Getting started with the USB-525

Getting started with the USB-525
This quick start explains how to configure and log data with a USB-500
Series temperature/humidity data logger using the USB-525 Logger
Assistant for the first time.

Minimum and recommended system requirements


Computer with Pentium® II-class processor,
450 MHz (Pentium III class processor, 650 MHz or higher
recommended)

Windows 8/7/Vista/XP (32- or 64-bit)

Power on the USB-525

To power on the USB-525, press-and-hold the button on the front of the
device until the screen turns on.
The USB-525 battery comes approximately 25% charged so you can try
the device straight out of the box. The USB-525 powers down and
cancels any operation after five minutes of inactivity. Touch the screen
before five minutes elapses to keep the device powered on.

Example: Configuring a data logger

Complete the following steps to configure a USB-500 Series data logger
using the USB-525:
With the USB-525 powered on, insert a compatible USB-500 Series
1.
data logger into the USB port on the top of the USB-525.
Press Set-Up Logger.
2.
Press Full Set-Up.
3.
Press Next
4.
Press Next
5.
to retain the current logger name.
to retain the current temperature units.
3
