RecorderGear FD10 Instruction Manual

FD10 INSTRUCTION MANUAL

USING THE FD10 VOICE RECORDER

- Begin Recording - Push the switch into the "ON" position. A red
light will flash then stop after 5 seconds, indicating that recording
has started.
- Stop Recording – Push the switch into the "OFF" position. A red
light will flash again then stop after 5 seconds, indicating that
recording has stopped.
- To Transfer Files – Verify that the switch is in the "OFF" position.
Insert the FD10 into your computer's USB port. Files can then be
accessed for transfer, or deletion from the recorder.

ADDITIONAL DETAILS

- Red light will remain on while the FD10 is charging, and will turn
off when charging is completed.
- Device will not record while connected to computer
Should the battery be depleted before you complete a recording,
the recording will automatically save the current file.
- If memory is full before you complete a recording, the recording
will automatically save the current file.

TECHNICAL SPECIFICATIONS

Recording time: 15-30 hours on full charge
Memory Capacity: 100 hours (8GB), 200 hours (16GB)
Charging Time: 2-3 hours
Battery: Built-in 110MAH Rechargeable LItihium
Size: 64x21x7mm
Sampling rates: 48KHZ
Bit Rate: 192KBPS
USB 2.0
WAV Audio File Format
Weight: 16g, .56oz
