Cray CX1 Quick Start User Manual

CRAY CX1
QUICK START USER'S GUIDE
Safety Information: Enclosure Cover:
Before removing the CX1 system from its box, In compliance with applicable safety, emission,
to prevent any damages to the system itself or and thermal requirements, no covers should
injury to the person handling the CX1, all the be removed and all bays must be filled with
safety cautions must be read. compute shelves.
Installation and Service: Electrostatic Discharge:
To avoid injury from electrical shock, only Observe normal Electrostatic Discharge (ESD)
qualified technical service personnel can procedures during system integration to avoid
perform any type of service or installation on possible damage to the server board and/or
this system. other components of the system.
CX1 QUICK START GUIDE SECTIONS
GETTING TO KNOW THE CX1 STAGE 1 - UNPACKING
(RED SECTION) (BLUE SECTION)
GETTING TO KNOW THE CX1
FRONT PANEL
GET 1.1
Shipping Information:
Do not ship any CX1 compute shelves within the CX1
system chassis. Doing so may result in damage to
the CX1 system.
CX1 System Power:
The power cord must be disconnected before
installing or removing any shelves. Dedicate a
20 Amp AC Outlet exclusively to the CX1.
The high processor count of the CX1 could require
the draw of a full 20 Amp circuit.
STAGE 2 - PRE-ASSEMBLY STAGE 3 - ASSEMBLY STAGE 4 - POWERING THE CX1
(YELLOW SECTION) (GREEN SECTION) (GREY SECTION)
REAR PANEL
Future USB 1
Expansion (to front of system)
Power Inlet 110-250V
GET 1.2
UNPACKING
THE CX1 SKID PACK AGING
Box Contents
[1] Documentation Box
[2] Chassis Cart Box
[3] Rail Box
[4] Main Chassis Box
[5] Power Supply Box
[6] Blade Box
[7] Cables
[8] Accessories
THE CX1 ROADCASE PACK AGING
Unlocking the CX1 ROAD CASE
Remove the front portion of the case (2 latches on the right side)
USB 2
USB
(to DVD-ROM)
50-60Hz 20A
CX1 ROAD CASE
Package Contents
1
2
3
4
5
6
7
Qty
1
1
STEP 1
1
1
2
2
1
1
STEP 4
FRONT
2
1
3 4
6
5
5
STEP 2 STEP 3
1
7
2
5
4
6
5
8
3
6
BACK
7
