EL/GL Series - Mach 3
ML551/ML554 Quick Reference Guide
Light
Light

Jets 1

Jets 2

Initial Start-up

When your spa is first actuated, it will go into Priming mode
(after displaying some configuration information). Please
see the M-7 Installation Instruction Manual for complete
instructions on Power-up and Pump Priming.
The Priming mode will last for up to 4 minutes and then the
spa will begin to heat and maintain the water temperature
in the Standard mode. You can exit Priming mode early by
pressing "Cool" or "Warm."
Warm
Warm
Heat
Heat
Blower
Cool

Cool/Warm

Press the "Cool" or "Warm" button once to display the set
temperature. Each time either button is pressed again, the
set temperature will increase or decrease depending on
which button is pressed. After three seconds, the LCD will
automatically display the last measured spa temperature.
Jets 1
Press the "Jets 1" button once to turn pump 1 on or off,
and to shift between low and high speeds if equipped. If
left running, the pump will turn off after a timeout period.
The pump 1 low speed timeout on some systems may be
as long as 4 hours.
On non-circ systems, the low speed of pump 1 runs
when the blower or any other pump is on. It may also
activate for at least 1 minute every 30 minutes to detect
the spa temperature (polling) and then to heat to the set
temperature if needed, depending upon mode. When the
low speed turns on automatically, it cannot be deactivated
from the panel; however, the high speed may be started.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML551 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Balboa ML551

  • Page 1 Press the “Cool” or “Warm” button once to display the set temperature. Each time either button is pressed again, the ML551/ML554 Quick Reference Guide set temperature will increase or decrease depending on which button is pressed. After three seconds, the LCD will automatically display the last measured spa temperature.
  • Page 2 “Warm” followed by “Light” will revert the mode to locked, it cannot be changed from either panel. Economy immediately. Additional Features Refer to your User Guide for additional details and features that are available with your ML551 or ML554 panel and EL/GL Series system. 900854 P/N 40632-80_C 02/12/2008...
