Sensio SE30766C0 Installation Instructions

Please read these instructions carefully before installation.
Installation should be carried out by a qualified electrician.
GENERAL
THIS PRODUCT CONFORMS TO UK SAFETY STANDARDS AND MUST BE INSTALLED IN
ACCORDANCE WITH CURRENT IEE WIRING REGULATIONS AND BUILDING REGULATIONS (PART P).
THIS PRODUCT MUST BE EARTHED, AND SHOULD NOT BE CONNECTED TO AN UNEARTHED CIRCUIT.
IF THERE ARE ONLY TWO WIRES COMING FROM YOUR POWER SUPPLY IT MEANS THAT THIS FITTING
CAN BE WIRED TO AN UNEARTHED CIRCUIT.
ENSURE THAT CONNECTIONS ARE TURNED OFF AT THE CONSUMER UNIT OR FUSE BOARD BEFORE
INSTALLING OR CARRYING OUT ANY MAINTENANCE.
THIS PRODUCT IS FOR IN DOOR USE ONLY.
THIS PRODUCT IS IP44 RATED AND CAN BE INSTALLED IN BATHROOM ZONE 2 (AS DEFINED BY THE IEE
WIRING REGULATIONS) AND BEYOND. SEE BATHROOM DIAGRAM BELOW.
REPLACE FAILED LAMPS IMMEDIATELY. ALLOW THE GLASS, LAMP AND FITTING TO COOL
BEFORE REPLACING THE LAMP.
IEE Bathroom Zones Diagram
zone
2
Lucia - SE30766C0
IMPORTANT
When working at heights, please use a suitable platform to work from.
Please note: For new installations, check for any electrical cables or pipe
work (gas/water) in the vicinity of the intended mounting point before proceeding
with the installation.
Ensure that the fixing location is able to take the weight of the complete fitting.
Wear suitable eye protection when drilling. Be careful when using power tools near water.
MIN
150mm
LUCIA LED MIRROR - SE30766C0 INSTALLATION INSTRUCTIONS
60CM
60CM
zone
1
zone
zone
2
2
225cm
OUTSIDE ZONES
The product must be installed with a
minimum distance of 150mm between
the infrared sensor and an adjacent
countertop or obstruction to ensure correct
function of the sensor(see diagram left)
1 - 2
Do NOT strike mirror glass with hard or pointed items. It is
recommended that the product is cleaned with a soft, dry,
non abrasive cloth. Do NOT use cleaning agents or abrasive
materials on any type of finished surface. Do NOT allow
moisture to come into contact with the electrical components.
Compliance
This product complies with the following safety standards:
BS EN 60598-1: 2008+A11: 2009, EN60598-2-1: 1989
Wiring
This product is manufactured to class I category and requires
an earth connection
COLOUR CODING:
L - Live = Brown
- Neutral = Blue
- Earth = Green & Yellow
Any Queries Call : 0845 0340 780
