  • Page 1 ® MODEL NO. PE20 OWNER’S MANUAL PE20MAN-REV 01.032018...

  • Page 2: Table Of Contents

    Layers of protection add to the security of the pool. A barrier fence should always be used around a IMPORTANT: pool in conjunction with a gate or door alarm, such as SmartPool’s YardGard to alert the responsible party that an unwanted intrusion to the pool area has occurred.

  • Page 3: List Of Components

    LIST OF COMPONENTS ITEM DESCRIPTION Alarm Body Mounting Plate Siren Plate Bracket Ladder Mount Clamp Plate Shim Screw Self Tapping Screw (Ladder Mount) Machine Threaded Screw (Deck Mount) Adhesive Pad (sets) Plate Shim Ladder Shim Deflector Shield INSTALLATION REQUIRED TOOLS/MATERIALS •...
  • Page 4 ALARM ALARM Oval or Rectangle Pools WARNING: Every pool is different. The alarm must be tested immediately upon installation to ensure the positioning of the alarm fits its specific environment. Improper positioning of the alarm or return fitting may result in false alarms. ALARM ASSEMBLY 1.
  • Page 5 LADDER MOUNT 1. Using the "W" shaped Ladder Mount Clamps, place (1) clamp around the alarm and the top, vertical portion of ladder, ensuring a tight fit around the ladder. If the clamp is loose around the ladder, insert a set of Ladder Shims to tighten the fit around the ladder (Fig 4 &...
  • Page 6 DECK MOUNT (WOOD DECKING) 1. Identify the location of the where the alarm will be 4. Use deck screws (not included) to fasten the bracket installed. securely to the deck. 2. Loosely attach the Alarm Body to the Mounting Plate 5.

  • Page 7: Winterization

    ADJUSTING THE ALARM SENSITIVITY ADJUSTMENT SWITCH NOTE: Alarm is factory-set to the highest sensitivity level. 1) Loosen the screws on the bottom of the sensor tube (Fig 15). Fig 15 2) Slide the adjustment switch from the high sensitivity position (H) to the low sensitivity position (L) (Fig 16).

  • Page 8: Warranty

    WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. The representations set forth herein are the only representations made by SmartPool LLC, with respect to the product, and this warranty does not constitute either a performance or satisfaction guarantee. It is the responsibility of the product owner to regularly test and check the product for proper function and safety.
