ZyXEL AMG1302-11C
FIBRE WiFi ROUTER
POWER ETHERNET WLAN WPS DSL INTERNET
1 4
2 3
CONNECTING TO FIBRE
Using the Blue Ethernet cable, connect the LAN port of the Fibre Unit (ONT)
to the blue port labelled "WAN" on the back of the router
CONNECTING A DEVICE TO THE
ROUTER VIA A LAN CABLE
You will need a second LAN cable for this step. Plug one end of the LAN
cable into the LAN port of your PC
into the yellow LAN port labelled LAN1, LAN2, LAN3, or LAN4 on the
back of the router Follow to connect without a second LAN cable.
CONNECTING A DEVICE TO
THE ROUTER WITH WiFi
If your WiFi-enabled device is equipped with a WPS button, press the
WPS button on the back of the router until the WPS LED blinks. Press
the WPS button on the WiFi-enabled device and allow 2 minutes for a
secure WiFi connection to be established.
Plug the other end of the LAN cable
IN THE BOX
Quick Start Guide
Fibre WiFi Router
Router Stand
CONNECTING THE
POWER SUPPLY UNIT
Plug the power supply unit into the wall socket and connect the small
round plug from the power supply unit into the power socket on the
back of the router. Switch the power on at the wall socket and press the
red power button on the back of the router. The power LED on top of
the router will light up.
CONNECTING A DEVICE TO
THE ROUTER WITH WiFi
The default SSID (WiFi Network Name) and WiFi key (WiFi Password)
are displayed on the bottom of your router. Ensure that the WLAN LED
on top of your router is lit up. If the LED is not lit, open a web browser
on your device and type 192.168.1.1 into the address bar at the top.
Enter the username and password (admin/admin). Click on WLAN in the
menu on the left. Click on Basic Settings and uncheck the box named
"Disable WLAN Interface". On your WiFi-enabled device, browse for
and select the router's SSID (WiFi Network Name). Use the WiFi key
when prompted to connect your device to the WiFi network.
CONFIGURE YOUR ROUTER
Open an Internet browser (e.g. Google Chrome) on your device. Enter
192.168.1.1 into the address bar and enter the default username (admin)
and password (admin). Follow the Quick Setup instructions to complete
the Fibre configuration on your device. If you are having trouble, contact
MWEB Tech Support for Help.
Power Supply Unit
Grey Telephone Cable
Yellow Ethernet Cable
