- Page 1 KARMAN HEALTHCARE XO-505 INSTRUCTION MANUAL Power Stand-Up and Recline Power Wheelchair 07/07/2015EC...
-
Page 2: Table Of Contents
Contents XO-505 Series : Parts Explanation Chapter 1. SAFETY TIPS 1-1. Standing 1.2. Important point to note for operating the wheelchair 1-3. Safety information on driving and free wheel mode 1-4. Rear wheels 1-5. Armrests 1-6. Power drive attachments 1-7. Modifications Chapter 2. - Page 3 Chapter 5. OPERATION THE STANDING AND SITTING Chapter 6. CONTROL SYSTEM 6-1. The Dynamic DX2 remote 6-2. Battery and control box connection 6-3. Battery charge 17~18 6-4. Main Circuit Breaker 6-5. System Lock / unlock & Sleep mode / wake up 6-6.
-
Page 4: Safety Tips
XO-505 Series Headrest Joystick Backrest Front Stick Supporter Armrest Seatrest Side Panel Knee Support Recline Actuator Legrest Footrest Motor/Differential Footrest Gear Anti-Tipper wheel Swing Caster Rear Wheel Front Wheel H-style Belt Chapter 1. SAFETY TIPS 1-1. Standing Attention： Open the master power switch before using. ( See Chapter 6 , P18 ) - Page 5 ● Before using the stand up wheelchair you should supposed to be familiar with the operation and the function. ● Use only standard household and hard even ground. Not use in the ground of dripping wet. ● In case of staircase, the stand up wheelchair must be carried by two persons. ●...
-
Page 6: Important Point To Note For Operating The Wheelchair
1-2. Important point to note for operating the wheelchair : The following action should not attempt to try DO NOT DRIVE OVER UNEVEN GROUND! Danger of tipping over! DO NOT LEAN OUT OF THE RAISED VERTICALIZER! Danger of tipping over! NEVER DRIVE ON ASCENDING OR DOWNWARD SLOPES WHEN THE VERTICALIZER IS RAISED! Danger of tipping over! -
Page 7: Rear Wheels
obstacle in one stroke! Do not stop halfway! Do not exceed the maximum obstacle height! ● Avoid shifting your center of gravity as well as abrupt joystick movements and changes of direction when the wheelchair is in motion! ● Never use the wheelchair to transport more than one person! ●... -
Page 8: Wheelchair For Use
Chapter 2. UNPACKING AND PREPARING THE POWER STAND UP WHEELCHAIR FOR USE 2-1. The Original Package And Accessories The Following Components: ● Power Stand up wheelchair & Joystick & Heel strap & chest belt ● Knee Support ● Charger ● User manual, Oil pot and tool ●... - Page 9 003 After the back cushion to stop 004 Alignment holes and tighten the positive ,Align the hole and tighten screw screws ( Not too tighten ) 005 Complete screws locking 006 To assemble the Actuator and tighten the screw ( Not too tighten ) 007 Use cable tie to fixed cable 008Use cable tie to fixed cable...
- Page 10 009 Use cable tie to fixed cable 010 Use cable tie to fixed cable 011 To assemble head rest 012 To assemble head rest...
-
Page 11: Chapter 3. Adjustment
Chapter 3. ADJUSTMENT Should you require adjustments and alterations to the mechanism of the wheelchair, or any maintenance work, please contact qualified technicians. 3-1. Adjusting the Seat Depth （1）Push the Joystick forward let the wheelchair frame rise . (Fig-7) ( 2）After loosening the left（right）both side screws the seat depth can be adjusted using the different holes at 1 inch distance.（Fig-8 &... -
Page 12: Adjusting The Footrest Height
3-2. Adjusting the Footrest Height The height of the footrest is adjustable and should be altered in line with your body proportions to guarantee the best standing position possible. Footrest adjustment should also take account of your choice of seat cushion. （Fig-11 ~ 14） ●... -
Page 13: Adjusting The Footrest Angle
3-3. Adjusting the Footrest Angle ● After release the screws the footplate angle can be adjusted using the different hole for 3 range. （Fig-15 & 16） ● Retighten the screws.（Fig-17） 3-4. Adjusting the Knee Support and Safety Belt and Chest Belt The most important safety features of the stand up wheelchairs are the knee support &... - Page 14 3-4-2. The safety belt （Fig-20） ● The safety belt holds the waist in place. ● Make sure that the safety belt is secure on the backrest of velour fasten. ● Close the catch on the safety belt and pull it and not too tight. ●...
-
Page 15: Adjusting The Armrest Height
3-5. Adjusting the Armrest Height （1） Release the left（right）screws can be removed to suit position.（Fig-24） （2） Retighten the screws .(Fig- 24) 3-6. The Heels Strap （Fig-25） The purpose of the heel strap is to prevent the legs and feet slipping backwards. It is fitted behind the heels or higher. -
Page 16: The Seat Cushion
3-8. The Seat Cushion There is a choice of various different seat cushions, governed by your individual needs. The Velcro fasteners fitted to the surface of your seat should allow you to attach the majority of set cushions securely. The Velcro fasteners prevent the cushion from slipping out of place even when you are standing up. -
Page 17: Chapter 4. Driving
Chapter 4. DRIVING 4-1. Before Driving for the First Time Before you take your first trip, you should familiarize yourself well with the operation of the vehicle and with all operating elements. Take your time to test all functions and driving modes. -
Page 18: Free Wheel
DANGER: ● When the vertical is raised drive operation only serves positioning and not normal driving. ● Never driver over uneven ground, on an upward or downward slope obstacles when the vertical. 4-4. Free Wheel Because the motors are designed to engage the electromagnetic brakes when the vehicle is not in use or when the power is OFF. -
Page 19: Chapter 5. Operation The Standing And Sitting
Chapter 5. OPERATION THE STANDING AND SITTING 1. First, adjusting and fixed the knee support to suit position and make sure the two triangular form of knee support lock to the double-head screws of frame. （Fig-31 & 32） 2. Fixed the safety belt and chest belt.（Fig-33） 3. -
Page 20: Chapter 6. Control System
Chapter 6. CONTROL SYSTEM Master power switch ※ Open the master power switch before using. 6-1. The Dynamic DX2 Remote Assembly of the remote 1. ON/OFF 2. Left indicator button 3. Function keys I 4. Drive Profile selection+ 5. Drive Profile selection- 6. -
Page 21: Battery And Control Box Connection
6-2. Battery and Control Connection The main electrical control system is composed of motor, Control box battery and controller. The connection of control system as below. 6-3. Battery Charge （Fig-34） 1. First, the battery charger line connect to the battery DC power socket and make sure the line is right connect. -
Page 22: Main Circuit Breaker
Battery Warnings Battery warnings are shown at the centre of the screen, in the "Active Mode" area Attention: 1. Anytime check the battery capacity. 2 .New battery must charged over 8 hours. 3.Charge your battery from the battery charger provided by manufacturer only. 6-4. -
Page 23: System Lock / Unlock & Sleep Mode / Wake Up
6-5. System Lock / unlock & Sleep mode / wake up If the Lock Enable parameter is set to 'Yes', the system can be locked by pressing the power button for more than 4 seconds. To lock the DX System Press the power button for 4 seconds when the DX System is turned on. -
Page 24: Standard Menu Navigation Drive Mode - Standard
6-6. Standard Menu Navigation Drive Mode - Standard The colour of the current Drive Profile, shown in the middle of the screen, is dependent on the chair’s status. A green Drive Profile shows a normal drive operation An orange Drive Profile is displayed to indicate that a chair can drive, or is driving in a restricted capacity –... -
Page 25: Accessory Mode - Standard
Accessory Mode – Standard 6-7. Accessory Modes are available: when the presence of that accessory is detected in the DX System; ● when the menu of that accessory has been enabled with its corresponding ● menu enable parameter When the Accessory Mode button is pressed (either Next or Previous) the menu will always start at the Seating Accessory screen (if actuators are active). -
Page 26: Flash Codes
6-8. FLASH CODES Flash codes indicate the nature of an abnormal condition directly from the DX2 Information Gauge. Without the use of any servicing tools, the condition can be simply diagnosed. Flash Action Description Code Turn the DX System off then on again. DX Module Fault Check DXBUS connections and replace where necessary.. -
Page 27: Chapter 7. Maintenance
Chapter 7. MAINTENANCE ● When cleaning your stand up wheelchair use a dry or slightly moistened cloth to wipe the wheelchair down. For stubborn or oily stains, apply a mild detergent to the cloth. Do not hose down your wheelchair with water. ●... - Page 28 WARNING! Failure to maintain the brushes could void the power wheelchair warranty. To inspect or replace the motor brushes: 1. Unscrew the motor brush caps. (Fig-45) 2. Remove the brushes. 3. Inspect the brushes for wear. (Fig-46) 4. Replace the brushes if necessary. This product has been supplied from an environmentally aware manufacturer that complies with the Waste Electrical Equipment ( WEEE) Directive 2002/96/EC.
- Page 29 NOTICE This chair is not intended for those who have: -Lower limbs joint contracture (absolute contra-indication) -Total hip replacement (THR) and total knee replacement (TKR) -Instability on lower extremity joints -Severe osteoporosis on lower extremities -Severe abnormal reflex (lower extremities withdraw reflex) -Severe postural hypotension -Low-shearing seat will be suggested to those who use positioning system...
- Page 30 This warranty is for the replacement or repair, at the option of Karman Healthcare Inc., of defective parts only and does not cover any labor charges including, but not limited to, charges incurred for installation of replacement parts or additional fees, which may be imposed by Karman Healthcare Inc.
