- Page 1 ARES 2000 U S E R M A N U A L A N D C A R E I N S T R U C T I O N S...
- Page 2 Rangefinder Elements Startup and Shutdown “Mode“ Button Battery Compartments 1. Remove the battery cap on the bottom and insert a CR2- “Ranging“/”Power” Button Laser Receiving Objective 3V battery into the battery chamber, having the negative Eyepiece Laser Emission Objective side facing in, then close the battery cap. BACK VIEW SIDE VIEW 2.
- Page 3 Eyepiece LCD Display Menu Operational Flowchart Power ON: Short press Battery Indicator; to power on. The startup Aiming Reticle; screen will display the last used mode. After 10 seconds Golf Function Sign of no-operation the display will power off automatically. Incline Angle, Horizontal Distance, Vertical Distance Mode Sign;...
- Page 4 2. Select display mode: While the display is active, long press 3. Select measuring units: Short press to select “M” or button for more than 3 seconds. Press button to “Y”. select Golf or Auto mode. Flashing icon indicates selected. Yards Golf Mode Meters...
- Page 5 4. Select ranging mode: Short press to select one of the following ranging modes: Incline Angle, Vertical Distance, 5. Low battery indication: When the voltage is lower than Horizontal Distance, “OFF“ No-Display. 2.7V, “LOW BATTERY” sign will appear and blink as below, the blink interval is 1s, and will blink for 5 seconds and then power off automatically.
- Page 6 THE ATHLON GOLD MEDAL LIFETIME WARRANTY* Your Athlon product is not only warranted to be free of de- fects in materials and workmanship for the lifetime of the product. Athlon will also repair or replace, at no charge to you, your product if you should damage it through normal use.
- Page 7 T O LL F R E E : 1- 8 5 5- 9 1 3 - 5 6 7 8 C ON TA CT @ AT H LO NO PT IC S.C O M 801 N MEADOWBROOK DR, OLATHE, KS 66062...
