COMSOL Travel Series User Manual

Travel Series Power Bank
8800mAh Dual USB Ports

User Manual

Version 1.1

To Charge Power Bank

Charge via USB Wall Charger
• Make sure the ON/OFF switch is in the OFF position (O=OFF)
• Using the included USB Type A to micro USB cable, connect the larger USB Type A
connector to an AC wall adapter or USB port on a computer
• Connect the smaller micro USB connector to the input connector on the power bank
• During charging the LED's will flash to show status
• When charging is complete all four LED's will be permanently on

To Charge Phone or USB Device

To Charge a Mobile Phone or other USB Device
• Output 1 is for charging a mobile phone or other USB device
• Output 2 is for fast charging an iPad
• Output 2 can also be used to charge a mobile phone or other USB device
• You can simultaneously charge two devices at the same time
• Using your phone or other USB device's charging cable, connect the USB Type A
connector to either Output 1 or Output 2 connector on the power bank
• Connect the other end of the cable to your device
• Slide the ON/OFF switch to the ON position (I=ON)
• When your phone or device is fully charged, the power bank will stop charging to
prevent over charging or over heating
• If your phone or device uses a standard micro USB connector then you can also use
the included micro USB cable to charge your device
Charge via Computer USB Port

Power Bank Layout

1
2
3
1 USB Output 2: DC 5V 2.1A 2
3 USB Output 1: DC 5V 1A 4
5 4 x LED Capacity Indicators 6

Suitable for

• iPhone/iPad/iPod
• All smartphones including Samsung, HTC, Motorola, Nokia, LG, Sony, BlackBerry & more
• GPS devices & digital cameras
• Portable Bluetooth devices such as headset, hands-free car kit speaker etc.
• Portable hand-held gaming consoles
• eReaders such as Kindle, Kobo & Sony

Features

• 8800mAh is enough capacity to fully charge an average smartphone four times*
• Dual USB Outputs to simultaneously charge two devices
• 2.1A high output for fast charging an iPad
• Rechargeable more than 500 times
• Handy built-in LED torch
• Four LED indicators to show remaining capacity
• Includes micro USB cable for charging and re-charging
• Built-in over charging and short circuit protection
• Input Connector: 1 x Micro USB female
• Output Connectors: 2 x USB Type A female
• Input: DC 5V 1A
• Output 1: DC 5V 1A / Output 2: DC 5V 2.1A
• Charging Time: 8 to 9 hours
• Size: 108mm (L) x 80mm (W) x 25mm (H)
• Weight: 250g

To Check Remaining Capacity

Slide the ON/OFF switch to the ON position (I=ON) and the capacity LED's will come on
Four LEDs on: 75% to 100% remaining capacity
Three LEDs on: 50% to 75% remaining capacity
Two LEDs on: 25% to 50% remaining capacity
One LED on: 0% to 25% remaining capacity

To Operate LED Torch

Slide the ON/OFF switch to the torch position
Torch =

Important Safety Instructions

• To maximize battery life span, fully charge power bank before first use for 5 to 6 hours
• Store power bank in a cool and dry place
• Do not store power bank in hot or humid environment
• Operating temperature should be between -10c to 45c
• If power bank is not used for long periods of time, you should charge and discharge
once every three months
• When charging a device, the power bank may feel warm, this is a normal operating
condition and should not be cause for concern
• In normal conditions, the battery performance will decline over several years
• Do not dispose of power bank in heat or fire
• Do not clean power bank with harmful chemicals or detergents
• Misuse, dropping or excessive force may cause product damage
All rights reserved. Any information printed here is subject to change without notice.
iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries.
iPad is a trademark of Apple Inc.
All other brand names, trademarks, registered trademarks and copyrights are the property of their
respective owners.
Comsol and the Comsol logo are trademarks of Comsol Pty Ltd
* Based on smartphone with a battery capacity of 1500mAh
www.comsol.com.au
4
5
6
LED Torch
Micro USB Input: DC 5V 1A
ON/OFF Switch (I=ON / O=OFF)
