Atlona AT-HD800 User Manual
Portable hdmi signal generator
with 3d patterns
Hide thumbs
Also See for AT-HD800:
- User manual (12 pages) ,
- Features & specifications (2 pages) ,
- Q&a (2 pages)
Related Manuals for Atlona AT-HD800
Summary of Contents for Atlona AT-HD800
- Page 1 Atlona Portable HDMI Signal Generator with 3D Patterns AT-HD800 User Manual Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515 www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515...
-
Page 2: Table Of Contents
8. Support Timing Table ..........9. Support Pattern Table ..........10. Connection and Installation ..........10 11. Safety Information ..........12. Warranty ..........13. Atlona Product Registration ..........Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515 www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515... -
Page 3: Introduction
TION INTRODUCTION The Atlona HD800 is a Portable HDMI signal generator capable of testing any video resolution or timing color space issues in any DVI or HDMI video system. The HD800 features 19 test patterns including 3D tests Side by side, Top and Bottom, and Frame packing, a format that is mandatory for all HDMI 1.4 devices. -
Page 4: Power Consuming Chart
Different mode/resolution and batteries used may have different results. OPERATION CONTROLS AND FUNCTIONS 7.1. Bottom Panel DC 5V HDMI IN HDMI OU T OF F POWER ① ② ③ ④ Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515 www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515... -
Page 5: Front Panel
1. INFO/PATTERN: 1.1. If the input of the AT-HD800 is connected with the source and output is connected with the display (or other gear before the display) and user wants to view capabilities of both source and display side by side the Info Pattern can be pressed. - Page 6 5. Bypass/Pattern LED: This LED will illuminate in green when the input source is connected. When the input source is not connected the LED will not illuminate. Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515 www.atlona.com | toll free: 1-877-536-3976 For International: 1-408-962-0515...
- Page 7 6. BATT. LOW: This LED will illuminate red when the power is on. If the LED is flashing it means the power is below 10% and the AT-HD800 needs new batteries or a power supply. 7. Battery Container: This container is for 4 x AA batteries.
-
Page 8: Support Timing Table
3D capable. SUPPORT PATTERN TABLE Group Pattern Description Purity Pattern Full Screen Purity terns: Black, White (100% Y) Primary colors: Red, Green, Blue P01: Red P02: Green P03: Blue P04: Black P05: White Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... - Page 9 P13 6 Color Bar Gray Scale 720p 50/60 only P12 6 steps TV Timing Info 720p 50/60 only P14 VESA Timings 720p 50/60 only P15 Video Timings Battery Info 720p 50/60 only P16 Battery level Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
-
Page 10: Connection And Installation
TION Group Pattern Description 3D Type P17 Frame Packing P18 Side-by-Side (Half) P19 Top-and- Bottom CONNECTION AND INSTALLATION LCD Monitor AT-HD800 HDTV Blu-ray Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 11: Safety Information
Attempting to do so could expose you to dangerous electrical shock or other hazards. It may also cause damage to your AT-HD800. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 12: Warranty
Atlona Technologies’ and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technologies’ decision, either return of the price paid for the product, repair, or replacement of the product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of the Customer’s receipt. -
Page 13: Atlona Product Registration
TION Atlona Product Registration Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure At Atlona, we respect and protect your privacy, assuring you that your registration information is completely secure.
