Reliance Water Heaters 184735-000 Instruction Manual

Residential point of use electric water heaters for potable water heating only
Hide thumbs
Table of Contents

Advertisement

Quick Links

GAMA certification applies to all
residential electric water heaters
with capacities of 20 to 120 gallons.
Input rating of 12 Kw or less.
ALL TECHNICAL AND WARRANTY QUESTIONS: SHOULD BE DIRECTED TO THE LOCAL DEALER FROM WHOM THE WATER HEATER WAS
PURCHASED. IF YOU ARE UNSUCCESSFUL, PLEASE WRITE TO THE COMPANY LISTED ON THE RATING PLATE ON THE WATER HEATER.
KEEP THIS MANUAL IN THE POCKET ON HEATER FOR FUTURE REFERENCE
PRINTED IN THE U.S.A 0104
RESIDENTIAL POINT OF USE ELECTRIC
WHEN EVER MAINTENANCE ADJUSTMENT OR SERVICE IS REQUIRED.

Instruction Manual

WATER HEATERS
FOR POTABLE WATER
1
HEATING ONLY
NOT SUITABLE FOR
SPACE HEATING
LISTED
PART NO. 184735-000
