ClearCube CD7800 Series Quick Start Manual

Package Contents

• CD7800-series or CD9800-series Cloud Desktop
• Cable adapter for dual-link DVI
• Power adapter and cable
• This Quick Start Guide
USB Ports
HD HD
Audio In Audio Out
MAC Address DVI #2 (DVI-I)
and Serial Number
USB Ports
SFP or RJ45
Connector
DVI #1 (DVI-D)
ClearCube Technology, Inc.
Quick Start Guide
CD7800 and CD9800 Series
Front
Kensington®
Security Slot
Client Power & PCoIP Session
Indicator Indicator
Rear
Power Jack
HD Audio Out
3700 W Parmer Lane
Cloud Desktop Overview
(Note: the terms Cloud Desktop and zero client are used
interchangeably in this document.) ClearCube
CD9800 Series zero clients connect to supported ClearCube
PC blades containing Tera1 or Tera2 host cards and virtual
machines to provide:
• Seven USB ports
• Small form-factor pluggable (SFP) connector accepting
various Ethernet modules or RJ45 connector
• Support for fiber media (100FX and 1000SX) and for
copper media
• Support for up to two independently-configurable monitors
– 2 DVI monitors up to 1920 × 1200
– 1 DVI monitor up to 2560 × 1600 (requires included
DVI-to-dual-link-DVI adapter)
• PC–over–IP™ (PCoIP™) Tera2 processors, delivering
PC video, audio, and USB over an IP network
• HD audio in and out (front) and HD 4.0 audio out (rear)
ClearCube PC blades are typically located in remote data
centers. Blade users connect to a remote blade or VM over
an IP network (of fiber and Ethernet segments) using a
Cloud Desktop. Users connect monitors, a mouse, and other
peripherals to their zero client, enabling them to work on the
blade or VM as if it is a local PC. The connection between
the zero client and the remote device is over PCoIP
protocol. Inside the blade, a Tera1 or Tera2 Dual Host card
manages the PCoIP session.
* Fiber or Copper
Cloud Desktop with Monitors
and Peripherals
* Media can vary depending on model and SFP module connected to
zero client.
Cloud Desktop connected to blade or to VM
Austin, Texas 78727 (512) 652-3500
®
CD7800 and
Network Infrastructure
Fiber or Copper
Chassis with
Blades and VMs
www.clearcube.com
