COMSOL SG30 User Manual

Power Bank Charger
3000mAh
User Manual
Power Bank Layout
Anti-Skid Suction Cups
Micro USB Input
Rotating USB Output
Power On/Off
LED Indicators
Suitable for
• iPhone/iPod
• Most smartphones including Samsung, HTC, Motorola, Nokia, LG, Sony,
BlackBerry, Huawei, Asus, Telstra, Doro & more
• GPS devices, digital cameras, portable hand-held gaming consoles
• Portable Bluetooth devices such as fitness tracker or headset
• eReaders such as Kindle, Kobo & Sony
Features
• 24 x Anti-Skid suction cups to securely attach to your phone
• Sticks to almost any smooth surfaced phone or phone case
• Simple and fast to stick and remove
• Rechargeable more than 800 times
• Four LED indicators to show remaining capacity
• Includes short micro USB cable for charging your Android phone
• Includes additional micro USB cable for charging the power bank
• Built-in over charging and short circuit protection
• Advanced 3000mAh Lithium-Polymer battery
• Input: DC5V 1.5A
• Output: DC5V 1A
• Charging Time: 5 to 6 hours
• Size: 107mm (L) x 58mm (W) x 13.5mm (H)
• Weight: 92g
To Charge Power Bank
Charge via USB Wall Charger Charge via Computer USB Port
• Using the included USB cable, connect the larger USB connector to an
AC wall adapter or USB port on a computer
• Connect the smaller micro USB connector to the input port on the power
bank
• During charging the LEDs will flash to show charging status
• When charging is complete all four LED's will be permanently on
To Charge Phone or USB Device
• Using your phone or other USB device's charging cable, connect the USB
Type A connector to the USB Output on the power bank
• Connect the other end of the cable to your device
• Charging should start automatically. If it doesn't, press the on/off button
• If your phone or device uses a standard micro USB Type B connector
then you can also use the included cable to charge your device
• When your phone or device is fully charged, the power bank will stop
charging to prevent over charging or over heating
To Check Remaining Capacity
• Press the On/Off button and the LEDs will light to show remaining capacity
• The LEDs will turn of automatically after about 10 seconds
LED On / Off / Flashing Remaining Capacity
Less than 5%
5% to 25%
25% to 50%
50% to 75%
75% to 100
Important Safety Instructions
• To maximize battery life span, fully charge power bank before first use for
5 to 6 hours
• Store power bank in a cool and dry place.
• Do not store power bank in hot or humid environment
• Operating temperature should be between -10c to 45c
• If power bank is not used for long periods of time, you should charge and
discharge once every three months
• When charging a device, the power bank may feel warm, this is a normal
operating condition and should not be cause for concern
• In normal conditions, the battery performance will decline over several years
• Do not dispose of power bank in heat or fire
• Do not clean power bank with harmful chemicals or detergents
• Misuse, dropping or excessive force may cause product damage
