- Page 1 Pre-Installation Manual Sync November 2017 / 10-095400-091...
- Page 2 Sync Pre-Installation Manual © November 2017 by Brunswick Bowling Products. All rights reserved. Manual Part No. 10-095400-091 Notice: If available, updates to this manual can be found on-line at www.brunswickbowling.com. Confidential proprietary information. All information contained in this document is subject to change without notice.
- Page 3 Will designate a mechanical or nonelectrical alert which could potentially cause personal injury or death. WARNING! Will designate electrical alerts which could potentially cause personal injury or death. CAUTION! Will designate an alert which could potentially cause product damage. Will designate grounding alerts. Sync Pre-Installation...
-
Page 4: Table Of Contents
Sync Scoring Installation Schedule ..................13 Customer Responsibility .........................13 Installation Schedule ........................14 To Be Performed By Certified Field Mechanic ................14 To Be Performed By Brunswick Field Engineer ................14 To Be Performed By Brunswick Field Trainer ................15 Important ..........................16 Surge Suppression ...........................16 Brunswick’s Responsibility ......................16... - Page 5 Center Management System ......................62 Miscellaneous ..........................64 Required Certificates ......................65 Curtain Wall Structure Certification ....................65 Certification and Release of Brunswick Proprietors ...............65 Curtain Wall Structure Support Specifications ................66 Wide Screen LED OverheadVideo Display Structure Certification ..........67 Certification and Release of Brunswick Proprietors ...............67 Wide Screen LED Overhead Video Display Support Specifications ..........68...
- Page 6 Intentionally Blank Page Sync Pre-Installation...
-
Page 7: Overview
(POS) terminals for other areas of the center. SYNC TABLET Sync tablet is the top of the line scoring system in Sync. This system offers a lower touchscreen monitor and overhead monitors. Sync Tablet offers the convenience of touchscreen entry that can be free standing or integrated with Brunswick furniture in a table mount configuration. -
Page 8: Bowler's Keypad
This system consists of the overhead monitor and a keyboard console. This system gives the customer the ability of the Sync scorer. The system enables bowler interface into the system. This includes name entry, score correction, and the menu options. Like Bowler’s Touchscreen, Bowler’s Keypad is offered in both free standing and table mount configurations. -
Page 9: Preliminary Survey
Preliminary Survey BUILDING CONFIGURATION Phase and Voltage QUESTIONS ANSWERS Pinsetter Sub panel NOTE: Brunswick Surge Suppressors are required on each GS-pinsetter and scoring sub panels for new installations. All other installations have only one surge suppressor on the scorer panel. Scoring Sub panel Existing Equipment QUESTIONS ANSWERS Scoring Bowler’s Console NOTE: Vector keypad bowler’s consoles are compatible with Sync. Vector touchscreens are NOT compatible with Sync. Server Model Number... -
Page 10: Lane Configuration
Existing or New Building NEW EQUIPMENT QUESTIONS ANSWERS Scoring Quantity of Client Computers Digital Signage Remote Order Printers Wireless Handheld Ticket Depot Brunswick Music Network Overhead Type and Size Overhead Configuration Masking Units Video Projection Screen Type of Pinsetter or Pinsetter Interface Sync Pre-Installation... -
Page 11: Distances
Client #4 Distance from Control Desk Switch to Client #5 Distance from Control Desk Switch to Client #6 Intercom QUESTIONS ANSWERS Distance from the closest end lane bowlers keypad or touch screen to the audio box at control desk Sync Pre-Installation... -
Page 12: Audio/Video
NOTE: For any video source with only an HDMI connector, HDMI to Component adapter, pn 57-863630-000, must be purchased. VGA to Component adapter, pn 57-863631-000 is available for the 720 MODULATOR. Note: 57-863633-000, VGA to Component adapter ONLY FOR THE 1080 RESOLUTION MODULATOR. QUESTIONS ANSWERS Quantity of separate sources to display on overheads NOTE: Projectors video is not part of Sync scoring and must be supplied by customer. Quantity of 480 resolution modulator Quantity of 720 resolution modulator Quantity of 1080 resolution modulator Distance from the Video Distribution Center to the middle of... -
Page 13: Sync Scoring Installation Schedule
CUSTOMER RESPONSIBILITY NOTE: All pre work must be completed prior to equipment arrival. This includes Control Desk assembly and installation. 1. Site Survey to be performed by a Brunswick Field Engineer. The Field Engineer will need to meet with the center manager/proprietor, mechanic, electrician, and architect to cover the following: Determine non-bowling hours. -
Page 14: Installation Schedule
INSTALLATION SCHEDULE IMPORTANT: Brunswick installation completion will be delayed if Brunswick pre- installation requirements are not met. To Be Performed By Certified Field Mechanic Day 1 a. Travel to installation. b. Unload truck and unpack equipment. Days 2 and 3 a. -
Page 15: To Be Performed By Brunswick Field Trainer
To Be Performed By Brunswick Field Trainer Day 9 a. Travel to installation. b. Control desk management training. Day 10 a. Scorer training. b. Control desk session. c. Possible league coverage. Day 11 a. Continue control desk session. b. Cover leagues and open bowling. -
Page 16: Important
If you have questions regarding this document, call 1-800-YES-BOWL (1-800-937-2695) When planning to install Brunswick electronic scoring equipment, the customer is required to provide an electrical sub panel which is solely dedicated to the scoring systems with a neutral and ground buss. -
Page 17: Grounding Conductor - Nec 384-27
A relative level of 40% must be maintained to obtain optimum characteristics and performance from all equipment. A minimum of 35% and a maximum of 50% is possible if the temperature is controlled and constant. Sync Pre-Installation... -
Page 18: Electrical Overview
Pinsetter Sub panel - The Pinsetter sub panel provides power to the GS-Series pinsetters and other Brunswick equipment. The pinsetter sub panel must be powered directly from the primary main service sub panel or transformer and must be three phase. Non-Brunswick equipment including electronic video games, arc welders, HVAC, compressors, etc., cannot share this sub-panel. - Page 19 IMPORTANT!: Split house centers with multiple sub panels require a single source of power and ground from main service. Sync Pre-Installation...
-
Page 20: Scoring Sub Panel Installation
SCORING SUB PANEL INSTALLATION Single Phase Surge Suppressor Sync Pre-Installation... -
Page 21: Three Phase Surge Suppressor
Three Phase Surge Suppressor Sync Pre-Installation... -
Page 22: Electrical Quick Reference Checklist
Class-A CERTIFIED ground is recommended and should be measured at main service. Floating receptacles in the consoles MUST BE insulated. Metallic electrical boxes CANNOT touch console metal base. If local code permits, you may install “SO” cords with insulated female cord cap receptacle. NOTE: It is very important to read all the information available for the equipment being installed in your bowling center. Any deviation from these specifications could potentially cause problems to your electronic automatic scoring equipment that may be difficult to detect and/or correct. Sync Pre-Installation... -
Page 23: Selecting A Surge Suppressor
Needed TK-TT160-3Y208-FB 120/208/Three 4 Wire + Ground 57-861915-000 TK-TT160-1S240-FB 120/240/Single 3 Wire + Ground 57-861917-000 TK-TT160-3D240-FB 120/240/Three Delta 4 Wire + Ground 57-861916-000 TK-TT160-NN240-FB 240NN/Three Delta 3 Wire + Ground 57-861918-000 TK-TT160-3Y380-FB 220/380/Three 4 Wire + Ground 57-861919-000 Sync Pre-Installation... -
Page 24: Conduit And Low Voltage Cable Specifications
• Overhead Monitors Additional low voltage cables are routed from the office to the closest end lane pair pinsetter area. Various ways of doing this can be discussed with the Brunswick Service Representative at the time of the survey. The interconnecting cables are supplied and installed by Brunswick and routed through suitable conduit. -
Page 25: Electrical Receptacle Locations
ELECTRICAL RECEPTACLE LOCATIONS Overview Sync Pre-Installation... -
Page 26: Network Switch Location
Location of Network Switch on Curtain Wall and Overhead Structure 3,4 5,6 7,8 9,10 11,12 13,14 15,16 17,18 19,20 21,22 23,24 25,26 27,28 29,30 31,32 33,34 35,36 37,38 NOTE: There is NO need for an additional electrical outlet. The curtain wall and overhead switch can connect to other scoring equipment for power. Sync Pre-Installation... -
Page 27: Conduit
Conduit LOCATION IN FLOOR The illustration below shows a typical conduit network to accommodate all cables in the system. The conduit sizes shown apply to all scoring systems. NOTE: If local code requires low voltage electrical to be inside conduit, all conduit must be ELECTRICAL CONDUIT NOT plumbing/water conduit. Sync Pre-Installation... -
Page 28: Wood Floor
REFER TO DIMENSIONS ABOVE FOR PLACEMENT OF 2 X 4 LUMBER. THE REMAINING 2 X 4S MAY BE POSITIONED IN ANY MANNER THAT PROPERLY SUPPORTS THE FLOOR. ONE SUGGESTION IS TO PUT THE LUMBER ON 16” (406 MM) CENTERS. Sync Pre-Installation... -
Page 29: Pedestal
Pedestal INSTALLATION INFORMATION CUSTOMER’S RESPONSIBILITY: A LOW VOLTAGE 2” ELECTRICAL CONDUIT FROM THE CENTER LINE OF THE BALL LIFT TO THE PEDESTAL IS REQUIRED FOR LOW VOLTAGE CABLES. Sync Pre-Installation... -
Page 30: Oval Table
CUSTOMER’S RESPONSIBILITY: TRENCH OR ROUTE 2 EACH 2” ELECTRICAL CONDUIT FOR LOW VOLTAGE CABLES. THESE CONDUITS MUST BE 3” (76 MM) BELOW FLOOR SURFACE AND MEET LOCAL CODES. NOTE: A minimum space of 25” (635 mm) is required between the lane approach step and scorer. BRUNSWICK RESPONSIBILITY: SUPPLY AND ROUTE LOW VOLTAGE CABLES TO THE BOWLER’S KEYPAD OR TOUCH SCREEN. Sync Pre-Installation... - Page 31 REFER TO DIMENSIONS ABOVE FOR PLACEMENT OF 2 X 4 LUMBER. THE REMAINING 2 X 4S MAY BE POSITIONED IN ANY MANNER THAT PROPERLY SUPPORTS THE FLOOR. ONE SUGGESTION IS TO PUT THE LUMBER ON 16” (406 MM) CENTERS. Sync Pre-Installation...
-
Page 32: Triangle Table
CUSTOMER’S RESPONSIBILITY: TRENCH OR ROUTE 2 EACH 2” ELECTRICAL CONDUIT FOR LOW VOLTAGE CABLES. THESE CONDUITS MUST BE 3” (76 MM) BELOW FLOOR SURFACE AND MEET LOCAL CODES. NOTE: A minimum space of 25” (635 mm) is required between the lane approach step and scorer. BRUNSWICK RESPONSIBILITY: SUPPLY AND ROUTE LOW VOLTAGE CABLES TO THE BOWLER’S KEYPAD OR TOUCH SCREEN. Sync Pre-Installation... - Page 33 REFER TO DIMENSIONS ABOVE FOR PLACEMENT OF 2 X 4 LUMBER. THE REMAINING 2 X 4S MAY BE POSITIONED IN ANY MANNER THAT PROPERLY SUPPORTS THE FLOOR. ONE SUGGESTION IS TO PUT THE LUMBER ON 16” (406 MM) CENTERS. Sync Pre-Installation...
-
Page 34: Circular Ball Rack
CUSTOMER’S RESPONSIBILITY: A LOW VOLTAGE 2” ELECTRICAL CONDUIT FROM THE CENTER LINE OF THE BALL LIFT TO THE CIRCULAR BALL RACK IS REQUIRED FOR LOW VOLTAGE CABLES. FOR INFORMATION ON INSTALLING CIRCULAR BALL RACK ON WOOD STRINGER, REFER TO SECTION “WOOD FLOOR.” Sync Pre-Installation... -
Page 35: Coffee Table
LIFT TO THE COFFEE TABLE IS REQUIRED FOR LOW VOLTAGE CABLES. FOR INFORMATION ON INSTALLING COFFEE TABLE ON WOOD STRINGER, REFER TO SECTION “WOOD FLOOR.” IF USB POWER CONNECTION OPTION IS AVAILABLE IN COFFEE TABLE, FLUSH OR SIDE MOUNTED DUPLEX RECEPTACLES ARE REQUIRED. Sync Pre-Installation... -
Page 36: Bowler's Console Ethernet Switch
BOWLER’S CONSOLE ETHERNET SWITCH INSTALLATION INFORMATION CUSTOMER’S RESPONSIBILITY: A LOW VOLTAGE 2” ELECTRICAL CONDUIT FROM THE CENTER LINE OF THE BALL LIFT TO THE TRAP DOOR IS REQUIRED FOR LOW VOLTAGE CABLES. NOTE: No separate power outlet is needed, power available from curtain wall electronics. Sync Pre-Installation... -
Page 37: Location In Ceiling
Location in Ceiling Sync Pre-Installation... -
Page 38: Equipment Electrical Specifications
CIRCUIT. INSTALL CIRCUIT WITH 2 OUTLET. NO 2 WIRES + 200-220 50/60 MORE THAN 8 LANE PAIRS PER 16 AMP GROUND CIRCUIT. Electrical Information - Sync Tablet Power Supply (Sync Tablet Installations Only) AMPS BRANCH VOLTS HERTZ AC/DC PHASE WATTS... - Page 39 INSTALLATION INFORMATION CUSTOMER’S RESPONSIBILITY: PROVIDE A SUITABLE LOCATION ON THE CURTAIN WALL, AS SHOWN ABOVE, FOR THE MOUNTING THE PERIPHERAL CONTROLLER AND, AS NEEDED, ADD ON DEVICES INCLUDING SYNC TABLET POWER SUPPLY, CURTAIN WALL SWITCH, AND HDLC INTERFACE. IF A CURTAIN WALL IS NOT AVAILABLE, A SUPPORT STRUCTURE MUST BE INSTALLED TO HANDLE THE 25 LB.
-
Page 40: Automated Bumper System - Pinball Wizard
2 WIRES + INSTALL CIRCUIT WITH 2 OUTLETS. NO GROUND 200-240 50/60 MORE THAN 8 LANES PAIRS PER 16 #12AWG AMP CIRCUIT. WIRE INSTALLATION INFORMATION CUSTOMER’S RESPONSIBILITY: THE CUSTOMER MUST PROVIDE ELECTRICAL POWER SOURCE THAT COMPLIES WITH LOCAL CODE. Sync Pre-Installation... -
Page 41: Lightworx Power
ELECTRICIAN TO CONNECT. Circuit Requirements - Lightworx WIRES UNITS PER WIRE SIZE BREAKER SIZE RECEPTACLE SUPPLIED BY BRUNSWICK CIRCUIT CIRCUIT UP TO 10 12 GAUGE 20 A Receptacle Location Lightworx ONE JUNCTION BOX BELOW THE LIGHTWORX UNIT ON EACH BALL RETURN NEAR THE FOUL LINE. -
Page 42: Tel-E-Foul
ELECTRICIAN TO CONNECT. Circuit Requirements - Tel-E-Foul WIRES UNITS PER WIRE SIZE BREAKER SIZE RECEPTACLE SUPPLIED BY BRUNSWICK CIRCUIT CIRCUIT UP TO 10 12 GAUGE 20 A Receptacle Location Tel-E-Foul ONE JUNCTION BOX BELOW THE TEL-E-FOUL UNITS ON EACH BALL RETURN NEAR THE FOUL LINE NOTE: One on/off switch per Tel-E-Foul. -
Page 43: 32" Overhead Led Monitor ( 2 Or 3 Units Per Lane Pair)
THE PROPER POSITION OF THE SUPPORT PIPE. THE CUSTOMER IS ALSO RESPONSIBLE FOR HAVING THE STRUCTURE CERTIFICATE FORM COMPLETED BY AN ARCHITECT OR STRUCTURAL ENGINEER. SEE “WIDE SCREEN LED OVERHEAD VIDEO DISPLAY CERTIFICATE FOR SUPPORT WEIGHT SPECIFICATIONS. NOTE: Support pipes must be as straight as possible. Any variation in the support will affect overhead positioning. Sync Pre-Installation... -
Page 44: 40" Overhead Led Monitor ( 2 Or 3 Units Per Lane Pair)
THE PROPER POSITION OF THE SUPPORT PIPE. THE CUSTOMER IS ALSO RESPONSIBLE FOR HAVING THE STRUCTURE CERTIFICATE FORM COMPLETED BY AN ARCHITECT OR STRUCTURAL ENGINEER. SEE “WIDE SCREEN LED OVERHEAD VIDEO DISPLAY CERTIFICATE FOR SUPPORT WEIGHT SPECIFICATIONS. NOTE: Support pipes must be as straight as possible. Any variation in the support will affect overhead positioning. Sync Pre-Installation... -
Page 45: 49" Overhead Led Monitor ( 2 Or 3 Units Per Lane Pair)
THE PROPER POSITION OF THE SUPPORT PIPE. THE CUSTOMER IS ALSO RESPONSIBLE FOR HAVING THE STRUCTURE CERTIFICATE FORM COMPLETED BY AN ARCHITECT OR STRUCTURAL ENGINEER. SEE “WIDE SCREEN LED OVERHEAD VIDEO DISPLAY CERTIFICATE FOR SUPPORT WEIGHT SPECIFICATIONS. NOTE: Support pipes must be as straight as possible. Any variation in the support will affect overhead positioning. Sync Pre-Installation... -
Page 46: 55" Overhead Led Monitor (2 Units Lane Pair)
THE PROPER POSITION OF THE SUPPORT PIPE. THE CUSTOMER IS ALSO RESPONSIBLE FOR HAVING THE STRUCTURE CERTIFICATE FORM COMPLETED BY AN ARCHITECT OR STRUCTURAL ENGINEER. SEE “WIDE SCREEN LED OVERHEAD VIDEO DISPLAY CERTIFICATE FOR SUPPORT WEIGHT SPECIFICATIONS. NOTE: Support pipes must be as straight as possible. Any variation in the support will affect overhead positioning. Sync Pre-Installation... -
Page 47: Hd Video Distribution Center
There can be any number of different channels and modulators in the HD video distribution center. The quantity and type of modulator is determined by the customer. INSTALLATION INFORMATION NOTE: All video sources must have a component output. NOTE: The HD video distribution center must be within 3-4 ft (.9-1.2 m) of the component video source. Sync Pre-Installation... -
Page 48: Control Desk
CUSTOMER’S RESPONSIBILITY: THE CONTROL DESK SHOWN IS AN EXAMPLE OF A TWO TERMINAL CONTROL DESK. THE CONTROL DESK LAYOUT VARIES WITH INDIVIDUAL BOWLING CENTERS. THE DECISION OF EQUIPMENT LOCATIONS SHOULD BE MADE BEFORE POWER OUTLETS AND CONDUITS ARE INSTALLED. PLEASE PROVIDE OUTLETS IN SIMILAR CONFIGURATION AS SHOWN. NOTE: The CPU must be within 3-4 ft (.9-1.2 m) of the terminal and printer. NOTE: Two circuits are necessary for everything at the Control Desk. Sync Pre-Installation... -
Page 49: Office
100-130 50/60 1770 GROUND INSTALL CIRCUIT WITH APPROPRIATE OUTLETS. 2 WIRES + 200-240 50/60 1770 GROUND INSTALLATION INFORMATION CUSTOMER’S RESPONSIBILITY: INSTALL ONE CIRCUIT WITH TWO - 2 OUTLETS WITHIN THREE FEET (914 MM) OF THE UPS AND COMPUTER. Sync Pre-Installation... -
Page 50: Point Of Sale Terminal
CUSTOMER’S RESPONSIBILITY: THE POINT OF SALE TERMINAL CAN BE LOCATED IN VARIOUS AREAS OF THE BOWLING CENTER. THEY ARE TYPICALLY IN THE LOUNGE, SNACK BAR, PRO SHOP, OR BILLIARDS AREA. THE ELECTRICAL CONFIGURATION IS THE SAME FOR EACH LOCATION, A SUITABLE LOW VOLTAGE RACEWAY MUST BE INSTALLED FOR COMMUNICATION CABLES. Sync Pre-Installation... -
Page 51: Summary Of Electrical Information
Sync Pre-Installation... - Page 52 Sync Pre-Installation...
- Page 53 Sync Pre-Installation...
-
Page 54: Equipment Dimensions
Equipment Dimensions PEDESTALS Sync Pre-Installation... -
Page 55: Led Overhead Monitors
(406 mm) 22-3/4” (578 mm) 40” LCD Single Overhead 35.7” (906.78 mm) 16” (406 mm) 24.76” (699 mm) 49” LCD Single Overhead 43.18” (1097 mm) 16” (406 mm) 28.7” (729 mm) 55” LCD Single Overhead 48.4” (1229.36 mm) Sync Pre-Installation... -
Page 56: Circular Ball Racks
CIRCULAR BALL RACKS Sync Pre-Installation... -
Page 57: Oval Table
OVAL TABLE Sync Pre-Installation... -
Page 58: Triangle Table
TRIANGLE TABLE Sync Pre-Installation... -
Page 59: Coffee Table
COFFEE TABLE COFFEE TABLE (NARROW) Sync Pre-Installation... -
Page 60: Scoring
SCORING Sync Pre-Installation... - Page 61 Sync Pre-Installation...
-
Page 62: Center Management System
CENTER MANAGEMENT SYSTEM Sync Pre-Installation... - Page 63 Sync Pre-Installation...
-
Page 64: Miscellaneous
MISCELLANEOUS Sync Pre-Installation... -
Page 65: Required Certificates
Required Certificates Curtain Wall Structure Certification I, by signing this document, certify to Brunswick Bowling Products Corporation and to the proprietor named below that: I am an engineer/architect licensed by and in good standing with the State of ______________________; and I have examined the bowling center premises known as __________________________________________ , located at ___________________________________________________________________________ ;... -
Page 66: Curtain Wall Structure Support Specifications
If a curtain wall is not available, a support structure must be installed to accommodate the 30 pounds actual/static weight load per lane pair. Curtain Wall Mounting Sync Pre-Installation... -
Page 67: Wide Screen Led Overheadvideo Display Structure Certification
49" Monitors (lb/kg) 28.8 13.1 55" Monitors (lb/kg) 33.5 15.2 Weldment Length * Samsung LED monitor weight as specified in Samsung's (Feet / Meter) product specification literature TOTAL Figure 1. LED Monitors with Wide Screen Continuous Mounting Structure. Certification & Release of Brunswick by Architect/Structural Engineer I, by signing this document, certify to Brunswick Bowling Products Corporation and to the proprietor named below, that: I am an engineer/architect licensed by and in good standing with the State of ____________________________________________; and I have examined the bowling center premises known as ________________________________________________________________; located at; _________________________________________________________________________________________________; and The roof structure of the bowling center is fully and safely capable of supporting the additional static weight for each LED Overhead Video Display unit as indicated in Figure 1. Display support to be attached to the roof structure by the means and methods set forth in the support specifications on the reverse side of this page. Print or Type Name of Architect or Structural Engineer Signature of Architect or Structural Engineer Title Seal Date Certification &... -
Page 68: Wide Screen Led Overhead Video Display Support Specifications
Side View ELECTRICAL OUTLETS 60” (1.524 m) FRONT OF WIDE SCREEN LED 57” 57” 3” (1.448 m) (1.448 m) (76 mm) 120” (3.048 m) CONTINUOUS WELDMENT Top View Sync Pre-Installation... -
Page 69: Customer Purchased Overhead Monitor Waiver Of Liability And Hold Harmless Agreement
Sales Contract; WHEREAS, Brunswick will permit Buyer to self-install such equipment, if Buyer agrees to indemnify Brunswick and waive any claims against Brunswick arising from or related to the installation of such equipment pursuant to this Agreement. - Page 70 Intentionally Blank Page Sync Pre-Installation...
- Page 71 Sync Pre-Installation...
- Page 72 Intentionally Blank Page Sync Pre-Installation...
