TEC Infra-red Cherokee CH-10SS Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

INFRA-RED
Cherokee
T T M M
OWNER'S MANUAL
Thermal Engineering Corporation
P.O. Box 868, Columbia, South Carolina 29202-0868
2741 The Boulevard, Columbia, South Carolina 29209
Telephone: (803) 783-0750 Toll-free (800) 331-0097
Fax : (803) 783-0756 Toll-free fax: (888) 581-0286
Website: www.tecinfrared.com
Revised 11/04 -- Z21.89b-2004/CSA 1.18b-2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cherokee CH-10SS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TEC Infra-red Cherokee CH-10SS

Summary of Contents for TEC Infra-red Cherokee CH-10SS

  • Page 1 INFRA-RED Cherokee T T M M OWNER’S MANUAL Thermal Engineering Corporation P.O. Box 868, Columbia, South Carolina 29202-0868 2741 The Boulevard, Columbia, South Carolina 29209 Telephone: (803) 783-0750 Toll-free (800) 331-0097 Fax : (803) 783-0756 Toll-free fax: (888) 581-0286 Website: www.tecinfrared.com Revised 11/04 -- Z21.89b-2004/CSA 1.18b-2004...
  • Page 2 Cherokee - Expanded View...
  • Page 3 Warnings Notices Notice to Customer DANGER PRIOR TO OPERATING THIS APPLIANCE, READ THIS If you smell gas: MANUAL FULLY AND CAREFULLY. RETAIN THIS 1. Shut off gas to the appliance. MANUAL FOR FUTURE REFERENCE AND HAVE AVAILABLE AT ALL TIMES. ENSURE THAT ALL 2.
  • Page 4 Lifetime Limited Warranty EXPRESS WARRANTIES Thermal Engineering Corporation (TEC) warrants this, TEC Cherokee Portable Gas Grill to be free ® of defects in material and workmanship when subjected to normal domestic use and service from the date of purchase as follows: LIFETIME The entire stainless steel outer structure is warranted indefinitely.
  • Page 5 Dear TEC Cherokee Owner: ® Congratulations on selecting a TEC Cherokee Portable Gas Grill. You’re among a select group who ® truly appreciate fine cooking and demand the best. I know you’ll be pleased with the Cherokee’s performance. Over the years, we’ve invested great resources in developing high quality gas grills that are truly unique —...

  • Page 6: Table Of Contents

    Contents Location General Overview Location ............4 General Overview Proper location and use is essential to insuring safe and Location of Cherokee continued trouble-free operation. Any alterations made Gas Connection ...........5 to the appliance without prior written consent from General Overview Thermal Engineering Corporation will void the product's LP Gas Cylinder Safety warranty.

  • Page 7: Gas Connection

    Location Gas Connection continued General Overview COMBUSTIBLE AND NON-COMBUSTIBLE CONSTRUCTION WARNING: WHEN PURCHASED FOR USE WITH Sides 8” PROPANE GAS, THE CHEROKEE GRILL COMES WITH A REGULATOR ASSEMBLY THAT USES TYPE I Back 8” CYLINDER CONNECTION DEVICE FOR USE WITH A 5-20 LB.

  • Page 8: Connecting Your Lp Gas Cylinder

    Gas Connection continued TRANSPORTATION OF DANGEROUS GOODS; AND will feel the Coupling Nipple seal when there is COMMISSION, SHOULD BE USED. ALL APPROVED slight resistance (See Figure 1). Turn about one-half CYLINDERS MUST BE EQUIPPED WITH AN INTEGRAL to three-quarters further to complete the COLLAR DESIGNED TO PROTECT THE CYLINDER connection.

  • Page 9: Disposable Lp Gas Connection

    Gas Connection continued to cross-thread the connection. SUPPORTING THE APPLIANCE. WHEN PROPERLY INSTALLED, THE CYLINDER SHOULD REST AT AN 9. To disconnect after use, ensure that the Burner Output APPROXIMATE ANGLE OF 45 FROM AN UPRIGHT Knob is in the OFF position, close the Cylinder POSITION (SEE FIGURE 4) OR A FULLY UPRIGHT POSITION (SEE FIGURE 3).

  • Page 10: Quick Disconnect Instructions

    Gas Connection continued 4. Remove the protective cover from the 16.4 oz. disposable supply cylinder (save the protective cover Quick Disconnect Instructions in order to place it on the cylinder after use). Procedure 5. Inspect the 16.4 oz. disposable LP-gas supply cylinder (especially the threaded connection) for damage, dirt 1.

  • Page 11: Operation

    Operation General Overview until ignition occurs. 7. Rotate Burner Output Knob to desired cooking WARNING: NEVER ATTEMPT TO USE THIS OR ANY level. OTHER GAS APPLIANCE WHEN YOU SMELL GAS. DO NOT LEAVE THIS APPLIANCE UNATTENDED. KEEP CHILDREN AND PETS AWAY FROM THE APPLIANCE FERME AT ALL TIMES.

  • Page 12: Extinguishing Burner Flame

    Operation continued Extinguishing Burner Flame should ONLY be made with the Burner Output Knob at the Burner LOW setting while visually monitoring Procedure changes (See Figure 9). 1. Depress and rotate Burner Output Knob to OFF. Procedure 2. Close the Valve on the gas supply cylinder. 1.

  • Page 13: Infra-Red Cooking

    TEC Infra-red grill. Please refer to the section entitled on page 13. SAMPLE COOKING METHODS Searing Method 1.

  • Page 14: Sample Cooking Methods

    Infra-red Cooking continued Sample Cooking Methods Use this chart as a cooking guide. Cooking times may vary, depending on thickness of food. FOOD CONTROL SETTING TOTAL COOKING TIME Steak 1" Thick High fire 2 min. each side 4 min. - Rare High fire 2 min.

  • Page 15: Cleaning And Maintenance

    Cleaning and Maintenance General Overview Also, never cover the ventilation louvers with foil or other materials that prevent air flow. Specifically: Proper care, maintenance and cleaning will help ensure Do not cover the entire surface with foil, a large pan, long life of your grill.

  • Page 16: Cleaning And Storage

    Cleaning and Maintenance continued Cleaning and Storage Maintenance CAUTION: The Cherokee requires very little maintenance. However, ALWAYS ALLOW THE GRILL TO COOL BEFORE CLEANING. DO NOT ALLOW WATER TO MAKE a periodic inspection of orifice openings and venturi CONTACT WITH THE BURNER SURFACE, AT ANY TIME. inlets to clear obstructions to gas flow is recommended.

  • Page 17: Appendix A. Expanded View Of Burner

    Appendix A: Cherokee Expanded View of Burner Figure 11. Cherokee Expanded View Reference Guide ITEM PART NO. DESCRIPTION QUANTITY FM1525 Burner Body Weldment FM1537 Tubing Assembly, Gas supply. HW0264 Valve, Burner FM1520 Ceramic Burner Clamp FM1521 Screen Retainer Clamp HW0555 Screw, Hex HD, 1/4-20 X 1-1/2”...

  • Page 18: Appendix B. Accessories

    Appendix B: Accessories Deep Fryer/Steamer the ceramic Burner glows orange. 5. Let the Burner stay on HIGH for 4 to 8 minutes to The Deep Fryer lets you cook foods that have been properly heat cooking oil or water. We suggest you traditionally limited to indoor cooking.
  • Page 19 Appendix B: Accessories continued Steamer The Steamer is great for steaming vegetables like broccoli, new potatoes, carrots or cauliflower. It’s also ideal for seafood such as shrimp, clams and oysters. The Steamer is used together with the Deep Fryer. CAUTION: STEAM CAN CAUSE SERIOUS BURNS.
  • Page 20 Appendix B: Accessories continued Griddle The Griddle provides a surface for you to use your grill for pan frying foods such as bacon, eggs, sausage, french toast and pancakes, and also for blackening fish and meats. After each use, the Griddle should be thoroughly washed with warm soap and water, dried and rubbed with cooking oil to season the griddle, prior to storing.

  • Page 21: Appendix C. Replacement Parts

    Appendix C: Replacement Parts Contact your Authorized TEC Dealer regarding information on replacement parts and accessories. Following is a list of replacement parts and accessories. ORDER NO. DESCRIPTION CHBA ............Burner Assembly (less screen) STBP ..............Burner Head CHBS..............Burner Screen CHBCVL ............Gas Valve, Burner, Propane STBK ..............Knob, Burner STIK..............Knob, Igniter CHCG ............Cooking Grid...

  • Page 22: Appendix D. Troubleshooting

    Appendix D: Troubleshooting PROBLEM REMEDY PROBABLE CAUSE Burner output at HIGH Check gas level in LP gas cylinder, if applicable. Lack of gas setting is too low. (Rumbling b. Reposition regulator hose, as necessary. b. Kinked regulator hose. noise and fluttering blue flame Adjust regulator, as necessary.
