Note: When Refrigerated Cooling is installed, the zone
sensor IDs are forced to match those used for Heating. For
example if Heating Zone B sensor ID was set to "n02", then
Refrigerated Cooling Zone B sensor ID would also be set to
"n02".

6.3 Installer Parameters

Accessing
• Press Key "5" on the proposed Slave NC-6 and the screen
will display the message "Clock setting mode". Ensure that
the word "Clock" is flashing on the display before
proceeding
• Press and hold Keys "2" & "4" simultaneously, until the
screen displays the message
access"
• All setup parameters, once entered, are automatically
saved
Heater Installer Parameters
• Set and record heater installer parameters ("H01 ID01" –
"H01 ID08") as per Table 7 in the Appendix.
• Press "M" (Mode) to access Master Controller Parameters
(Table 8, p.22)
• Press On/Off to exit
"Installer parameter
14

6.4 Setting NC-6 Master Controller Parameters

Important Note:
The Installer Parameter value ("
(p. 14) to enable specific zoning options before proceeding.
Table 8 (p.22) details all Installer Parameters that may be
made available for setting up the ZonePlus system.
All other parameter values must be set in ascending
sequential order, with the exception of parameter "n01
ID92" (for Multi Temperature Set Point Systems, which
MUST BE SET PRIOR to setting all other NC-6 parameters).
Set and record all Master Controller Parameters in Table 8
in the Appendix.

6.4.1 Single or Multi Temperature Set Point

The default ZonePlus
Temperature Set Point. To activate Multi Temperature Set
Point, parameter "n01 ID92" must be changed from the factory
default setting of "0" to "1".
must be set in 6.3
H01 ID07 :#")
configuration setting is Single
