Antenex Antenna Y(B)8966 Product Specifications

TITLE: Y(B)8966 Black or Gold anodized 896-970MHz fully welded
6 elements 9dBd Directional Yagi
ELECTRICAL
Frequency Range:
Frequency Bandwidth:
VSWR:
Return Loss:
Nominal Gain:
Front to Back Ratio:
Maximum Power:
Nominal Impedance:
Polarization:
Pattern:
Horizontal Beamwidth:
(For Horizontal Polarization)
Vertical Beamwidth:
(For Vertical Polarization)
Tuning:
Transmitting / Receiving:
Product Specification
896 - 970 MHz
74 MHz
< 2.0:1
-10dB max
9 dBd
20 dB
300 W
50Ω
Vertical or Horizontal
Directional
56°
52°
Fixed Tune
Both
Part #:
Memo:
Page:
Date:
MOUNTING
Included:
MECHANICAL
Material:
Length:
Height:
Boom Diameter:
Weight:
Rated Wind Velocity: 150mph (241kph)
Rated Wind Velocity (with 0.5" radial ice)
Equivalent Flat Area: 0.2492 sq. ft.
Cable:
Termination:
Color:
Lightning Protection: Lightning Arrestor
Y(B)8966
Spec
1 of 4
3/10/2006
Heavy Duty Cast mount bracket
accommodates 7/8" mast
Aluminum
27.688"
6.75"
0.875"
3.9 lbs
80mph (130kph)
None
N–female connector
Gold or Black Anodized
LABH350NN
(Sold Separately)
