Model No. ACD039
A. AC Charging At Home with 110 Volt Charger
1. Keep the Power Switch in middle "O" off position while charging.
2. Insert the AC charger round plug into the Spotlight Charging Port located at the back of the
spotlight.
3. Connect the 110 Volt AC Charger into the 110 Volt AC home receptacle.
4. Fully charge the spotlight according to the following charging schedule:
First time charge:..................................................... 24 hours
Recharge and subsequent charge:....................... 18 hours
5. Unplug the AC charger from the 110 Volt receptacle first and then remove theround plug
from the Spotlight Charging Port.
B. DC Charging In Your Vehicle with 12 Volt Charger
1. Keep the Power Switch in middle "O" off position while charging.
2. Insert the 12 Volt DC Charger round Plug into the Spotlight
3. Charging Port located at the back of the spotlight.
4. Connect the 12 Volt DC Charger Plug into the vehicle cigarette lighter or 12 Volt accessory port.
5. Fully charge the Spotlight internal battery for 8 hours while the vehicle engine is running.
6. Unplug t he D C c harger f rom t he v ehicle c igarette l ighter o r 1 2 V olt a ccessory p ort fi rst a nd t hen r emove t he
round plug from the Spotlight Charging Port.

12 VOLT DC CHARGER ADAPTOR FUSE REPLACEMENT:

1. Unscrew the retainer ring at the tip of the 12 Volt DC charger plug.
2. Replace the internal glass fuse with the same grade fuse rated at 2-AMP.

SPECIFICATIONS:

600 Peak cranking amps
Battery rated capacity
Bulb
LED area light
300 continuous cranking amps
12 Volt - 8 Ah
H4-120 Watt Quartz Halogen Bulb
360 mA
