Thermaltake Riing 12 Installation Manual

Riing
A x 3
Fan
1
Install the fans properly onto the radiator.
3
Set the DIP switch on the back side of the
controller to assign the number of the controller
4
C
Connect the controller cable onto the mainboard
(USB 2.0 9 pin) and controller.
Patented
256 Colors
Parts List
B x 1 C x 1
Controller Controller Cable
Installation Guide
A
C
Radiator Fan TT Premium Edition
D x 1 E x 1
Bridge Cable Power Cable Short Screw Long Screw
2
B
A
Connect the 4pin fan cable onto the controller.
NO.1 NO.2
ON ON
1 2 3 4 1
NO.5 NO.6
ON ON
1 2 3 4 1
NO.9 NO.10
ON ON
1 2 3 4 1
NO.13 NO.14
ON ON
1 2 3 4 1
F x 12 G x 12
NO.3 NO.4
ON ON
2 3 4 1 2 3 4
NO.7 NO.8
ON ON
2 3 4 1 2 3 4
NO.11 NO.12
ON ON
2 3 4 1 2 3 4
NO.15 NO.16
ON ON
2 3 4 1 2 3 4
H x 1
Velcro
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
