HoIP Telecom PET PEBBELL User Manual

Gps pet tracking system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
STARTING PET PEBBELL™
Publication number PP2015-01
All rights reserved. © HoIP Telecom, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PET PEBBELL and is the answer not in the manual?

Questions and answers

Related Manuals for HoIP Telecom PET PEBBELL

Summary of Contents for HoIP Telecom PET PEBBELL

  • Page 1 STARTING PET PEBBELL™ Publication number PP2015-01 All rights reserved. © HoIP Telecom, 2015...
  • Page 2 STARTING PET PEBBELL...
  • Page 3 You can request position, set tracking and area tracking of the pet(s), and view your pet(s) position on map. PET PEBBELL can be used with any Smartphones and you do not need to install any applications.
  • Page 4  HoIP Telecom warrants its products to be free of defects in material or workmanship when leaving the factory. For details, see the warranty terms at end of this User Manual ...
  • Page 5 Never try to disassemble or service the product. Only qualified personnel may repair the product.  Use only approved accessories and batteries. Do not connect incompatible battery charger or charge other devices with the Pebbell GPS charger. A wrong charger may damage the device. -We wish you enjoyable moments with Pet Pebbell-...

  • Page 6: Package Contents

    STARTING PET PEBBELL PACKAGE CONTENTS 1 User Manual 1 GPS Device 1 USP Charging Cable 1 AC Adapter...

  • Page 7: Getting To Know Your Device

    STARTING PET PEBBELL GETTING TO KNOW YOUR DEVICE...

  • Page 8: Getting Started

    STARTING PET PEBBELL GETTING STARTED The Pet Pebbell device is equipped with an internal rechargeable battery. The autonomy of the battery may vary depending on the GPS and GSM activity and the use of the device.  When charging for the first time use, please fully charge the battery for around 5~6 hours, using the USB charger.

  • Page 9: What Do The Lights Mean

    STARTING PET PEBBELL Switching the device OFF  To turn off the device: Send SMS: >> to the device, after you hear the beep, the device is turned off. WHAT DO THE LIGHTS MEAN? LED—GREEN Light shows a single flash rapidly every 3 seconds...

  • Page 10: Low Battery Alarm

    STARTING PET PEBBELL LOW BATTERY ALARM When the unit’s battery is less than 15%, it will send an SMS alarm “BAT: LOW!” to all authorized numbers. If battery is less than 15%, the blue light will flash rapidly to warn the user to charge the device as soon as possible.
  • Page 11 STARTING PET PEBBELL B1, phone number (Example: B1, +441234567890) ②Command:  The device will reply: Set mobile number 2 OK! To delete this number, you can send C1, phone number (Example: C1, +441234567890) ③Command:  The device will reply: Set mobile number 3 OK! To delete this number, you can send 2.

  • Page 12: Location Request

    STARTING PET PEBBELL 3. User defined name in SMS content name1, user name Command: Example: name1, PET PLUG, the tracker will reply “Add name ok!” name0 To delete name send LOCATION REQUEST 1. Reply with coordinates and web link Command: The device will reply “GPS Info! Time: xxxxx;...
  • Page 13 STARTING PET PEBBELL 2. Reply with Address Command: The device will reply with an address e.g. “Add: Coombe Lane, Awbridge, SO51 0HN Hampshire, Notes: This function needs GPRS function support. GEO-FENCE ALARM Command: G+X, Y, Z, xxxM/KM (Default G0) Example: G1,1,1,100M Notes: No spaces in between.

  • Page 14: Movement Alert

    STARTING PET PEBBELL xxx is the preset distance to the tracker’s original place, must be 3 digitals. M means meters, KM means kilometers The device will send the message to the authorized numbers as “Geo fence alarm!+GPS info” when it enter the area you set. (User must set this function when the device has GPS fixed.)

  • Page 15: Motion Alarm

    STARTING PET PEBBELL LISTEN-IN (Voice wiretapping) Command: A1, B1, C1 can make a silent call to the tracker, the track answers the call automatically and allows the caller to hear what is happening around the tracker. There is no voice indication that the call is in progress.

  • Page 16: Shut Down Led

    STARTING PET PEBBELL SHUT DOWN LED Command: LED1 The device will reply “LED off” and later LEDs will stop flashing, but the device is actually on. To turn off this function, please send LED0 AGPS Command: AGPS1 A-GPS is for accelerated positioning and helping position a device when GPS signals are weak or not available.
  • Page 17 STARTING PET PEBBELL AGPS with known position Command: AGPS1, latitude, longitude Example: AGPS1,48.148899,11.542254 To turn off this function, please send AGPS0 GPS SIGNAL LOST AND RECOVERY ALERT Command: The device will automatically send the latest available GPS information to the preset numbers when it enters into the area without GPS signal.
  • Page 18 STARTING PET PEBBELL CELL LOCATE Command: The device will reply “Cell locate on! To turn off this function, please send The unit can be tracked by GSM base station tower, If GPS signal is not available for example in room or underground, and then user can be located by GSM tower.

  • Page 19: Turn Off Device

    STARTING PET PEBBELL CHECK SETTINGS Command: STATUS device will reply E.g. A+8613812345678 B13912345678 C13712345678; Speed: 0,110km/h; GEO:0,0,0; VB:,0S; MV:0,0; LBS.1,LED:0; TZ:2.0; LI: 0; PS:1; DS:0,3M; FL:0; Bat: 66 To recognize the meaning of “0”& “1” The number “0” implies that the function is turned off; while “1” indicates that the function is turned on.

  • Page 20: Device Power Modes

    STARTING PET PEBBELL DEVICE POWER MODES 1. No Power saving mode Command: In this mode, both GSM and GPS are on, battery can last 18~24 hours. 2. Smart Power saving mode (default mode) Command: In this mode, the GSM chip is working and receives calls, SMS and transmits location.

  • Page 21: Reboot Device

    STARTING PET PEBBELL 3. Deep Sleeping mode Command: Both GSM and GPS chip will shut down to save power, the device is unable to receive calls or SMS. It can be only activated by movement. Once movement is detected, it will run for the set time and sleep again if no movement is detected.

  • Page 22: Hardware Specification

    STARTING PET PEBBELL HARDWARE SPECIFICATION Content Specs. Mainframe Dimension 65 x 35 x 16 mm Weight GSM Frequencies 900/180/850/1900Mhz GPS chip U-blox 7 (Support AGPS) GPS sensitivity Cold start: -148dBm Hot start: -162dBm GPS accuracy <2.5m Time to First Fix...
  • Page 23 Manufacture’s limited warranty HoIP Telecom warrants to the original retail purchaser (“Consumer” or “You”) that this HoIP Telecom PET PEBBELL device and all accessories originally provided by HoIP Telecom in the sales package (“Product”) are free from defects in materials, design and workmanship under normal use in accordance with the operating instructions and pursuant to the following terms and conditions.
  • Page 24 (hereinafter “Warranty Period”). The different Warranty Periods are: 1. Twelve (12) months for HoIP Telecom Pet PEBBELL device and three (3) months for accessories (whether included in the device sales package or sold separately) other than the consumable parts and accessories listed in 2) below;...
  • Page 25 STARTING PET PEBBELL CAUTIONS Please comply with the instructions to extend the unit life: Keep the unit dry. Any liquid may destroy or damage the inside circuitry Don’t use & store the unit in dusty places Don’t put the unit in overheated or overcooled places Clear the unit with a piece of dry cloth.
  • Page 26 STARTING PET PEBBELL Real time tracking on www.smart-tracking.com Our web based tracking system incorporates the TCP/IP protocol and allows users to monitor it in real time over the internet or sends an e-mail to the predefined e-mail address. How to connect device to the platform for real time tracking via GPRS 1.
  • Page 27 STARTING PET PEBBELL Note: - Hardware Version: Please choose EV07 - Type the name and the IMEI number. Please make sure IMEI numbers are correct.

  • Page 28: Gprs Setting

    STARTING PET PEBBELL GPRS SETTING In order to use the GPRS function, the user needs to setup the APN by sending SMS command. APN stands for Access point name (APN) and is the name used to identify a general packet radio service (GPRS) bearer service in the GSM mobile network.

  • Page 29: Disable Gprs

    STARTING PET PEBBELL SET GPRS TIME INTERVAL by SMS (this can be also set from platform) Send the command TIxxS/M/H The setting must be in 2 digitals, the maximum value is 99, which means 01~99. The meaning of “xx”: xxS is the time interval in second with range(30~99) ...
  • Page 30 STARTING PET PEBBELL RECONNECT GPRS Reconnect the website via GPRS for real time tracking, please send the command CHECK APN & IP, Port Send the command The device will reply “APN: internet; Name: xxx; Password: xxxx; Port: 5050; IP:www.smart-tracking.com” CHANGE IP AND PORT...

  • Page 31: Built-In Memory

    STARTING PET PEBBELL INITIALIZATION Send the command RESET! Note: This is to make all settings back to the factory default. BUILT-IN MEMORY The device built in 8MB flash memory inside. It will store the GPS information when do not have GSM network coverage (i.e., very low population density areas, some mountainous terrain,...
  • Page 32 STARTING PET PEBBELL Mobicare Oy Repokalliontie 10 80230 Joensuu Finland Company Number: 2664782-2 Phone. +358 400 577 478, Email; support@mobicare.fi www.mobicare.fi...
