  • Page 1 Operating instructions. PosCon OXH7 – Clever height measurement.

  • Page 2: Table Of Contents

    Contents General information ........................4 Concerning the contents of this document ..................4 Intended use ........................... 4 Safety .............................. 4 Commissioning ..........................5 Connection ............................ 9 Connection cable ..........................9 Pin assignment and connection diagram ..................10 Installation ........................... 11 Mounting ............................
  • Page 3 Error correction and tips ......................67 Examples of sensor setup ......................67 Error correction ..........................68 Revision history .......................... 69 en_BA_OXH7_PosCon_OXH7.docx 3/70 Baumer Electric AG 21.03.2018 14:28/tof V1.2 ANW_81184815 Frauenfeld, Switzerland...

  • Page 4: General Information

    General information 1.1 Concerning the contents of this document This manual contains information about the installation and initial setup of Baumer PosCon OXH7 sensors. It is a supplement to the mounting instructions supplied with each sensor. Read these operating instructions carefully and follow the safety instructions! 1.2 Intended use The Baumer PosCon OXH7 sensor measures heights of objects.

  • Page 5: Commissioning

    Commissioning After the sensor is connected and installed, configure it via the display. The sensor is then ready for operation and outputs the measuring value in mm to the screen. Optionally, the measuring field can be limited or the switching output can be configured. Connection Installation Application specific settings...
  • Page 6 Installation Function HEIGHT At the function HEIGHT, the reference surface will be teachted-in with FLEX MOUNT. The sensor can be mounted angled with up to +/- 30 ° to the reference surface. Left Right +/-30° Blind region FIELD OF VIEW Measuring field width left 0 mm...
  • Page 7 Application specific settings HEIGHT Height of an object For a height measurement, the required MEAS TYPE (average value, maximum, minimum or delta). The reference surface (0) is the maximum measuring range of the sensor, or if present, the FLEX MOUNT teached reference surface.
  • Page 8 Optional settings FLEX MOUNT If the sensor is mounted at an angle or the reference surface is not at the End of the measuring range Sde, FLEX MOUNT must be activated and the reference surface taught in. If FLEX MOUNT is activated, the following settings are reset: SCALE OUT, FIELD OF VIEW and DIGITAL OUT.

  • Page 9: Connection

    Connection ATTENTION! Incorrect supply voltage will destroy the device! ATTENTION! Connection, installation and commissioning may only be performed by qualified personnel. ATTENTION! The IP protection class is valid only if all connections are connected as described in the technical documentation. ATTENTION! Laser class 1 laser beam according to EN 60825-1:2007.

  • Page 10: Pin Assignment And Connection Diagram

    3.2 Pin assignment and connection diagram Color Function Description Pin 1 WH = white Rx/Tx- RS 485 receive/transmit- (B) Pin 2 BN = brown + Vs Voltage supply (+15…+28 VDC) Pin 3 GN = green analog Analog output (4…20 mA or 0…10V) Pin 4 YE = yellow Switching output, push-pull...

  • Page 11: Installation

    Installation ATTENTION! Connection, installation and commissioning may only be performed by qualified personnel. Protect optical surfaces from moisture and dirt. 4.1 Mounting The sensor has four mounting holes for flexible alignment and mounting. The use of 2 M4x35 screws is recommended for mounting.

  • Page 12: The Reference Surface

    4.3 The reference surface If the height of the object is to be measured from a specific surface or the sensor is mounted at an angle up to ±30°, then the reference surface must be taught in with the FLEX MOUNT function. The following points must be satisfied for teaching in the reference surface: •...

  • Page 13: Measuring Field Definition

    4.4 Measuring field definition The maximum measuring field and additional important measuring field definitions are described in the following diagram. The important terms "left" and "right" are to be regarded respectively from the viewpoint of the connector side of the sensor. Left Right Blind range...
  • Page 14 4.4.1 Blind region The region from sensor level R2 up to the start of measuring range Sdc is called the blind region, i.e. the sensor cannot detect any objects there. Objects in this area can cause incorrect measuring values. Object Start of measuring range Sdc Measuring field...

  • Page 15: Mounting

    4.5 Mounting: The sensor can be installed at an inclination of up to ±30° to the reference surface. This is particularly useful when space conditions do not allow any other installation option. See the FLEX MOUNT section. After activation of FLEX MOUNT, the sensor axis is no longer relevant. The measurement coordinate system is now represented by the M and K axes.
  • Page 16 4.5.2 Practical zero point search The LIVE MONITOR mode can be used to find the LEFT EDGE reference point (0 mm). This function displays the Right RISING Left LEFT EDGE RISING (the first rising edge from the left side) of objects. Now an object is slowly pushed toward the presumed zero point.

  • Page 17: Installation Accessories

    4.6 Installation accessories To ensure optimal mounting, various mounting brackets are available an as accessory. These brackets fit the mounting holes of the sensor exactly. The sensor can be shifted and adjusted inside the mounting hole. 4.6.1 Mounting kit for standard installation Order no. 11120705 With the mounting bracket for standard installation, the sensor can be mounted quickly and easily at a 90°...
  • Page 18 4.6.2 Mounting kit for ±30° angled installation with horizontal mounting Order no. 11126836 If it is not possible to position the sensor at a right angle to the reference surface, the sensor can be mounted at an inclination angle of ±30° with this mounting kit. Mounting kit 11126836 Contents of this set: 30°...

  • Page 19: Configuration

    Configuration 5.1 Overview of control elements LEDs Graphical display Avg HEIGHT 112.4 mm Touch panel: Four touch-sensitive keys DOWN 5.1.1 Display modes Run mode 112.42 mm The sensor is in run mode, the measuring value is displayed in large characters. Main menu AVG HEIGHT In the main menu the active mode is displayed at the top,...
  • Page 20 5.1.2 Functions of the individual keys Pressed briefly Pressed >2 s. Back Jump to Run mode Up/increase value DOWN Down/decrease value Save new value* *Only in the setting menu when the top line is displayed on a black background (change value) Locking the touch panel 5.1.3 The keys on the control panel are locked when they are not pressed for 5 minutes.
  • Page 21 5.1.4 Further key functions Action Reaction Slide over all keys from left to right Unlock locked touch panel Only if touch panel is locked Slide over all keys from right to left Jump directly to run mode Can be used from any menu 5.1.5 LEDs on the sensor Lights up...

  • Page 22: Function Tree

    5.2 Function tree The menu that can be accessed via the touch panel is shown below. en_BA_OXH7_PosCon_OXH7.docx 22/70 Baumer Electric AG 21.03.2018 14:28/tof V1.2 ANW_81184815 Frauenfeld, Switzerland...

  • Page 23: Live Monitor

    5.3 LIVE MONITOR The installation conditions can be checked using LIVE MONITOR. The sensor outputs the angle and edge position to the object with the smallest distance to the sensor. LIVE MONITOR 15,7° 13mm Angle in ° Position of object (To object or LEFT EDGE RISING reference surface)
  • Page 24 • “End of measuring range” of the sensor represents the standard reference for angle measurement. Once the reference surface with FLEX MOUNT is Teached, “End of measuring range” is no longer valid. The new reference surface corresponds to 0° tilt angle. •...
  • Page 25 Displaying the tilt angle to the reference surface For displaying the tilt angle of the sensor to the reference surface, FLEX MOUNT must not be activated and in the measuring field must not be an object. The output will be ---- for EDGE LEFT RISING of the object. Finding the reference point without a teached reference surface Once an object is within the measuring range, the position of LEFT EDGE RISING and the angle of the surface of the object relative to the axis "End of measuring range"...

  • Page 26: Meas Type

    5.4 MEAS TYPE The PosCon OXH7 can determine the height of an object in various ways. The measuring value is calculated in mm with analog or RS485 output. NOTE If the MEAS TYPE is changed, SCALE OUT, DIGITAL OUT, FLEX MOUNT and FIELD OF VIEW are reset to the default setting.

  • Page 27: Flex Mount (Function Height)

    5.5 FLEX MOUNT (Function HEIGHT) With FLEX¨MOUNT the reference surface will be Teached-In. With respect of its inclination, the sensor is able to calculate the height of objects correctly. This function is recommended for the correct calculation of the height of objects with respect to the reference surface.
  • Page 28 5.5.1 The FLEX MOUNT function is switched off by "No", the sensor can be mounted again at a right angle. If FLEX MOUNT is not activated, a 0° angle and "distance" = end of measuring range Sde are set. The angle symbol disappears from the display.
  • Page 29 5.5.3 TEACH REF Conditions during TEACH REF The following four conditions must be met during the reference surface teach-in process. If one of the symbols listed below appears on the display, it lights up red. The teaching process can only begin after elimination of all errors (the display no longer lights up red).
  • Page 30 5.5.4 CORRECTION The reference surface can be moved in height with CORRECTION after teaching. This is useful when using an auxiliary plate, or if the reference surface has to be hidden. Using an auxiliary plate In this menu item, the reference surface is defined with due regard to the thickness of the auxiliary plate (optional).
  • Page 31 Hide the reference surface The fact that everything is hidden below the reference surface, the originally teached-in reference surface can be hidden by shifting the reference surface upwards. New position of the reference surface. Everything underneath is hidden. CORRECTION = Move the teached-in reference surface (-x mm) Teached-in reference surface Example: While using the Delta Height function (Maximum height minus minimum height of the object) the teached-in...

  • Page 32: Object

    5.6 OBJECT To improve sensitivity to dark objects, the exposure time can be increased. This also changes the measuring repetition time. 5.6.1 Object: Bright (Reflectivity > 18%, white-grey) Exposure time Short (Pulse duration) 5.6.2 Object: Dark (Reflectivity 6…18%, dark grey-black) Exposure time Long (Pulse duration)
  • Page 33 The diagram shows the effects of the median (sample size 5). The filter is used to suppress errors. The output changes after a defined number of samples (sample size/2). The measurement frequency is not affected by this filter, but rather the response time. Moving average The output of the moving average filter is the average of all values found in the array with the defined sample size.
  • Page 34 Number of samples until the correct value will be output: In PRECISION mode HIGH, the distance has to be stable for 2 + 0 samples for the output to show the current value. In precision mode very high, the distance has to be stable for 2 + 16 samples for the output to show the current value.

  • Page 35: Field Of View

    5.8 FIELD OF VIEW The width of the measuring field can be limited with the FIELD OF VIEW function. All measuring values outside the set measuring field are ignored. This is particularly useful if, for example, the measuring field contains an unwanted object that should not be detected. The measuring field is adapted by software so the width of the visible laser beam does not change.
  • Page 36 5.8.2 LIMIT LEFT Limitation of the left side of the measuring field in mm, measured from the reference point. 5.8.3 LIMIT RIGHT Limitation of the right side of the measuring field in mm, measured from the reference point. NOTE The measuring field width (LIMIT LEFT to LIMIT RIGHT) must be at least 2 mm.

  • Page 37: Analog Out

    5.9 ANALOG OUT 5.9.1 SCALE OUT In the factory setting, the analog output runs across the entire measuring range (start of measuring range Sdc - end of measuring range Sde) from 0...10V (voltage mode) or from 4...20mA (current mode). The start and end of the measuring range can be reset with SCALE OUT, reducing the measuring field and changing the calibration curve.
  • Page 38 Example: SCALE OUT with HEIGHT function At an object height of 30 mm, the sensor should display 20 mA and 4 mA at a height of 5 mm. • Set OFFSET to 5 mm • Set HEIGHT to 30 mm 10 V / 20 mA 30 mm 0 V / 4 mA...

  • Page 39: Digital Out

    5.10 DIGITAL OUT With Pin 4 (out), the user has a configurable switching output. It can be defined as a single switching point (threshold) or a window. Pin 4 is activated when the value (point or window) is exceeded or not reached (active high or active low depending on the setting). The switching points can only be placed inside the active, preset measuring field (note SCALE OUT).
  • Page 40 5.10.3 WINDOW P1 Window point 1 (for the WINDOW mode) is selected in mm using the arrow keys. The point must lie within the measuring range (greater than start of measuring range Sdc +2x hysteresis 5.10.4 WINDOW P2 Window point 2 (for the WINDOW mode) is selected in mm using the arrow keys. The point must lie within the measuring range (less than end of measuring range Sde -2x hysteresis 5.10.5 LEVEL...

  • Page 41: System

    5.11 SYSTEM 5.11.1 RS485 BAUD The sensor can be operated with three different baud rates: • 38400 • 57600 • 115200 5.11.2 RS485 ADDR Every sensor has its own RS485 address, allowing the selected sensor to be addressed directly. This address is preset to 001 in every sensor and the 3 digits can be changed here.
  • Page 42 5.11.7 RESET This resets all settings in sensor parameters to the factory settings. MEAS TYPE = Delta HEIGHT OBJECT = Bright PRECISION = Standard SCALE OUT = Max. values FLEX MOUNT = Not activated (standard installation) FIELD OF VIEW = Max. values DIGITAL OUT = Threshold (end of measuring range Sde, active high) RS485 lock...

  • Page 43: Setting

    5.12 SETTING The settings entered in the sensor can be applied, stored or displayed here. 5.12.1 APPLY The settings saved under SAVE can be activated here. • Setting 1 • Setting 2 • Setting 3 5.12.2 STORE The settings entered in the sensor can be stored here. Three storage spaces are available.

  • Page 44: Function And Definition

    Function and definition 6.1 Sensors data sheet General data PosCon OXH7 PosCon OXH7 11159406 11161809 OXH7-11159406 OXH7-11161809 Function Object height Object height Function: FLEX MOUNT Function: FIELD OF VIEW Measuring range (distance) 100…150 mm 100…500 mm Start of measuring range Sdc End of measuring range Sde Measuring range (width) 48…72 mm...
  • Page 45 Digital output hysteresis 0.5% of Sd (switch point) 1 % of Sd (switch point) Minimal switching window 2 mm 10 mm Power on indication Green LED Green LED Output indicator Yellow LED / red LED Yellow LED / red LED Light source Red laser diode, pulsed Red laser diode, pulsed...
  • Page 46 Optical properties PosCon OXH7 PosCon OXH7 11159406 11161809 OXH7-11159406 OXH7-11161809 Light source InGaAlP -Laser Diode AlGaInP-Laser Diode Wavelength 656 nm 660 nm Operational mode pulsed pulsed Pulse duration bright mode 0.6 ms 0.15 ms dark mode 1.8 ms 0.8 ms Pulse period bright mode >1.7 ms...
  • Page 47 6.1.2 Dimensions *Optical axis en_BA_OXH7_PosCon_OXH7.docx 47/70 Baumer Electric AG 21.03.2018 14:28/tof V1.2 ANW_81184815 Frauenfeld, Switzerland...

  • Page 48: Functional Principle

    6.2 Functional principle The sensor works on the laser triangulation principle. By means of special optics, a laser beam is enlarged into a line and projected to the surface of the object to be measured. Using the multi-lens system, the reflected light from this laser line is projected onto a matrix.
  • Page 49 6.2.1 qTarget The measuring field is aligned with the housing reference surfaces at the factory. The beam position in every sensor is in exactly the same spot, which makes planning and sensor replacement very easy. en_BA_OXH7_PosCon_OXH7.docx 49/70 Baumer Electric AG 21.03.2018 14:28/tof V1.2 ANW_81184815 Frauenfeld, Switzerland...

  • Page 50: Measuring Repetition Time And Response Time

    6.3 Measuring repetition time and response time Response time fast Measuring 2x measuring repetition time repetition time Laser- exposure Response time worst case 3x measuring repetition time 6.3.1 Measuring repetition time The measuring repetition time (specified in milliseconds) is the time between two exposure times. Measuring repetition time = 1/‘Measuring frequency in Hz‘...

  • Page 51: Hysteresis

    6.4 Hysteresis 6.4.1 Definition of the Hysteresis The Hysteresis is the difference between switch-on and switch-off point. It is defined as a percentage of the sensing distance . Without hysteresis , objects could at the limit of the switching points lead to ceaseless on/off switching or bouncing.
  • Page 52 6.4.3 Characteristics of the switching output at SWITCH POINT Measuring value Hystereis SWITCH POINT High Output Level 6.4.4 Characteristics of the switching output at WINDOW Measuring value Hysteresis WINDOW P2 WINDOW WINDOW P1 Hystersis High Output Level en_BA_OXH7_PosCon_OXH7.docx 52/70 Baumer Electric AG 21.03.2018 14:28/tof V1.2 ANW_81184815 Frauenfeld, Switzerland...

  • Page 53: Object To Be Measured

    6.5 Object to be measured 6.5.1 Smallest detectable object For an object to be reliably detected, it must conform to the minimum object width . This minimum object width varies with the distance from the sensor. Smallest detectable object close Smallest detectable object...

  • Page 54: Interfaces And Outputs

    • Covers entire sensor measuring range 6.6 Interfaces and outputs All sensor inputs and outputs that transmit measuring data are referred to as interfaces. Analog current output Synchronization Switching output Alarm output RS-485 NOTE When an object moves laterally out of the measuring field, the last valid output value is retained until an object is again present in the measuring range.
  • Page 55 6.6.1.1 Formulas for analog signal conversion The measuring values can be converted from mm into the analog output signal and vice versa with the following formulas. If the measuring range has been limited with SCALE OUT, the new settings for Current Start of measuring range Sdc and Current End of measuring range Sde must be used.
  • Page 56 6.6.2 Sync-In / Trigger The measurement and signal output can be interrupted with the Sync-In input by connecting with high. As long as Sync-In stands at high, the sensor delays the next measurement (Hold) and reduces the power of the laser beam.
  • Page 57 Measuring if Synch-In low The sensor checks the level of the Sync - In each time before it sends out the laser pulse. If it is low, the sensor will immediately begin the next measurement. Start measuring cycle High Sync-In High Laser 1ms or 3ms...
  • Page 58 Sync-In Low to High: If the Synch - In level is High, the sensor completes the actual measurement, but do not start the next measurement. All outputs are held (Hold function). High Sync High Laser 1ms or 3ms (Object white/black) High Reading camera Calculations...
  • Page 59 Sync-In High to Low: Sync - In has to set from High to Low to bring the sensor back into the measuring mode. The Sync - In must be at least 5µs set to low level, so that the sensor starts to measure. For this first measuring cycle, the response time will be 5µs longer.
  • Page 60 6.6.3 Switching output The switching output can be set as a point or a window, see Section DIGITAL OUT. The output is transmitted as a push-pool signal with active high or active low (inverted), depending on the setting. 6.6.4 Alarm output The sensor evaluates the signal level (amount of reflected light) during every measurement cycle.
  • Page 61 6.6.6 Response of outputs If no object is within the measurement range, the sensor will hold the last valid signal. The alarm output is high during this time. Object Measuring Range Object Object Object Conveyer Direction of movement Analogue output Alarm output en_BA_OXH7_PosCon_OXH7.docx 61/70...

  • Page 62: Touch Panel

    6.7 Touch panel 6.7.1 Function and design The display consists of a monochrome 128 x 32 pixel LCD with RGB LED background illumination. The sensor can be configured using four capacitive touch operator interfaces. 6.7.2 Dimensioning 20.5 Capacitive operator 31.5 6.8 Memory All changes made in the sensor are saved in nonvolatile (permanent) memory and are even retained after a power outage.

  • Page 63: Standard Deviation

    Standard deviation The standard deviation is a term from the field of statistics or stochastics and is given in σ (sigma). With the standard deviation it is possible to determine how great the dispersion of values around a mean value is. Broadly speaking, the standard deviation is the average distance of all measured expressions of a characteristic from the mean value.

  • Page 64: Safety Instructions And Maintenance

    Safety instructions and maintenance 7.1 General safety instructions Intended use This product is a precision device and is used for object detection and the preparation and/or provision of measuring values as electrical quantities for a subsequent system. Unless this product is specially labeled, it may not be used for operation in potentially explosive environments.
  • Page 65 Class 1: No risk to eyes or skin Class 2: Do not stare into beam Class 2 lasers emit radiation in the visible portion of A Class 1 laser product is defined as safe the spectrum (400 nm to 700 nm). A short-term in normal operations under reasonably exposure (duration to 0.25 s) is harmless to the eye.

  • Page 66: Influence Of Ambient Light

    7.3 Influence of ambient light Ambient light from lamps, the sun, etc. in the view field of the sensor can lead to malfunctions or a reduction of accuracy and should be avoided as much as possible. 7.4 Front (optics) In the event of broken front window, broken display panel or loose or detached laser optics the sensor must immediately be disconnected from the power supply and it must not be put back into operation until it has been repaired by an authorized person.

  • Page 67: Error Correction And Tips

    Error correction and tips 8.1 Examples of sensor setup 8.1.1 Analog height measurement with inclined installation of 30°, height 10 mm= 0V, height 30 mm = 10 V 1. Connection: In accordance with connection diagram 2. Installation: The sensor is installed at and inclination of 30°.

  • Page 68: Error Correction

    8.2 Error correction Error Error correction • No function Check connection. Power supply 15…28 VDC between pin 2 (+Vs, brown) and pin 7 (GND, blue) • Green LED flashes Short circuit at the digital output. Check connection. • Red LED lights up Object outside measuring field (near, far or to the side) •...

  • Page 69: Revision History

    Revision history 23.11.2015 Manual released in version 1.0 26.01.2016 Integrated linearity and definition of response time and measuring repetition time Integrated new article; optimized Laser characteristics 8.04.2016 28.04.2016 Additional information about the working principle of the filter PREZISION 31.05.2016 New sensor type integrated. Chapter 6.1 updated 15.06.2016 Chapter “beam divergence”...
  • Page 70 en_BA_OXH7_PosCon_OXH7.docx 70/70 Baumer Electric AG 21.03.2018 14:28/tof V1.2 ANW_81184815 Frauenfeld, Switzerland...
