Chamberlain CPS-RPEN4GM Manual

To prevent possible SERIOUS INJURY or DEATH from a closing door or gate:
• Be sure to DISCONNECT POWER to the operator BEFORE installing the photoelectric sensor.
• The door or gate MUST be in the fully opened or closed position BEFORE installing the LiftMaster
Monitored Entrapment Protection device.
• Correctly connect and align the photoelectric sensor.
• Install the photoelectric sensor beam NO HIGHER than 6" (15 cm) above the fl oor for door and
27.5" (69.8 cm) above grade for gate operators.
• LiftMaster ® Monitored Entrapment Protection devices are for use with LiftMaster
and Gate Operators ONLY. Use with ANY other product voids the warranty.
• Entrapment protection devices MUST be installed per the operator owner's manual for each Entrapment
Zone.
APPLICATION
The LiftMaster ® Protector System models CPS-RPEN4 and CPS-RPEN4GM, are single-sided safety devices
providing monitored entrapment protection for use with LiftMaster
The CPS-RPEN4 and CPS-RPEN4GM may be installed in areas exposed to rain or moisture. The images are for
reference and your product may look different.
Model CPS-RPEN4 (LiftMaster
Door Operators)
Logic 4
Medium Duty Logic
FDC Commercial Door
Operator
CARTON INVENTORY
Photoelectric Sensor. . . . . . . . . . . . . . . . . . . . . . . (1)
Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . (2)
Refl ectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (2)
LIFTMASTER PROTECTOR SYSTEM
®
IMPORTANT INFORMATION ABOUT THE PHOTOELECTRIC SENSOR
Be sure power to the operator is disconnected.
When properly connected and aligned, the photoelectric sensor will detect an obstruction in the path of its
beam. If an obstruction breaks the beam while the door/gate is closing, the operator will stop and typically
reverse to the full open position.
The sensor must be installed so that it faces the refl ector across the entrapment zone, no more than
6" (15 cm) above the fl oor for a door and no more than 27.5" (69.6 cm) above grade for a gate. Minimum
installation width of 5 feet and maximum width of 50 feet. The devices can either be installed on the left or right
of the entrapment zone.
The brackets must be securely fastened to a solid surface such as the wall framing. If installing in masonry
construction, add a piece of wood at each location to avoid drilling extra holes in masonry if repositioning is
necessary.
The invisible light beam path must be unobstructed. No part of the gate or door (or door tracks, springs,
hinges, rollers or other hardware) may interrupt the beam while the door/gate is closing.
® Commercial
FDCL Commercial Door Operator
FDOA Commercial Door Operator
FDOB Commercial Door Operator
PROTECTOR SYSTEM
MODELS CPS-RPEN4 AND CPS-RPEN4GM
® Commercial Door and Gate Operators.
Model CPS-RPEN4GM (LiftMaster
Gate Operators)
CSL24V Series
CSW24V Series
RSL12V Series
Refl ectors Support Bracket . . . . . . . . . . . . . . . . . . (1)
Installation Instruction . . . . . . . . . . . . . . . . . . . . . (1)
Self-tapping Screws . . . . . . . . . . . . . . . . . . . . . . . (4)
1
LIFTMASTER
®
® Commercial Door
®
RSW12V Series LA500
LA400
LA412
®
