FIM P Series Installation Manual

P-Series Umbrella Installation Instructions
These instructions are provided to facilitate assembly of the CAPRI umbrella, and for your safety.
Please follow the instructions carefully.
Failure to do so may result in damage to objects or injury to people. If in doubt, always consult an expert.
Keep this handbook for future reference.
IMPORTANT SAFETY INSTRUCTIONS
1. INSTRUCTIONS - Please completely read and follow all the instructions. Damage or injuries may
result if the umbrella is not assembled and used as described
herein. For safe use it is essential that anyone using the umbrella should have read all the
instructions in advance. Only persons familiar with
all safety aspects should operate this umbrella.
2. PRECAUTIONS - The CAPRI umbrella is intended for sun protection, not as protection from all
bad weather. It must be closed and removed from the frame in case of strong
winds or storms, as well as heavy rain or snow. Always close and remove the umbrella from the
frame at night, when you are not at home
and whenever it is not under control. The base must be ballasted with a minimum weight of 100 kg
(200 lbs). Always remove the handle from
the winch and keep it out of children's reach.
ASSEMBLY INSTRUCTIONS
COMPONENTS (fig. 1): A: base - B: hook - C: base tube - D: vertical pole - E: cantilever pole - F: umbrella -
G: winch - H: handle - I: clamps
M: bag with mounting accessories.
BASE ASSEMBLY (fig. 2 - fig. 2 a): assemble the base as shown in fig 2 - place the four slabs in the base
using the hook (B). The 2 adjustment screws (K) allow leveling
of the base (A). IMPORTANT: always fix the 2 feet (I) at the base (A).
CAUTION: tighten the base bolts well. and ballast the base with a weight of at least 200 kg (400 lbs).
FRAME ASSEMBLY (fig. 3 - fig.3a - fig. 3b - fig. 3c - fig. 3d – fig. 4):
1. (fig 3a) insert the cantilever pole (E) into the vertical pole (D) and fix the two parts with the bolts (P).
CAUTION: tighten the bolts (P) well.
2. (fig 3b) Slide the vertical pole (D) over the base pole (C). IMPORTANT: the vertical pole (D) must be
pushed down all the way into the square housing of the
orientation ring (O).
3. (fig. 3c) take the umbrella (F) and slide the umbrella attachment (R) over the cantilever pole (E).
CAUTION: the umbrella attachment (R) must be pushed in all the way onto the cantilever pole (E).
4. (fig.3) pass the cord (Z) over the pulley (S).
5. (fig. 3d) screw in the handwheel (T) into the threaded hole of the vertical pole (D).
6. insert the winch slot (G) onto the hand wheel (T). Next insert the winch (G) pin (b) into the hole (b') of the
vertical pole (D)
and screw the hand wheel (T) well in.
7. insert the handle (H) into the hole of the winch (G).
8.(fig. 3) put the 4 cover caps (N) onto the nuts.
Your umbrella is now ready for use.
