Page 1: User Manual
HD 1080P New Pro Black Box Security Wi-Fi Camera with Rotatable Lens User Manual Version:April, 2017... -
Page 2: Table Of Contents
Contents Quick Guide.............P3 Overview............P4 Packing List.............P4 Product Instruction .........P5 Camera Part Setting........P6 Camera name and password setting....P10 APP Introduction..........P11 PC Setting(LAN)..........P13 PC Setting(WAN)..........P15 Speci cation...........P16 FAQ..............P16... - Page 3 180°Horizontal rotation Invisible rotatable Lens by App...
- Page 4 120mm...
-
Page 5: Quick Guide
Quick guide of Wi-Fi camera function 1.Download Free App Pro iCam from App Store or Google Play. 2. Plug in power —> Turn on devices’ right side ON/OFF button, wait for 2 mintues (Back blue light blink slowly); 3. Enter smartphone setting —> Search and connect device’s wi named: YM……,wait till phone status bar appear Wi-Fi symbol;... -
Page 6: Overview
Overview The HD 1080P New Pro Black Box Security Wi-Fi Camera, equipped with a Invisible 180 degree Rotatable Lens and built-in 5000mA rechargeable Li-battery, and have insisted the super simple design plus a smart & powerful 1080P Wi-Fi hidden camera. First, it is a simple designed black box;... -
Page 7: Product Instruction
Product instruction ON/OFF Micro SD card slot USB port Power indicator light Reset key ON/OFF (For Wi-Fi Camera) Camera Wi-Fi indicator light... - Page 8 Getting started of Wi-Fi camera part Step1: Download and install APP Scan below QR code or search and download free APP named “Pro iCam” in Apple APP store, Google play or Electronic market, and install it. [ Pro iCam ] APP QR code...
- Page 9 Step 2: Turn on device and connect power Open right side cover, turn on ON/OFF button,close the cover and plug it into AC power using the included adapter, wait for 2 minutes (Back blue light blink slowly); Step 3:Connect Wi-Fi 1.
- Page 10 2. Open APP, press symbol + at the top right corner, select “Add new online camera”； Search for new camera and press OK. Then back to the rst page to check the live video of camera and do the following setting.
- Page 11 3. Press the gear icon after the camera or long press the camera and select Device Settings, select Wi-Fi Con g. 4. Select local router Wi-Fi and input passcode, camera will be connected to router Wi-Fi. The smartphone will disconnect with device and connect to the router Wi-Fi.
- Page 12 Set camera name and private code Set name:Press the after the camera or long press the camera,select Modify device, select Name and revise name like Of ce, Room…... Set code: Long press the camera and select Device Settings,select Change password. Current one is 8888.
-
Page 13: App Introduction
APP introduction Camera name Camera setting key Camera UID Camera online user number Snapshot: Review snapshot pictures Record: Review recorded videos Alarm: Review alarmed pictures Live video page - Click camera to check Brightness Night vision switch Backside LED Switch Resolution Contrast ZOOM... - Page 14 Alarm Con g: Set motion detection sensitivity / Alarm interval Wi-Fi Con g: Set camera to other Wi-Fi SD Card Record Con g: Set SD card record mode / Resolution /File length … Set time Set motion alarm with email (Need turn on email alert rst in alarm con g) Change password: Set camera new password...
- Page 15 Set and watch by PC in LAN 1. Once camera connected well with Wi-Fi, install software “IPCamera”from included CD and open software to nd the connected device’s IP address. 2. Double click the IP address, insert name“admin” (no password) and press OK.
- Page 16 3. After above steps, please insert setting interface. For rst use, please choose langauge, then click download and install plug-in.
- Page 17 4. Click to go to the nal setting interface. 5. Click left options to set other needed functions. 6. Click left side System --> About, to check wi camera’s rmware version. Set and watch by PC remotely (WAN) Please check details in included CD for instructions and software...
-
Page 18: Faq
Specification Resolution 1 Mega CMOS Video pixel in phone Max 1920*1080 Video pixel in TF card 1080*720 Frames Max 25fps Compressed format H.264 View angle 90° Type of memory card TF card>=Class 4/10 and HC marked Maximum capacity of memory card 128GB PC operation system Windows 7, 8 / Mac OS X Play software... - Page 19 2. Q: Can’t get device Wi-Fi signal? (Five solutions FYI). A: 1). Please con rm the power adaptor connected; 2). Press reset key for 5 seconds and wait 2 mins; 3). Turn off camera backside, then turn on again; 4). Turn off smartphone Wi-Fi for a while, then turn on to search again.
- Page 20 7. Q: How many visitors support to check live video? A: 1-2 8. Q: Only 1 user, but show 2 or more users? A: 1). If login in very often, last record is still in. Please check every 2-5 mins； 2).
- Page 21 12. Q: After connected to Wi-Fi, how is the status of camera when Wi-Fi off? A: 1). If modem off and router on, camera can still check locally，as it is in local area network（LAN）; 2). If modem off and router off,camera will keep searching for the connected Wi-Fi and connect again once on.
- Page 22 b, Input below format to the le wi :xxxxxx (Your local wi name) pwd:xxxxxx (Both are case-sensitive) c, Insert the micro SD card when camera is OFF d, Turn on camera, it will connect with your wi in 10-15 seconds. TIPS Can also copy the txt le from camera's CD to the micro SD card,change wi name and password.
- Page 23 18. Q: How is the indicator lights work? A: Red light indicate charging,blue light indicate Wi-Fi working status. 19. Q: The blue Wi-Fi indicator light is not hidden? A: Refer to P11,to turn on/off the light as like on APP. The End!
