Summary of Contents for Eurotek EK-MFR/1
- Page 1 Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 1 of 13 Rev F of 13/10/2006 User’s handbook Digital radio link EK-MFR/1 EK-PWS/11 board EK-PWS/12 board EK-PWS/13 board Eurotek s.r.l.
- Page 2 The test results show compliance with the Class A limits for radiated emissions. The present design is property of Eurotek s.r.l. and is protected by Copyright. Its reproduction, distribution and disclosure to third-parties without written authorisation is forbidden Every reproduction, re-distribution or disclosure without prior written authorisation is expressly forbidden by the law and can lead to serious civil and penal sanctions.
- Page 3 Eurotek not assumed responsibility for waste disposal in contrast with enforced laws. LIFE SUPPORT APPLICATIONS. Eurotek’s products are not designed for use as critical components in life support devices or system without the express written approval of the Eurotek S.r.l. As used herein.
- Page 4 Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 4 of 13 Rev F of 13/10/06 First aid: artificial breathing(mouth to mouth) In case of electric shock you have to ensure the first aids to the patient, but to do this you have to consider two very important things: - interrupt immediately the electric circuit;...
- Page 5 Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 5 of 13 Rev F of 13/10/2006 INDEX EK-PWS/6 BOARD........................6 ..........................6 OP VIEW ......................7 OP VIEW DESCRIPTION ........................8 OTTOM VIEW ....................9 OTTOM VIEW DESCRIPTION BOARD PANEL ........................10 .....................
-
Page 6: Ek-Pws/6 Board
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 6 of 13 Rev F of 13/10/06 EK-PWS/6 BOARD Top view Eurotek s.r.l. -
Page 7: T Op View Description
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 7 of 13 Rev F of 13/10/2006 Top view description Line filter Cooling fan Cooling fan General switch Fuse Vac (2A) AC power supply Fuse +12V (5A) Fuse -DC (5A) Fuse +DC (5A) -
Page 8: B Ottom View
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 8 of 13 Rev F of 13/10/06 Bottom view Eurotek s.r.l. -
Page 9: B Ottom View Description
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 9 of 13 Rev F of 13/10/2006 Bottom view description A) DC power supply 18 ÷ 36 Vdc EK – PWS/11 36 ÷ 72 Vdc EK – PWS/12 EK – PWS/13 NOT INCLUDED... -
Page 10: Board Panel
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 10 of 13 Rev F of 13/10/06 BOARD PANEL Panel representation Panel description Ethernet connector Auxiliary connector Power supply connector RS-232 interface connector Eurotek s.r.l. -
Page 11: P Anel Connectors Description
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 11 of 13 Rev F of 13/10/2006 Panel connectors description 2.3.1 RS-232 interface connector FUNCTION GROUND GROUND 2.3.2 Auxiliary connector FUNCTION +12V OUTPUT +12V OUTPUT UART 2 RX ANALOG TO DIGITAL 0 DIGITAL TO ANALOG 0... -
Page 12: Technical Specification
Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 12 of 13 Rev F of 13/10/06 TECHNICAL SPECIFICATION EK – PWS/11 Input range voltage(Vac) 230 Vac, 110Vac 18 ÷ 36 Vdc Input range voltage(Vdc) 47 ÷ 63 Hz Input Frequency Output Current... - Page 13 Series EK-MFR/1 EK-PWS/x board Arch. 2348 Pag. 13 of 13 Rev F of 13/10/2006 Eurotek S.r.l. c/o Parco Scientifico Tecnologico e delle Telecomunicazioni in Valle Scrivia Strada Comunale Savonesa, 9 15050 RIVALTA SCRIVIA (AL) tel. +39 (0)131 860205 r.a. fax +39 (0)131 860993 http://www.eurotektel.com...
