / (855) 283-4699
email: help@vmaudio.com
© VM Audio All rights reserved. All trade names are registered trademarks of
respective manufacturers listed.
5.1 Speaker System
VMHS511
Guide
Rev. 1
