Installation Manual
XLA 3200
Installation Manual
EN Line Array Loudspeakers
Manuel d'installation
FR Enceintes colonnes
Installationshandbuch
DE Line-Array-Lautsprecher
Manual de instalación
ES Altavoces de línea vertical
Installatiehandleiding
NL Line Array Luidsprekers
Manuale d'installazione
IT
Colonne sonore
Manual de instalação
PT Coluna linear de altifalantes
EN | 1
Advertisement
Related Manuals for Bosch XLA 3200
Summary of Contents for Bosch XLA 3200
- Page 1 EN | 1 XLA 3200 Installation Manual EN Line Array Loudspeakers Manuel d'installation FR Enceintes colonnes Installationshandbuch DE Line-Array-Lautsprecher Manual de instalación ES Altavoces de línea vertical Installatiehandleiding NL Line Array Luidsprekers Manuale d'installazione Colonne sonore Manual de instalação PT Coluna linear de altifalantes...
- Page 3 Installation Manual EN Line Array Loudspeakers Manuel d'installation FR Enceintes colonnes Installationshandbuch DE Line-Array-Lautsprecher Manual de instalación ES Altavoces de línea vertical Installatiehandleiding NL Line Array Luidsprekers Manuale d'installazione Colonne sonore Manual de instalação PT Coluna linear de altifalantes...
- Page 5 EN | 5 XLA 3200 | Installation Manual | Contents Page Installation guide (fig 1 - fig 17) ........................6 Line/Loudspeaker supervision board mounting (optional) (fig A1 - fig A5) ........8 Additional bracket mounting (optional) (fig B1 - fig B5) ..............8 Foorstand mounting (optional) (fig C1 - fig C3)..................8...
- Page 6 EN | 6 XLA 3200 | Installation Manual | LBC 3210/00 and LBC3201/00 only! (See B1 to B5) LBC 3210/00 LBC 3201/00 LBC 3200/00 See 11 6 mm (max.) 90 mm Use foam packaging to 300 mm 300 mm protect cabinet during...
- Page 7 EN | 7 XLA 3200 | Installation Manual | Loop-through Left or right entry Center entry Default setting is ‘1’ (nominal power) Loop-through Tighten! Bosch Security Systems | January 2004...
- Page 8 EN | 8 XLA 3200 | Installation Manual | Instructions A1 to A5 Surveillance board mounting (for LBC 3210/00 only!) Refer to the installation instructions supplied with the PCB Make bracket to required length (not supplied) LBC 1259/00 Bosch Security Systems | January 2004...
- Page 9 EN | 9 XLA 3200 | Installation Manual | Listening area and related mounting height for XLA3200/00 Determining mounting height and angle for the • If I cannot see the loudspeaker array, does it mean LBC3200 loudspeaker array: that I cannot hear high tones? 1.Determine the dimensions of the desired ‘listening area’...
- Page 10 EN | 10 XLA 3200 | Installation Manual | Figure 1 side view of loudspeaker array radiation mounted to the wall with a small angle Figure 2: side view of loudspeaker array radiation mounted to the wall with a 5...
- Page 11 EN | 11 XLA 3200 | Installation Manual | Listening area and related mounting height for XLA3201/00 How to use these mounting method: Installation questions and answers: 1.Determine the dimensions of the desired ‘listening area’ • The desired listening area is too large and does not (a horizontal plane at the level of the listeners’...
- Page 12 EN | 12 XLA 3200 | Installation Manual | • Depending of the amount of reverberation in the • To determine exactly were the edges of the listening room and the sound shadow (people or objects in area are in your situation, you have to carry out a...
- Page 13 EN | 13 XLA 3200 | Installation Manual | Figure 1: side view of loudspeaker array radiation and listening plane Figure 2: 1kHz octave shape of the loudspeaker array Figure 3: 4kHz octave shape of the loudspeaker array Figure 4: Focus the 0...
- Page 14 EN | 14 XLA 3200 | Installation Manual | Listening area and related mounting height for XLA3210/00 How to use these mounting method: Installation questions and answers: 1.Determine the dimensions of the desired ‘listening area’ • The desired listening area is too large and does not (a horizontal plane at the level of the listeners’...
- Page 15 EN | 15 XLA 3200 | Installation Manual | front of a listener who block the direct sound source), Background information: the speech intelligibility at the furthest positions may • The shapes are defined in an anechoic environment. be low. In these situations, it is better use more In these shapes at anechoic conditions, you have a loudspeaker arrays to split the listening area.
- Page 16 EN | 16 XLA 3200 | Installation Manual | Figure 1: side view of loudspeaker array radiation and listening plane Figure 2: 1kHz octave shape of the loudspeaker array Figure 3: 4kHz octave shape of the loudspeaker array Figure 4: Focus the 0...
- Page 17 EN | 17 XLA 3200 | Installation Manual | TECHNICAL PERFORMANCE DATA LBC 3200/00 Maximum power 45 W Rated power 30 W (30-15-7.5 W) Sound pressure level at 30 W/1 W (at 1 kHz, 1 m) 106 dB/91 dB (SPL)
- Page 18 EN | 18 XLA 3200 | Installation Manual | Horizontal Vertical Bosch Security Systems | January 2004...
- Page 19 EN | 19 XLA 3200 | Installation Manual | Horizontal Vertical Bosch Security Systems | January 2004...
- Page 20 EN | 20 XLA 3200 | Installation Manual | TECHNICAL PERFORMANCE DATA LBC 3201/00 Maximum power 90 W Rated power 60 W (60-30-15 W) Sound pressure level at 60 W/1 W (at 1 kHz, 1 m) 110 dB/92 dB (SPL)
- Page 21 EN | 21 XLA 3200 | Installation Manual | Horizontal Vertical LBC 3201/00 250Hz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120° 210° 150° 180° LBC 3201/00 500Hz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120°...
- Page 22 EN | 22 XLA 3200 | Installation Manual | Horizontal Vertical LBC 3201/00 2kHz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120° 210° 150° 180° LBC 3201/00 4kHz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120°...
- Page 23 EN | 23 XLA 3200 | Installation Manual | TECHNICAL PERFORMANCE DATA LBC 3210/00 Maximum power 90 W Rated power 60 W (60-30-15 W) Sound pressure level at 60 W/1 W (at 1 kHz, 1 m) 115 dB/97 dB (SPL)
- Page 24 EN | 24 XLA 3200 | Installation Manual | Horizontal Vertical LBC 3210/00 250Hz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120° 210° 150° 180° LBC 3210/00 500Hz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120°...
- Page 25 EN | 25 XLA 3200 | Installation Manual | Horizontal Vertical LBC 3210/00 2kHz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120° 210° 150° 180° LBC 3210/00 4kHz vertical 0° 330° 30° 300° 60° 270° 90° 240° 120°...
- Page 26 www.boschsecuritysystems.com Data subject to change without notice | 2004 - 9922 141 50601en...
