- Page 1 Sonoma 12 Pergola Manual and Installation Instructions Please read these instructions before removing parts from crate...
- Page 2 Introduction Thank you for your purchase from The Outdoor GreatRoom Company. This pergola has been engineered and manufactured in the USA. This user manual will help make the installation and setup of your new pergola fast and easy. Outdoor GreatRoom company recommends visiting with your local authority for building codes, restrictions, or requirements for this product.
- Page 3 Included Parts: Arch Mending plate Foot Tall Corbel Short Corbel Post Brace Post Brace Col- ALL bolts require washers M10x 55 Hex Bolt (with nut and washers) M10 x160 Hex Bolt (with nut and wash- ers) Canopy Beam, T Canopy Beam, Right L Canopy Beam, Left L M10 x 90 Hex Bolt (with nut and wash-...
- Page 4 Step 2: Step 1: Step 3: Bolt steel footplate to each of four sup- plied posts “A” as shown. Use hardware “M”, and “O”. Apply construction adhesive to boards on one side and bolt beams together as shown using bolts “P” with a nut and washers. Bolt heads should be on the side comprised of beams Attach rectangular mending plates...
- Page 5 NOTE: In the remaining steps, a rubber mallet may be useful in fitting beams together properly. Step 5: Step 7: After end arched beams are Lay columns on level sur- Once header beams are installed, Tall Corbel Post face. Bolt ledger beams Braces “B”...
- Page 6 Step 8: Carefully position posts in final location. Check for square. Install cano- py beam assemblies with screw “R” at inter- sections with arch beams. The use of a level or similar tool is highly suggested.
- Page 7 Dimensional and Post Location Information NOTE 1: Recommended 12-18” DIA footing (12” minimum). Check local codes for depth minimums. Footing typically 24” mini- 109” +/-1” 114”+/-1” mum depth, 42” for extreme cold cli- mates. 109”+/-1” 154” +/-1” 5.25” 114+/-1” 5.5” 14”...
- Page 8 Sonoma Pergola Warranty Information Your new Sonoma 12 pergola is warranted against structural defects for a period of three (3) years from the date of purchase. This does not apply to damage caused by excessive loads such as snow or use of roof as storage. Your Sonoma pergola is warranted against defects in finish and other defects not related to structure for a period of one (1) year from the date of purchase.
