What's in the Box?
PART NO.
QTY
DESCRIPTION
HDS-8PS
1
HDMI 8-Port Splitter
Power Supply
1
PS12VDC3A
User Manual
1

Technical Specifications

VIDEO
Format
HDMI 1.3b [Deep Color, xvYcc color space supported]
DVI Compliance
Single-link DVI-D 1.1
HDCP Compliance
1.0/1.1
Video Bandwidth
Single-link 340MHz [10.2Gbps]
Resolution
480i,480p,720i,720p,1080i,1080p
Input Interface
(1) HDMI[7.1ch audio & video]
Output Interface
(8) HDMI[7.1ch audio & video]
Connector
Type A[19-pin female]
Maximum Distance
25 ft.
OTHER
DDC Signal
5-12 Volts [peak-to-peak], TTL
TDMS Signal
1.2 Volts[peak-to-peak], TTL
Power
External 12VDC3A
Dimensions
17"W x 1.75"H x 5"D
Weight
2 lbs.
Approvals
Device: CE, ROHS
Power Supply: C-UL US, CE
