Hardware Specification - HoIP Telecom Pebbell User Manual

Command: version
The device will reply" IMEI: xxxx; GSM CSQ:xxxx; Soft:V07.20.10.1345"
26. Change IP and Port:
Command: IP1,IP,port
Example: IP1,103.21.211.11,5050
27. Reboot Device:
Command: reboot
The device will restart itself without changing any settings.
28. Initialization:
Command: RESET!
Note: This is to make all settings back to the factory default.
29. Built-in Memory
The device built in 8MB flash memory inside. It will store the GPS information when do not have GSM
network coverage (i.e., very low population density areas, some mountainous terrain, underground
areas etc). The device will transmit GPS locations to the WEB server automatically once the GSM
network is recovered.
Cautions:
Please comply with the instructions to extend the unit life:
1. Keep the unit dry. Any liquid may destroy or damage the inside circuitry.
2. Don't use & store the unit in dusty places.
3. Don't put the unit in overheated or overcooled places.
4. Clear the unit with a piece of dry cloth. Don't clean in chemicals, detergent.
5. Don't disassemble or refit the unit.
6. Using other batteries will cause unwanted situation

Hardware Specification:

Content
Mainframe Dimension
Weight
GSM Frequencies
GPS chip
GPS sensitivity
GPS accuracy
Time to First Fix
Charging Voltage
Battery
Standby Current
HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015
61mm*44mm*16mm
900/1800mhz or 850/1900Mhz
U-blox 7 (Support AGPS)
Cold start: -148dBm Hot start: -162dBm
Cold start 32s, Warm start 11s, Hot start 1s
Chargeable 3.7V 900mAh
- 12 -
Specs.
35g
<2.5m
5V DC
≤2mAh
