Jewel Laser Operating Manual
QUANTUM COMPOSERS, INC
PO Box 4248
Bozeman, MT 59772
(406)582-0227 phone
(406)582-0237 fax
www.quantumcomposers.com
Jewel Laser Manual v1.6
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jewel Laser and is the answer not in the manual?

Questions and answers

Summary of Contents for Quantum Composers Jewel Laser

  • Page 1 Jewel Laser Operating Manual QUANTUM COMPOSERS, INC PO Box 4248 Bozeman, MT 59772 (406)582-0227 phone (406)582-0237 fax www.quantumcomposers.com Jewel Laser Manual v1.6 Page 1...
  • Page 2: Table Of Contents

    SYSTEM OVERVIEW ............................ 11 JEWEL LASER B ......................... 11 LOCK IAGRAM Jewel Power Adapter ............................. 11 JEWEL LASER DESCRIPTION ......................... 12 LASER FEATURES ............................12 JEWEL LASER SETUP ..........................14 UNPACKING LASER ............................14 System Inventory ............................14 ..............................15...
  • Page 3: Jewel Manual V1.6 | Quantum Composers

    14. APPENDIX A - DICHROIC MODULE ......................37 ................................37 VERVIEW ..............................37 ONFIGURATIONS ..............................37 PECIFICATIONS Jewel Manual v1.6 | Quantum Composers Page 3...
  • Page 4: Introduction

    Internet - www.quantumcomposers.com Warranty The Jewel Laser has a one-year limited warranty from the date of delivery. This warranty covers defects in materials and workmanship. Quantum Composers will repair or replace any defective unit. Contact the Quantum Composers Service Dept. for information on obtaining warranty service.
  • Page 5: Safety

    Consulte la documentaciόn que acompaña. CAUTION: Risk of Electric Shock. ATTENTION: Risque d’éléctrocution. ACHTUNG!: Gefahr durch Stromschlag. ATTENZIONE: Rischio di shock elettrico. ADVERTENCIA: Riesgo de choque eléctrico Jewel Manual v1.6 | Quantum Composers Page 5...
  • Page 6: Laser Safety

    LASER SAFETY VISIBLE AND/OR INVISIBLE LASER RADIATION CAUTION: The Jewel Laser is a Class 4 OEM laser. Its output beam is, by definition, a safety and fire hazard. Precautions must be taken to prevent accidental exposure to both direct and reflected beams.
  • Page 7: Electrical Safety

    Consult with the Quantum Composers if repair of the laser electronics is required. Only those trained in high voltage, high current electronics, and who understand the laser circuitry, should be allowed to service and repair the laser electronics.
  • Page 8: Safety Labels And Locations

    Figure 1 and Figure 2 show the safety, model number, serial number and origination labels, and their locations on the Jewel Laser. These labels are installed at the factory and should not be removed by the user. If for some reason a label is removed, obscured, or damaged in any way, please contact the manufacturer for a replacement.
  • Page 9 Figure 2: Safety Labels - Jewel 1064, 532, 355, 266nm Figure 3 Safety Labels - Jewel 532nm OR 355nm OR 266nm ONLY Figure 4 Energy & Cover Label Figure 5 Laser Aperture Label Jewel Manual v1.6 | Quantum Composers Page 9...
  • Page 10 Figure 6 Model, Serial Number & Date of Mfg Figure 7 Cover Removed Page 10 Jewel Manual v1.6 | Quantum Composers...
  • Page 11: System Overview

    Figure 8 - System Block Diagram JEWEL POWER ADAPTER The power adapter for the Jewel Laser is a typical laptop style power adapter. It accepts inputs of 100-240 VAC and 50-60 Hz, and outputs 36 VDC, 1.6A (See Figure Figure 9 Power Supply Jewel Manual v1.6 | Quantum Composers...
  • Page 12: Jewel Laser Description

    15mJ and rep rates up to 20Hz. It is a self-contained laser head, including the diode and Q-switch drivers. LASER FEATURES The laser features (Figure 10 and Figure 11) are indicated below. Figure 10 Jewel Connection Panel Page 12 Jewel Manual v1.6 | Quantum Composers...
  • Page 13 The output is collinear, with all wavelengths exiting the same aperture. An optional dichroic module can be attached to “scrape” residual wavelengths from the output beams allowing single wavelength output. Jewel Manual v1.6 | Quantum Composers Page 13...
  • Page 14: Jewel Laser Setup

    Please do not connect the main power until you verify the power switch is in the OFF position. SYSTEM INVENTORY The Jewel Laser consists of the following items. Verify that all listed items are present in the shipping container. If there are any shortages or discrepancies, contact Quantum Composers immediately.
  • Page 15: System Setup

    Jewel laser. Drivers are included on the provided CD. Once the drivers have been installed, the Jewel laser will show up in the Device Manager as a USB to Serial Port Adapter. The Jewel laser can then be communicated with by either the included Jewel Laser application, or by using any generic communication terminal program.
  • Page 16: Driver Installation (Windows 7)

    9. A message will then indicate that the drivers have been successfully updated and a QC- LASER USB Communication Port is now available. 10. You can now communicate with the Jewel using either the included Jewel Laser application or by using any generic communication terminal program. You can view the Com Port number assigned to the Jewel in your computers device manager under Ports.
  • Page 17: Jewel Laser Application

     Power up the Jewel laser head.  Start the Jewel software.  The Jewel Laser application startup screen will be displayed as shown in Figure 12. o This application has been designed as a graphical user interface for ease of use. It includes a Command Terminal section that can be used to manually send and receive commands, to and from the laser system.
  • Page 18: Laser Operation Control

    System alignment should typically be done at diode current levels 10 to 20 Amps below the optimum setting. 3. Diode Pulse Width – In µsec it is the width of the diode current pulse. See the system ATP document for the optimal value. Page 18 Jewel Manual v1.6 | Quantum Composers...
  • Page 19 2 will trigger the qswitch on every 2 10. Fire button – Selecting the fire button will start laser output. NOTE: the laser must be enabled before the Fire button becomes active. Jewel Manual v1.6 | Quantum Composers Page 19...
  • Page 20: Laser Operation

    MANUAL SHUTTER OPERATION The Jewel Laser utilizes a manual shutter, located at the output of the laser head (see Figure 13). The shutter blocks laser output when in the CLOSED position. An internal switch prevents the laser from firing. The switch is satisfied only when the lever is fully in the OPEN position.
  • Page 21: Laser Head Connectors

    4. Sync Out – SMA connector – User selectable output signal. Can independently output Diode signal, Qswitch signal or both signals simultaneously. 5. USB – Communication Connection 6. Power Connector – Center pin positive connector matches included AC/DC power supply. Jewel Manual v1.6 | Quantum Composers Page 21...
  • Page 22: Laser Status Connectors

    Power-On Checklist Verify cable connections are correct. Apply power to laser power supply. Rotate keyswitch clockwise to turn on the Jewel Laser. Open Jewel Control Software. The laser will be ready to operate after approximately 2 minutes. When harmonic module is attached, best laser performance will require 10 minutes of warm-up time.
  • Page 23: Device Commands

     If the command is not recognized, then the device responds with a "?1<CR>".  If the command is recognized, but the parameter value is missing or invalid, then the device responds with a "?4” or “?5”. Jewel Manual v1.6 | Quantum Composers Page 23...
  • Page 24 Set Rep Rate Command to send: ;LA:RR 5<cr> sets rep rate to 5 Hz Response: OK<CR> Enable laser: Command to send: ;LA:EN 1<CR> Response: OK<CR> Fire laser: Command to send: ;LA:FL 1<CR> Response: OK<CR> Page 24 Jewel Manual v1.6 | Quantum Composers...
  • Page 25 Parameters are: 0 = manual mode, 1 = Low power, 2 = High power. A query returns the current state. If the diode current is adjusted by using the DC command, then the Jewel Manual v1.6 | Quantum Composers Page 25...
  • Page 26 System shot count, since factory build. System Status – Query Only. Returns the current system state. Value is a 16 bit decimal value with each bit position corresponding to a system state (See Table below, bits 0-15). Page 26 Jewel Manual v1.6 | Quantum Composers...
  • Page 27 Heater 2 temperature. Active temperature of the heater in degrees H2:VN? Heater 2 controller firmware version. spare spare spare Temp Temp Temperature Temp reading too high Target settling Control out of Temp Enabled range Jewel Manual v1.6 | Quantum Composers Page 27...
  • Page 28 A query will return the current percentage. If a ?1 is returned, this indicates the attenuator module is not installed. AT:SS? Attenuator Status. (See Table Below). Limit B Reserved Limit A Motor Motor Homing Motor Reserved Fault Installed Active Page 28 Jewel Manual v1.6 | Quantum Composers...
  • Page 29: Maintenance

    MAINTENANCE SERVICE PROCEDURES No User-Serviceable Parts Inside If service is required, contact the vendor for more information. Jewel Manual v1.6 | Quantum Composers Page 29...
  • Page 30: Trouble-Shooting

    TROUBLE-SHOOTING The JEWEL LASER control electronics are designed to control the laser and warn the user of problems that may occur. The microprocessor-based system monitors the laser system and automatically shuts down if a fault occurs. Software limits have been factory selected to protect the laser system against electrical and optical damage.
  • Page 31: Specifications

    Pulse Duration 1064nm 532nm 355nm 266nm Timing Jitter (+/-ns) <2 <2 <2 Beam Divergence 1064nm <2.5 <2.5 <2.5 532nm <2.0 <2.0 <2.0 355nm <1.8 <1.8 <1.8 266nm <1.8 <1.8 <1.8 Beam Diameter (mm) Jewel Manual v1.6 | Quantum Composers Page 31...
  • Page 32: Cables And Connection Pinout

    USB cable: Standard-A plug and Standard-B plug. A fully molded and shielded USB cable must be used with the Jewel laser to ensure compliance with all CE requirements. The cable must not allow access to the shielding portion of the cable through the outer sheathing i.e. no mold holes in the outer sheathing.
  • Page 33: Mechanical Interface Drawings

    MECHANICAL INTERFACE DRAWINGS Jewel Manual v1.6 | Quantum Composers Page 33...
  • Page 34 Page 34 Jewel Manual v1.6 | Quantum Composers...
  • Page 35 Jewel Manual v1.6 | Quantum Composers Page 35...
  • Page 36: Customer Service

    During the one year warranty period, we will repair or replace, at our option, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to Quantum Composers. All replaced parts and products become the property of the manufacturer.
  • Page 37: Appendix A - Dichroic Module

    266nm or 355nm with Dichroic Plus collinear residual 1064nm and 532nm Residual may be dumped or accessed SPECIFICATIONS Module Wavelength Transmission 94.1% 94.1% 94.1% Residual Energy .01% .01% .01% Spectral Purity >98% >98% >99% Jewel Manual v1.6 | Quantum Composers Page 37...
