Freemie Equality Quick Setup Manual

Hands Free, Concealable
Breast Pump Collection System
Assembly Layout
Valve
Base
Breast
Funnel
Valve
Cup
Preparing for rst use
1
MUST BOIL THESE PARTS FOR
10 MINUTES BEFORE FIRST
USE ONLY FOR SECURE FIT
BETWEEN PARTS.
Breast Valve
Funnel Base Cup
Clean parts with hot soapy water and
rinse thoroughly after each use.
Hand wash valve
in hot, soapy water.
Rinse thoroughly.
Assemble Freemie Cups
2
1
Align Valve to Valve Base correctly
Correct Incorrect
Incorrect assembly of the valve will
cause milk to back up into tubing
Align stem on
3
Valve Base with
tubing port on
Funnel
Push
together
Insert Tubing into Valve Base
5
Ensure all connections
are secure and tight to
prevent loss of suction.
®
Compatible
Your Freemie
Compatible Pump
Connecting to
your pump
See reverse side or
User Manual for
Connection Diagrams
DO NOT BOIL OR STEAM
THESE PARTS:
Quick Short Pressure
Connector Valve Tube Reducer
Freemie Tubing T Connector Pump Tubing
ENSURE ALL PARTS ARE DRY
PRIOR TO USE. DO NOT
STEAM STERILIZE OR USE
ABRASIVES ON ANY FREEMIE
COMPONENTS. STEAM MAY
DAMAGE PARTS AND CAUSE
THESE PARTS TO NOT FIT
SECURELY.
2
Push Valve onto Valve Base correctly
Once
assembled,
gently tug
on Valve to
ensure it is
secure
Push Breast
4
Funnel and
Valve Base
rmly
together
Align ports
6
and snap
together
without
pinching
tubing
This is intended as a reference guide,
please read entire User Manual prior to use.
compatible pumps (see User Manual).
Before using Freemie
3
Practice pouring water from Freemie Cups into a storage
bottle or bag before trying with pumped milk to help
ensure successful transfers.
BRA FIT IS CRITICAL TO PROPER USE.
Before choosing a bra, pump with the Freemie using your hands to hold the
Cups in place.
To achieve the same pressure and sensation with the Freemie Cups in your
bra, it may be necessary to adjust your bra or try different bras to nd the
best t for you. A sports bra or stretchy nursing bra works well for some
women.
Freemie Cups can be used discreetly with proper wardrobe planning. Loose
clothing with easy access and scarves will be most discreet. Before rst use
in public, put water in the Cups and practice placement and removal of the
Cups in your bra. This exercise will help in determining wardrobe
requirements.
Freemie position and placement
4
See reverse side to connect Freemie to a compatible NUK, Medela,
Hygeia, Lucina, Philips, Ameda, Freedom or Equality pump. See User
Manual for connection diagrams to other compatible pumps.
Place Freemie Cup inside
12 12
your bra with tubing
facing upright in the
12 o'clock position.
*
PLACEMENT AT ANY OTHER POSITION MAY
CAUSE MILK TO FLOW INTO TUBING.
Milk in tubing
Freemie Breast Funnel should be centered over
the nipple.
Keep Freemie Cups upright while pumping
by sitting or standing in an upright position.
*
LEANING FORWARD, BENDING OVER, OR
RECLINING MAY CAUSE LOSS OF SUCTION
OR MILK TO FLOW INTO TUBING.
To begin pumping, set suction to low and slowly adjust to your
personal suction preference. See User Manual.
*
CAUTION: If milk ows into tubing, stop suction immediately by turning
off your pump or disconnecting the tubing. See User Manual.
Transfer milk from Freemie Cups
5
• Turn off pump, remove tubing from Freemie Cups.
• Carefully remove Freemie Cups from your bra.
HANDLE CUPS WITH CARE.
pour spout. Placement at any other position may
cause milk to ow into the tubing or leak out of cups.
Transfer milk to storage container or bottle after
pumping. Pour quickly with breast funnel up.
Handwash all components that come into contact with
breast milk in hot soapy water, then rinse thoroughly.
Leave parts disassembled until ready for next use.
Quick Set-up Guide
Use the Freemie System only with
Tubing in
12 o'clock
position.
Milk pours out from
