SPECIFICATION:
• Detection range: 360°, radius 4.5M at an installation
height of 3M.
• Duration time: from 10±5 seconds to 14±1 minutes
adjustable.
• Voltage: 220-240Vac 50Hz.
• Wattage: Max. 2000W incandescent lamp (resistive
load), Max. 500W fluorescent lamp (inductive load).
• Lux control level: from daylight to night adjustable.
CLEANING:
To avoid dust build-up and ensure proper
functioning of the PIR sensor, please wipe the sensor
lens lightly with a dry cloth every 3 months.
Do not use any chemical or abrasive cleaners.
Issue 2013
FOR PRODUCT ADVICE:
• T: 01933 673 144
• F: 01933 678 083
• E: sales@eterna-lighting.co.uk
EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
"WEEE Directive" effective August 2005—UK
WEEE Regulations effective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WHEN YOUR PRODUCT COMES TO THE END OF
ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE
RECYCLE IT WHERE FACILITIES EXIST - DO NOT
DISPOSE WITH HOUSEHOLD WASTE.
IF YOU EXPERIENCE PROBLEMS:
If you believe your product is defective, please return
it to the place where you bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, but may not be able to give specific
instructions regarding individual installations.
Visit our website:
www.eterna-lighting.co.uk
Installation INSTRUCTIONS
A guide for qualified electricians
Pack contents:
360º flush mounted PIR
with terminal cover
Model:
PIRFM360
Flush Mounted 360° Internal PIR Detector
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
AND RETAIN FOR FUTURE REFERENCE
Advertisement
Table of Contents
Related Manuals for Eterna PIRFM360
Summary of Contents for Eterna PIRFM360
- Page 1 3 months. it to the place where you bought it. Our Technical Team will gladly advise on any Eterna Lighting Do not use any chemical or abrasive cleaners. product, but may not be able to give specific Pack contents: instructions regarding individual installations.
- Page 2 READ THIS FIRST: OPERATION: You are advised at every stage of your installation to 63mm cutout size double-check any electrical connections you have This light fitting must be installed in accordance made. After you have completed your installation WALK TEST with the Building Regulations making reference to Spring upwards there are electrical tests that should be carried out:...
