Avenview DVI-C5-LC-R User Manual

Cat5 dvi-d + audio series

Advertisement

Quick Links

Cat5 DVI-D + Audio Series
User's Guide
© 2008 Avenview™ Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. ("Avenview") products. Avenview makes no representations
or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to
specifications and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual
property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes
no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied
warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.
Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly
prohibited.
Disclaimer
While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the
operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of
Avenview concerning such products or this documentation, for any interruption of service, loss or interruption of business, loss of
anticipatory profits, or for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of the
Avenview hardware, software, or other products and documentation provided herein.
Avenview Inc. reserves the right to make changes without further notice to a product or system described herein to improve reliability,
function or design. With respect to Avenview products which this document relates, Avenview disclaims all express or implied warranties
regarding such products, including but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and
non-infringement.
1
www.avenview.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVI-C5-LC-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Avenview DVI-C5-LC-R

  • Page 1 No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.
  • Page 2: Table Of Contents

    DVI-C5-8 8 Port DVI-D + Audio Transmitter ..................5 Cable and Accessories ..........................5 Installation and Operation ........................6 DVI-C5-LC-R Transmitter Installation ....................6 Selection of Cable ..........................6 Multi-Port DVI-C5-2/4/8 Transmitter Installation ................8 Monitor and Speaker Connection through RJ45 and RJ11 Ports ............9 Installation of Multiple Transmitters ...................
  • Page 3: Getting Started

     DVI Output: Transmitting over standard DVI cable at 1920x1200 up to 10 meters (30 feet)  RJ45 Output and using longer range Receiver DVI-C5-LC-R: 800x600 @ 100 meters (330 feet) 1024x768 @ 70 meters (230 feet) 1280x1024 @ 60 meters (200 feet) 1920x1200 @ 35 meters (115 feet) ...
  • Page 4: Panel Description

    Panel Description DVI-C5-2 2 Port DVI-D + Audio Splitter / Extender DVI-C5-4 4 Port DVI-D + Audio Splitter / Extender www.avenview.com...
  • Page 5: Dvi-C5-8 8 Port Dvi-D + Audio Transmitter

    DVI-C5-8 8 Port DVI-D + Audio Transmitter Cable and Accessories DVI Integrated AV Cable 1.8m www.avenview.com...
  • Page 6: Installation And Operation

    Installation and Operation DVI-C5-LC-R Installation a. Device Connection: Plug power adapter to DVI-C5-LC-R, the orange LED above RJ45 should turn ON to indicate the power on status. The other LED should turn off, since there is no input of video signal from “ SYSTEM LINK” port.
  • Page 7 Termination: The RJ45 terminations to the Cat 5/5e/6 cable must be made to the EIA 568B specifications. Orange White Orange Green White Blue Blue White Green Brown White Brown The EIA/TIA definition of 568B in the pin assignment PAIR 3 PAIR 2 PAIR 1 PAIR 4 JACK POSITION www.avenview.com...
  • Page 8: Multi-Port Dvi-C5-2/4/8 Transmitter Installation

    Connect the Cable: Plug one end of the cable to DVI-C5-LC-R Receiver’s RJ45 “SYSTEM LINK” port. The Receivers connected monitor should display now and the green LED above DVI-C5-LC-R’s RJ45 port should turn ON to reflect the DVI signal activation. For DVI-C5-LC-R, you can manually adjust the EQ/FOCUS to have the best DVI display.
  • Page 9: Monitor And Speaker Connection Through Rj45 And Rj11 Ports

    Refer to previous section for Receiver to install and prepare the cable to be connected. b. RJ45 VIDEO with DVI-C5-LC-R: If the video connection is HDMI type, then you will need to use appropriate DVI-HDMI adapter to connect. The supported DVI-D resolution and distance is similar to regular DVI cable.
  • Page 10: Installation Of Multiple Transmitters

    From “VIDEO / AUDIO OUT”: Use one set of standard DVI/Audio cable. Connect one end from “VIDEO / AUDIO OUT” of first layers Transmitter and the other end to “DVI / AUDIO IN” port of the second layer’s Transmitter (as shown below). Installation Diagram of Multiple DVI Transmitters www.avenview.com...
  • Page 11: Specifications

    Specifications DVI Transmitter and Splitter / Extender Model DVI-C5-LC-R DVI-C5-2 DVI-C5-4 DVI-C5-8 1 Port DVI-D 2 Port DVI-D 4 Port DVI-D 8 Port DVI-D Description Transmitter Splitter Extender Splitter Extender Splitter Extender DVI Female x 1 Input DVI Male x 1...
  • Page 12 www.avenview.com...

This manual is also suitable for:

Dvi-c5-2Dvi-c5-8Dvi-c5-4
