COMSOL Stone Series User Manual

Stone Series Power Bank
4400mAh
User Manual
Version 1.1

Power Bank Layout

USB Output: 5V 1A USB Input: 5V 1A
Leather Strap 4 x LED Capacity Indicators
ON/OFF Button

Suitable for

• iPhone/iPad/iPod
• All smartphones including Samsung, HTC, Motorola, Nokia, LG
Sony, BlackBerry, Huawei, Asus, Telstra, Doro & more
• GPS devices
• Digital cameras
• Portable Bluetooth devices such as headset, hands-free car kit
speaker etc.
• Portable hand-held gaming consoles
• eReaders such as Kindle, Kobo & Sony

Features

• 4400mAh is enough capacity to fully charge an iPhone or average
smartphone twice*
• Rechargeable more than 500 times
• Four LED indicators to show remaining capacity
• Includes micro USB cable for charging and re-charging
• Built-in over charging and short circuit protection
• Battery: 4400mAh Advanced Li-Polymer
• Input Connector: 1 x Micro USB female
• Output Connector: 1 x USB Type A female
• Input: DC5V 1A
• Output: DC5V 1A
• Charging Time: 5 to 6 hours
• Size: 111mm (L) x 60mm (W) x 25mm (H)
• Weight: 120g
To Charge Power Bank
Charge via USB Wall Charger Charge via Computer USB Port
• Using the included USB Type A to micro USB Type B cable,
connect the larger USB Type A connector to an AC wall adapter
or USB port on a computer
• Connect the smaller micro USB Type B connector to the Input
connector on the power bank
• During charging the LED's will flash to show status
• When charging is complete all four LED's will be permanently on
To Charge Phone or USB Device

To Charge a Mobile Phone or other USB Device

• Using your phone or other USB device's charging cable, connect
the USB Type A connector to the Output connector on the power
bank
• Connect the other end of the cable to your device
• Charging should commence automatically. If it doesn't, press the
power button
• If your phone or device uses a standard micro USB Type B
connector then you can also use the included cable to charge
your device
• When your phone or device is fully charged, the power bank will
automatically turn itself off
To Check Remaining Capacity
Press the ON/OFF button and the capacity LED's will come
on. After five seconds the LED's will turn off automatically.
Four LEDs on: 75% to 100% remaining capacity
Three LEDs on: 50% to 75% remaining capacity
Two LEDs on: 25% to 50% remaining capacity
One LED on: 5% to 25% remaining capacity
One LED flashing: less than 5% remaining capacity

Important Safety Instructions

• To maximize battery life span, fully charge power bank
before first use for 5 to 6 hours
• Store power bank in a cool and dry place.
• Do not store power bank in hot or humid environment
• Operating temperature should be between -10c to 45c
• If power bank is not used for long periods of time, you should
charge and discharge once every three months
• When charging a device, the power bank may feel warm, this
is a normal operating condition and should not be cause for
concern
• In normal conditions, the battery performance will decline
over several years
• Do not dispose of power bank in heat or fire
• Do not clean power bank with harmful chemicals or detergents
• Misuse, dropping or excessive force may cause product
damage
All rights reserved. Any information printed here is subject to change
without notice.
iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and
other countries.
iPad is a trademark of Apple Inc.
All other brand names, trademarks, registered trademarks and copyrights
are the property of their respective owners.
Comsol and the Comsol logo are trademarks of Comsol Pty Ltd
* Based on smartphone with a battery capacity of 1500mAh
