D-Link DSL-2544N Quick Installation Manual page 2

Configuration Configuration
Web Browser Setup
1
Open a web browser (e.g., Internet Explorer, Chrome, Firefox, or Safari)
and enter the IP address of the router (http://192.168.1.1). The default
username and password will be admin and admin respectively.
Note: If you want to configure your modem router from a wireless computer or
mobile device, connect to the router wirelessly by going to your wireless utility
on your device. The default Wi-Fi Networks are D-Link DSL-2544N and D-Link
DSL-2544N 5Ghz. Select one and then continue to step 2.
2
When the Welcome screen appears, click Next to start the wizard.
3
Select your Time Zone from the list, click Next to continue.
4
Select your Country from the list, then enter your User Name and
Password as provided by your Internet Provider, click Next to continue.
5
Enter a new Wireless Network Name (SSID) for both the 2.4G and 5G
networks available in this modem router.
6
Select the security method that you wish to use for your wireless networks,
(D-Link recommends that you select BEST).
Enter a Pre-Shared Key (also known as a passphrase or Wi-Fi Password) for
each wireless network, click Next to continue.
7
Click Finish to complete setting up your router.
Congratulations! You have completed the modem router installation.
Link'n Print Utility
The Link'n Print allows you to share USB devices such as external storage drives and
multifunction printers with other users across your network by simply connecting
the device to your modem router This allows you to use an external storage drive
or printer located across your network as if it were connected to your local PC.
1
Download the application for your operating system from the below link
or by visiting the D-Link Support website as shown on the last page of this
guide and selecting the DSL-2544N from the list:
http://www.dlink.com.au/tech/download/download.aspx?product=DSL-2544N
2
Extract and Run the Setup/Installer that you have just downloaded.
3
When completed the Link'n Print utility will be installed and run on your
computer. Now you can Insert a USB device to your modem router.
4
Simply right click on the USB device you wish to use and click Connect, this
will now establish a direct connection to the USB device for your computer.
Troubleshooting
How do I connect my wireless devices to the DSL-2544N modem router?
1. Open your wireless network utility that displays available wireless networks.
2. Select the Wi-Fi Network name you assigned in the wizard and connect.
Note: If you did not run the setup wizard or you reset the router to its default
settings, refer to the label on the router for the default Wi-Fi Network Name and Wi-
Fi Password.
How do I change the wireless settings on the DSL-2544N modem router?
1. Open a web browser (e.g. Internet Explorer, Chrome, Firefox, or Safari) and
enter the IP address of the router (http://192.168.1.1).
2. At the login screen, type in admin for the user name and enter the router
password you created in the wizard (admin by default).
3. Go to Setup > Wireless Settings > Manual Wireless Network Setup to
create a new Wi-Fi network name (SSID) and Wi-Fi password.
How do I reset the DSL-2544N modem router to factory default settings?
1. Ensure the device is powered on.
2. Press and hold the WPS/reset button on the side of the device for 10 seconds.
Note:
Resetting the router to factory default will erase the current configuration settings.
To reconfigure your settings, log into the router using the and follow the Web
Browser Setup Wizard
Documentation available at http://www.dlink.com.au/DSL-2544N
Technical Support
Having trouble installing your new product? D-Link's website contains the latest
user documentation and software updates for D-Link products. Australian and New
Zealand customers can contact D-Link Technical Support through our website.
Australia
New Zealand
Internet: http://support.dlink.com.au
Internet: http://support.dlink.co.nz
