All fire extinguishers should be installed, inspected and maintained in
accordance with the National Fire Protection Association standard titled
"Portable Fire Extinguishers", NFPA-10 and the requirements of local
authorities having jurisdiction.
When maintenance is indicated, it should be performed by trained
persons having proper equipment.
vessels and must be treated with respect and handled with care. They
are mechanical devices and require periodic maintenance to be sure that
they are ready to operate properly and safely.
recommends that the maintenance of portable fire extinguishers be done
by a trained professional – your local authorized Amerex Distributor.
Amerex Corporation makes original factory parts available to insure
proper maintenance – use of substitute parts releases Amerex of its
warranty obligations.
threads that are manufactured to exacting tolerances. O-rings, hoses,
nozzles, and all metal parts meet precise specifications and are
subjected to multiple in-house inspections and tests for acceptability.
There are substitute parts available that are incorrectly labeled as UL
component parts, some are advertised as Amerex type. None of these
meet UL requirements and all of them voids the Amerex extinguisher
warranty and UL listing. DO NOT SUBSTITUTE.
RECHARGE FIRE EXTINGUISHERS IMMEDIATELY AFTER ANY USE
REFERENCES IN THIS MANUAL:
NFPA-10 Portable Fire Extinguishers
CGA C-1 Methods for Hydrostatic Testing of
Compressed Gas Cylinders
CGA C-6 Standard for Visual Inspection of
Compressed Gas Cylinders
AMEREX CORPORATION – P.O. BOX 81 – TRUSSVILLE, ALABAMA 35173-0081
Phone: 205/655-3271
e-mail:
sales@amerex-fire.com
Printed in U.S.A.
MAINTENANCE & RECHARGE
SERVICE MANUAL
NO. 05604
Fire extinguishers are pressure
Amerex parts have machined surfaces and
AVAILABLE FROM:
National Fire Protection Association
1 Batterymarch Park, P.O, Box 9101
Quincy, MA 02269-9101
Compressed Gas Association, Inc.
4221 Walney Road, 5
Chantilly, VA 20151-2923
Fax: 800/654-5980
Web Page:
Amerex strongly
th
Floor
http://www.amerex-fire.com
0M05604F Rev. 3/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 344 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Amerex 344

  • Page 1 – your local authorized Amerex Distributor. Amerex Corporation makes original factory parts available to insure proper maintenance – use of substitute parts releases Amerex of its warranty obligations. Amerex parts have machined surfaces and threads that are manufactured to exacting tolerances.
  • Page 2 NOTES IN THIS MANUAL BE CAREFULLY OBSERVED. FAILURE TO HEED THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY. AMEREX ASSUMES NO LIABILITY FOR SERVICE, MAINTENANCE OR RECHARGE OF FIRE EXTINGUISHERS BY PUBLISHING THIS MANUAL. INSPECTING THE EXTINGUISHER This extinguisher should be inspected at regular intervals (monthly or more often if circumstances dictate) to insure that it is ready for use.
  • Page 3 Inspect the extinguisher for damaged, missing or substitute parts. Only factory replacement parts are approved for use on Amerex fire extinguishers. Remove and check ring (safety) pin for freedom of movement. Replacement if bent or if removal appears difficult.
  • Page 4 Thoroughly clean all parts of the disassembled valve with a soft bristle brush or soft cloth. Blow the valve out with dry nitrogen. Install a new Amerex valve stem assembly after lightly lubricating the valve stem o-ring with Visilox 711 (do not lubricate the valve stem seal). Reassemble the spring and downtube. Carefully install a new collar o-ring which has been lightly lubricated with Visilox 711.
  • Page 5 Remove defective gauge* an install a new Halon 1211 gauge (see parts list) using Teflon tape on the gauge threads. Leak in the cylinder Contact Amerex if under warranty, otherwise mark "REJECTED" and remove from service or return to owner. Leak under operating lever Replace valve stem assembly.
  • Page 6 Lever & Rivet – "A" Valve 01060 Rivet Only for Lever 06067 Lever & Rivet – 344/344T, A344T 02625 Lever & Rivet – Forged Vlv (except 344/344T,A344T) 07762 Lever & Rivet – Brass Valve 01563 Rivet Only for Lever – Brass Valve 04839 Gauge –...
