OPCOM Farm O2-Light Quick Manual Manual

O -Light
²
Thank you for purchasing OPCOM Farm O ² -Light, the indoor hydroponics growing system. It is designed with
easy to use and efficient growth by one-touch AUTO mode. It holds up to (2"pot) 16 plants capacity. Read the
quick guide carefully before setting it up. For detailed user guide video, please scan the QR code or visit
O ² -Light page at http://www.opcomfarm.com/O2light
A. Assembly
A1. Remove all the parts from box and check all the accessories.
Planting Partition x 2
Grow Kit
Seedling Tray(ST-30) x1pcs Grow Sponge 2x30pk
1. Grow kit
(342*110*126mm) (OASS16K For Basil)
a. Seedling kit :
NT-Starter x24pcs
(OAMS27K for O -Light)
2
b. Nourishment:
A2. Easy Set Up: Please follow below steps to set up
Position lamp's arm and adjust the angle.
1
Install the planting partition(accommodate 1", 2", 3",
2
4" pot sizes per your needs)
Connect power adapter to the unit.
3
Add 0.7 gallons(2.7 Liter) water to the unit.
4
Ensure air tube immersed into the water.Always keep
water up the water level mark line.
Turn on the power and test the unit.
5
Auto Switch Mode : O²-Light is not only a hydroponics
6
system but also a table lamp, you can switch between
grow light and reading light by simply rotating lamp
arm or pressing auto button to show "Green".
A3. Reading Adjustment.
45 degrees
Left/ Right
180 degrees
Horizontal
Chart I: Control Box Mode
Fuction
Status
Growth (Growth Light)
Auto Reading (Hi Brightness)
Reading minus (Lo Brightness)
ON
LED
High
Low
OFF
ON
Pump High
Low
OFF
* 1. Push the button on the control box to switch the mode
Manual
Warranty Card
Adapter
INPUT: 100-240V~ 50/60Hz
OUTPUT: DC12V 3A
Accessories
Grow Sponge 2x30pk
(OASS15K For Lemon Balm) 1. Small Filter Bag x20pcs
4 4
Water Level
4 4
2
Water Level
0.7 gallons（2.7L）
6
Rotate over 30 degrees
Growth mode Reading mode
* Fan on when LED on , more air circulation will make plants grow better
UP
Front Back 90 degrees
90 degrees
Down
60 degrees
Light Time(On/Off)
LED: 16H/8H Pump: 24 cycles/ day ( 10mins / cycle )
LED: 24H/0H Pump: 12 cycles/ day ( 20Secs / cycle )
LED: 24H/0H Pump: 12 cycles/ day ( 20Secs / cycle )
24H/0H
18H/6H
10H/14H
0H/24H
48 cycles/ day ( 10mins/ cycle )
36 cycles/ day ( 10mins/ cycle )
1 cycle/ 5day ( 10mins/ cycle )
0 cycle/ day
* 2. you can reset the product timeline by pushing the LED button for 2 sec.
☑
Please read and follow every steps to avoid any malfunction.
B. Seedling
B1. Sprout stage
1. Add water into the seedling tray, up to the water (red) line.(Fig1)
2. Open Grow Sponge package, Put the sponge into water of seedling tray(make sure the front side with the
seed label is up),press the sponge into water 5 seconds and let the sponge absorb water completely.(Fig1)
3. Place the seedling tray with cover in the shade or cover it with black cloth(to block light).(Fig2)
4. Spray water to Sponges and keep them wet everyday.
5.During 7 days, find the sprouted one in the tray; pick it out, and move it into product (make sure the
sponges line up with the black dot on the partition)(Fig3) and to next stage: B2. Young Plant Stage.
6. Discard unsprouted sponge after regular germination time.
* Different plant may have different germination time, please check it before plant.
Quick Guide Manual
O -Light Chart II: Plant Stage
²
Basil, Lemon Balm
Quick Guide Manual
Sprout Stage
Young plant stage
Growing Stage
2. Large Filter Bag x10pcs
* Please keep the seedling sponge package in refrigerator if you don't use it.
* For your expected plant amout, you can refer to the sprout rate of 1st planting cycle.
* If you need more planting information, please vist to www.opcomfarm.com to read "Plant Q&A".
B3. Growing Stage
1. When plants grow to 3-4 inches height, switch to Auto Mode(Growth), refer to Chart I & II.
2. Harvest the larger plants for consumption and keep smaller plants growing.
* To save time, sow the new seeds in sprout tray one week before you restart the planting process.
5
* When water is less than 1/2 tank full, change to new water with new NT-starter.
C. Planting
C1. Planting Process: Buy plants from local stores
Choose a suitable filter bag size for 2", 3", 4" pot, put it into the
1
filter bag and tie the strings(Fig1), Then put the plants into
tank(Fig2)
2"
2"x 8pcs
1Line
Soil F Soil Free: Remove pot(Fig1) and put into filter bag(Fig2) and then move
2
to the product(Fig3).
(Fig1)
Free combination：You can mix different size of pots and sponges
3
into the growing hole of O
Planting Time LED Mode Pump Mode Nourishment
Day 0~7 N/A N/A N/A
Day 3~14 ON ON NT-Starter
After Day 14 Auto Auto NT-Starter
3" 4"
(Fig1) (Fig2)
3"x 5pcs 4"x 4pcs
1Line 1Line
2" Pots x 16pcs
(Fig2) (Fig2) (Fig3)
-Light.
²
Free combination
This side up!
(Fig1)
(Fig2)
(Fig3)
T (℃)
RH EC pH Notes
20℃- 25℃ 80% 0.5-1.0 5.5-6.5 The sponge is fully wetin seedling tray.
15℃- 30℃ 45%-70% 1.0-2.0 5.5-6.5
15℃- 30℃ 45%-70% 1.0-2.0 5.5-6.5
B2. Young Plant
C2. Flower Selection
Formaldehyde Clean
Rainbow Tree Chlorophytum Lucky Bamboo Chrysanthemum Snake Plant
Trichloroethylene Clean
White Bunny Ears Golden barrel Mottled Spurge Turk's Cap Cactus Golden ball cactus
Carbon dioxide & Formaldehyde Clean
Dot plant Wax Plant Dragon tree Barberton daisy Dragon tree
Xylene Clean
Dumbcane Tuberous Sword Fern Flaming lily Evergreen Pteris cretica
Carbon Monoxide Clean
Ivy Peace Lilies Parlour Palm Aloe Spiral-leaved croton
