Page 1: User Guide
HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 HoIP Pebbell® SOS Pendant Alarm USER GUIDE Personal/Asset/Pet GPS TRACKING SYSTEM - 1 -... - Page 2 Take the product to the appropriate collecting point for recycling when disposed. 1. Product Overview Thank you for using Pebbell GPS. The new Pebbel GPS tracker is the sweetest and most user-friendly product ever. This device is an innovative miniature size personal remote positioning device with built-in U-blox 7 GPS and GSM/GPRS technology.
- Page 3 2.2 Functional Parts 2.3 SIM card Installation The SIM card is usually preinstalled in Pebbell already if this is not the case not then, lift SIM card cover and insert activated Micro SIM card by the direction of the picture shows.
- Page 4 Make sure that you have charged the device for at least 6 hours. Place the device outside Pebbell GPS device should have unobstructed access to the sky. Turn the power - press and hold the power button for 3 seconds, all LED will flash rapidly. To receive first position may take some minutes...
- Page 5 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 2.5 What does the LED lights mean? LED—GREEN LED Light shows a single flash rapidly every 3 seconds The device is connected to GSM network Light shows a double flash rapidly every 3 seconds...
- Page 6 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 Configuration and Operation by SMS To Set the Authorized Numbers It is not mandatory for all three of the authorized numbers to be set, however a minimum of one must always be set.
- Page 7 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 o To delete name, you can send name0 5. Location request 5.1 Reply with coordinates and web link Command: The device will reply “GPS Info! Time: xxxxx; Lat: xxxx; Lon: xxxx; Spd: xxxxx, Altitude:xxxx Bt: xxx maps.google.com/maps?q=loc:48.148933,11.541970...
- Page 8 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 7. GEO-FENCE Alarm Command: G+X, Y, xxxM/KM Example: G1,1,1,100M Notes: No space in between. X=No. of Geo fence (1~3), user can set 3 Geo fences Y=0 means to turn off the function Y=1 means to turn on the function...
- Page 9 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 11. Listen-in (Voice wiretapping): Command: Only A1, B1, C1 number can make a silence call to the tracker, the track answers the call automatically and allows the caller to listen to what happens around the tracker. There is no voice indication that the call is in progress.
-
Page 10: Low Battery Alarm
HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 16. Check settings: Command: status The device will reply E.g. A+8613812345678 B13912345678 C13712345678; Spd: 0,100km/h; Geo:0,0,0; VB:1,10S; MV:1,100; LBS:1; LED:0; RCV:0; TZ:2.0; Lis-in: 1; PS:1; DS:0; FL:1; Bat: 95 To recognize the meaning of “0”& “1”... - Page 11 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 Pebbell Real time tracking on www.smart-tracking.com Our web based tracking system incorporates the TCP/IP protocol and allows users to monitor it in real time over the internet or sends an e-mail to the predefined e-mail address.
-
Page 12: Hardware Specification
HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 Command: version The device will reply” IMEI: xxxx; GSM CSQ:xxxx; Soft:V07.20.10.1345” 26. Change IP and Port: Command: IP1,IP,port Example: IP1,103.21.211.11,5050 27. Reboot Device: Command: reboot The device will restart itself without changing any settings. - Page 13 HoIP Pebbell SOS Pendant Alarm GPSTracker_V5.0_HoIP_Telecom_01_08_2015 Storage Temperature -40°C to +85°C Operation Temperature -20°C to +80°C Humidity 5%-95% non-condensing - 13 -...
