- Page 1 Endure Group 123 (9-36kg) 9-18kg 15-36kg Owner’s Manual Parts list Fitting Guide ©2013 Graco PD254465B 07/13...
- Page 2 Assembling your Headrest Endure 123 Child Restraint. Slot Once removed Backrest from the box, place your new Harness Endure123 on the floor as shown in Chest pad Diagram 1, left. Armrest Open the two parts Buckle & crotch pad out so that the...
- Page 3 Care and maintenance IMPORTANT NOTE This is a “Universal” child restraint. It is approved to ECE Regulation 44.04 for Children should not be left in their child restraint system THESE INSTRUCTIONS ARE general use in vehicles and will fit most, unattended.
- Page 4 Use the Correct Shoulder Strap Height Please always read the manual before using it. The manual is located in the pocket at the side of the seat. TOO LOW TOO HIGH CORRECT...
- Page 5 Top slot Middle slot Bottom slot Top loop Bottom loop Using the Correct Strap Positioning 1 For infants and toddlers (9kg to 18kg) use middle and bottom slots and the loops on the harness strap. 2 For older children (up to 18kg) use the top middle slots and the...
- Page 6 For 9 – 18kg Changing the Shoulder Strap Height 1 Firstly, loosen the harness. 2 From the rear of the seat find the harness connector. 3 Release the strap from the harness connector. 4 From the front of the seat, pull the strap through the slot in the seat’s backrest and chest pad.
- Page 7 Changing the Shoulder Strap Height (continued) 5 Thread the chest pad through to the back. 6 Thread the chest pad back through the next slot up or down on the cover and backrest, depending on the size of your child. 7 Pull the chest pad through to the front of the seat.
- Page 8 Changing the Shoulder Strap Height (continued) 8 Make sure that the rubber side of the chest pads faces the child’s chest. Thread the harness strap through the chest pad. Make sure NOT to twist the straps. 9 Re-thread the harness strap back onto the harness connector at the back of the seat.
- Page 9 For 9 – 18kg Fitting the Child Restraint with the 3-Point Lap & Diagonal Seat Belt Position the child restraint 2 Feed the belt buckle on the vehicle’s seat. around the back of the child restraint over the harness 1 Thread the diagonal of the straps and back through vehicle seat belt underneath the opposite seat belt route...
- Page 10 Fitting the Child Restraint with the 3-Point Lap & Diagonal Seat Belt (continued) CLICK 5 Fasten the vehicle seat belt Now you can strap your child into the seat belt buckle into the seat. Make sure making sure the vehicle seat the seat belt has not become belt and the buckle are in twisted.
- Page 11 Fastening the Harness 1 Slot the two metal sections of the buckle connectors together. 2 Slot the two buckle connectors into the slot in the top of the buckle until they “click” into place. Always check the harness is correctly locked by pulling the shoulder straps upwards.
- Page 12 Tightening the Harness Slackening the Harness 1 Pull the shoulder straps 1 The harness is slackened by upwards to remove the slack pressing the lever (under the from the lap sections of the seat cover) on the front of harness. the seat.
- Page 13 For 15 – 36kg Removing the Safety Harness Shoulder Straps 1 Firstly, loosen the harness. 2 From the rear of the seat find the harness connector. 3 Slide both the harness straps off the harness connector at the back of the backrest. From the front of the seat, pull the straps through the slots in the seat backrest...
- Page 14 Removing the Safety Harness Lap Straps and Crotch Strap 1 From underneath the seat, locate the three webbing retainer buckles. Turn the buckles on their narrowest end and feed them, complete with webbing straps, through the slots in the base of the seat, then through the slots in the fabric cover.
- Page 15 For 15 – 36kg Adjusting the Headrest According to the child’s height, the headrest can be adjusted up or down. 1 Put one hand on the backrest. Pull the button in the headrest with your other hand. 2 Move the headrest up or down as required ensuring your child’s head is centred on the headrest.
- Page 16 For 15 – 36kg Fitting the Child Restraint using the Adult Seat Belt IMPORTANT: Before fitting the seat remove the shoulder straps, crotch strap and lap strap. (See pages 13 and 14) 1 Place the child restraint onto 3 Ensure that the lap strap the vehicle’s seat.
- Page 17 Fitting the Child Restraint using the Adult Seat Belt (continued) 5 Fasten the vehicle seat belt into the seat belt buckle making sure the vehicle seat belt and the buckle are in line with each other as indicated with the red tag. 6 Finish by tightening the vehicle seat belt until there is no slack and the child and child restraint are held...
- Page 18 UK GRACO CONSUMER SERVICES Newell Rubbermaid Halifax Avenue Fradley Park Lichfield WS13 8SS United Kingdom Consumer Service Desk (UK enquiries only) Dialling from UK: 0844 412 1212 Dialling from ROI: 0818 221 422 www.graco.co.uk Newell Rubbermaid Europe Sarl Chemin de Blandonnet 10...
