Summary of Contents for ZENEC Z-E2050
- Page 1 Z-E2050 DEVICE INSTALLATION MANUAL...
- Page 2 COMPATIBILITY LIST Model Model Version Model Year VW Scirocco III 2008 – 2014 VW Amarok as of 2010 VW Sharan 2010 – 2013 VW Beetle Cabrio 2011 – 2015 VW Tiguan 2007 – 2013 VW Beetle Coupé 2011 – 2015 VW Touran 2003 –...
-
Page 3: Tools Required
● The ZENEC system is equipped with an integrated DAB+ receiver. To make use of this you will need a suitable DAB antenna (not included in kit) that must be connected to the ZENEC system. - Page 4 3. Now you can start with the uninstallation of the original device. 4. Please switch on the ignition only, once all installation steps are completed and the ZENEC system is firmly mounted. Gently lift the trim frame starting on the right side of OE device.
- Page 5 Route the USB extension cable (No. 7) from the radio bay to your preferred position. Connect one of the main connection cables (No. 4) of the ZENEC system (No. 1) to the Quadlock connector of the car and close its locking mechanism. Following this, connect the CAN bus interface (No.
- Page 6 12. Press the trim frame back on to make the installation complete. NOTE ● Make sure that all connectors at the rear of the ZENEC system have sufficient room and are not bent. ● Connectors without a retaining mechanism must be additionally secured with insulating tape. COMMISSIONING Finally carry out a general functional test and perform the basic and car specific settings (AC, OPS etc.).
-
Page 7: Connection Diagram
C14 N.A. C15 IR/IN C16 GND C17 N.A. C18 Camera +12V (max 300mA) C19 N.A. C20 N.A. C21 N.A. C22 N.A. C23 N.A. C24 N.A. ZENEC · Bohrturmweg 1 · CH-5330 Bad Zurzach · Schweiz/Switzerland · Mail: support@zenec.com · www.zenec.com...
