- Page 1 StudioLive Series III ™ Stagebox Mode Addendum ® English www.presonus.com...
-
Page 2: Table Of Contents
Table of Contents Overview — 1 About AVB Networking — 1 Getting Started — 2 Channel Routing Grid — 5 Preamp Control — 6 Stagebox Modes — 6 Recording in Stagebox Mode — 8... -
Page 3: Overview
Overview StudioLive™ Series III About AVB Networking Stagebox Mode Addendum Overview There are two types of potential data flowing to and from your StudioLive Series III mixer: control and audio. Control connections can be made over standard Ethernet networks, including WiFi networks. Sending and receiving audio requires an AVB network. -
Page 4: Getting
Direct connection DESIGNED AND ENGINEERED IN BATON ROUGE, LA, USA • MANUFACTURED IN CHINA • PATENTS PENDING • “STUDIOLIVE” and “PreSonus” ARE REGISTERED TRADEMARSK OF PRESONUS AUDIO ELECTRONICS • SD LOGO IS A TRADEMARK OF SD-3C, LLC MANUFACTURING DATE StudioLive 16... -
Page 5: About Avb Networking
DESIGNED AND ENGINEERED IN BATON ROUGE, LA, USA • MANUFACTURED IN CHINA • PATENTS PENDING • “STUDIOLIVE” White= PoE Off and “PreSonus” ARE REGISTERED TRADEMARSK OF PRESONUS AUDIO ELECTRONICS • SD LOGO IS A TRADEMARK OF SD-3C, LLC Link MANUFACTURING DATE... - Page 6 Getting Started StudioLive™ Series III About AVB Networking Stagebox Mode Addendum 3. Press the Stagebox Setup button on the screen. EFFECTS MASTER MASTER CONTROL 4. Tap on the “Select Rack Mixer” menu and choose your rack mixer from the list. If you have more than one rack mixer connected on the network and are unsure which mixer is which, you can press the Identify button.
-
Page 7: Channel Routing Grid
Network as the Input Source. For example, if you would like to use the guitar connected to Input 3 on your StudioLive 16R in any mix on your StudioLive 24, you would select Channel 3 on your StudioLive 24 and enable Network as the input source. -
Page 8: Preamp Control
StudioLive Series III rackmount Main Left/Right outputs are sourced from the console mixer’s Main Left / Right signals. The StudioLive Series III console mixer’s FlexMixes are sourced from the rack mixer as described below: StudioLive 16R StudioLive 24R StudioLive 32R... - Page 9 Getting Started StudioLive™ Series III Stagebox Modes Stagebox Mode Addendum Monitor Mix While this mode is active, the StudioLive Series III rackmount mixer retains all its mixing functionality for every FlexMix, allowing you to create monitor mixes and more using the FlexMix outputs. The Main Mix in this mode will not be accessible or have any effect on the sound as this mix is sourced from the Main Left/Right mix of the console mixer and must be controlled from there.
-
Page 10: Recording In Stagebox Mode
DESIGNED AND ENGINEERED IN BATON ROUGE, LA, USA • MANUFACTURED IN CHINA • PATENTS PENDING • “STUDIOLIVE” and “PreSonus” ARE REGISTERED TRADEMARSK OF PRESONUS AUDIO ELECTRONICS • SD LOGO IS A TRADEMARK OF SD-3C, LLC MANUFACTURING DATE wireless mic multi-effects... - Page 11 Integration, and XMAX are trademarks or registered trademarks of PreSonus Audio Electronics, Inc. Capture, Impact, Mixverb Presence, RedLightDist, SampleOne, Studio One, and Tricomp are trademarks or registered trademarks of PreSonus Software Ltd. Mac and Mac OS are registered trademarks of Apple, Inc., in the U.S. and other countries. Windows is a registered trademark of Microsoft, Inc., in the U.S.
- Page 12 StudioLive Series III ™ Stagebox Mode Addendum 18011 Grand Bay Ct. • Baton Rouge, ® Louisiana 70809 USA• 1-225-216-7887 Part# 70-22000063-A www.presonus.com...
